BEST BEST CEFBB199-66 Brass/Bronze Full Mortise Ball Bearing Concealed Conductor Heavy Weight Electrified Hinge With 6-Wire BEST-CEFBB199-66

BEST CEFBB199-66 Heavy Duty Full Mortise Ball Bearing Electrified Hinge with 6-Wire Concealed Conductor

(No reviews yet) Write a Review

Model: BEST-CEFBB199-66-626-4.5x4.5
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$248.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

BEST CEFBB199-66 Heavy Duty Full Mortise Ball Bearing Electrified Hinge with 6-Wire Concealed Conductor

Commercial-Grade Electrified Hinge with Concealed Conductor Technology

The BEST CEFBB199-66 is a heavy-duty electrified hinge engineered for commercial door applications requiring reliable electrical connectivity. This full mortise ball bearing hinge features concealed conductor technology with 6-wire configuration (2@24AWG, 4@28AWG) for enhanced versatility in electronic access control systems. Constructed with brass/bronze materials and available in 626 satin chromium plated finish, this hinge conducts current regardless of door position while maintaining tamper-proof security with no exposed electrical components.

Professional Features & Benefits

  • 6-Wire Concealed Conductor: Features 6-wire configuration (2@24AWG, 4@28AWG) for versatile wiring options and enhanced compatibility with electronic access control systems.
  • Heavy-Duty Ball Bearing Construction: Full mortise design with ball bearings ensures smooth and reliable operation for demanding commercial applications.
  • Tamper-Proof Electrical Integration: Concealed conductor technology allows current transmission regardless of door position with no exposed electrical parts when installed.
  • Commercial-Grade Materials: Brass/bronze construction with 626 satin chromium plated finish provides exceptional durability and aesthetic appeal for professional installations.
  • Versatile Electronic Compatibility: Designed for integration with electric locks, exit devices, hold open devices, and access control signal transmission from code readers to remote computers.
  • Permanent Fast Pin Design: Secure permanent fast pin construction prevents unauthorized removal while maintaining operational reliability.
  • Complete Installation Package: Packed one per box with all machine screws and installation instructions for professional installation.
  • Junction Box Compatible: Designed for use with junction box systems for proper electrical integration and code compliance.

Technical Specifications

  • Bearing Type: Ball Bearing
  • Commercial/Residential: Commercial
  • Corner Style: Square Corners
  • Department: Door Hardware
  • Duty Level: Heavy Duty
  • Electronic: Yes
  • Hinge Type: Electrified
  • Knuckles: 5
  • Lock Type: Mortise
  • Number of Wires: 6
  • Package Includes: Concealed Conductor
  • Product Category: Door Hinges and Pivots
  • Product Group: Door Hinges and Pivots
  • Product Model: CEFBB199-66
  • Product Subgroup: Electrified Hinges
  • Product Type: Electrified Hinges
  • Series: Electrified Hinges
  • Subcategory: Hinges

Installation & Operation

  1. Verify electrical requirements and confirm compatibility with existing access control systems before proceeding with installation.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Install hinge in the center hinge location as specified by manufacturer requirements for proper electrical conductor function.
  4. Route and connect 6-wire configuration (2@24AWG, 4@28AWG) according to manufacturer wiring diagrams using appropriate junction box connections.
  5. Configure electrical connections for integration with electric locks, exit devices, or access control signal transmission per application requirements.
  6. Restore power and test all electrical functions including current transmission regardless of door position and integration with connected electronic systems.
  7. Complete final inspection and document wiring configuration. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Commercial Building Access Control Systems
  • Healthcare Facility Electronic Security
  • Educational Institution Safety Systems
  • Government and Municipal Building Security
  • Industrial Facility Monitoring
  • Multi-Tenant Residential Electronic Access
  • Retail Security Integration

Why Choose BEST Quality?

BEST electrified hinges deliver professional-grade reliability with heavy-duty ball bearing construction and tamper-proof concealed conductor technology. The brass/bronze materials with satin chromium plated finish provide exceptional durability rated for demanding commercial applications. Engineered for seamless integration with electronic access control systems where dependable electrical connectivity and security are essential.

Product Specs

Subcategory:
Hinges
Series:
Electrified Hinges
Hinge Type:
Electrified
Knuckles:
5
Bearing Type:
Ball Bearing
Corner Style:
Square Corners
Product Group:
Door Hinges and Pivots
Product Subgroup:
Electrified Hinges
Product Type:
Electrified Hinges
Number of Wires:
6
Duty Level:
Heavy Duty
Commercial/Residential:
Commercial
Electronic:
Yes
Lock Type:
Mortise
Package Includes:
Concealed Conductor
Product Model:
CEFBB199-66
Product Category:
Door Hinges and Pivots
Department:
Door Hardware

BEST BEST-CEFBB199-66-626-4.5x4.5 – Frequently Asked Questions

1) What size and finish does the BEST CEFBB199-66 electrified hinge come in?
The CEFBB199-66 is sold as a 4.5 x 4.5 inch hinge in 626 satin chrome. That is the standard commercial leaf size for a 1-3/4 inch door, so it drops into typical hollow metal and wood door hinge prep with square corners.
2) How many wires does the BEST CEFBB199-66 concealed conductor hinge carry, and what gauge?
Six conductors: two at 24AWG and four at 28AWG. The heavier 24AWG pair is normally used for the power-consuming device (electric lock or exit device solenoid) and the 28AWG conductors for signal or monitoring runs back to a card reader or access control panel. If your device list needs more than six circuits, you need a different transfer.
3) Where in the door does the electrified hinge have to be installed?
Mount it in the center hinge position. The remaining hinge locations use standard non-electrified hinges, so you order one CEFBB199-66 plus matching standard hinges to fill out the opening. Power is routed through a junction box in the frame.
4) What is the closest equivalent to the BEST CEFBB199-66 if I need the same 6-wire electrified hinge from another maker?
The RCI 952 is the nearest match on wiring: it is an electrified hinge with 6-conductor wiring and ball bearing construction, the same conductor count and bearing type as the CEFBB199-66, which carries 6 wires and ball bearings. The difference is duty level - the RCI 952 is listed as medium duty, while the BEST CEFBB199-66 is a heavy duty hinge.
5) I need more than six conductors through the door - what electrified hinge should I use instead?
Step up to the Detex EWH8, a five knuckle electric hinge in 4.5 inch by 4.5 inch with 8 wires and a satin chrome finish. The BEST CEFBB199-66 carries 6 wires (2 at 24AWG and 4 at 28AWG), so if your access control run needs eight conductors, the EWH8 covers it in the same 4.5 x 4.5 size and five knuckle configuration.
6) Does current still pass when the door is open, or only when it is closed?
Current transmits regardless of door position. The conductor runs through the knuckle, so an electric lock, mag hold-open, or monitored exit device stays powered through the full swing, and there are no exposed wires or exposed electrical parts once it is mortised in.
7) Is this hinge heavy enough for a high-traffic commercial opening?
It is a heavy duty, full mortise, five knuckle ball bearing hinge in brass/bronze, built for commercial service. That is the right class for high-cycle openings like hospital corridors, school entries, and multi-tenant lobbies. For a lighter interior door, a standard weight electrified hinge such as the Design Hardware ETW2-BB5 in 4.5 x 4.5 is the medium duty option.
8) What comes in the box with the BEST electrified hinge?
One hinge per box with the concealed conductor, all machine screws, and installation instructions. What is not included: the junction box, the power supply, and the standard hinges for the remaining leaf positions.
9) What else could I use instead of the BEST CEFBB199-66 if I need more conductors?
For more circuits, the Detex EWH8 Series five knuckle electric hinge in 4.5 x 4.5 satin chrome carries 8 wires. If six conductors is enough, the RCI 952 is a 6-conductor ball bearing electrified hinge, and the Securitron EH Double Duty and SDC PTH Series are other power transfer hinge options. Match the leaf size and finish to the rest of the opening before you swap brands.
10) Will the CEFBB199-66 power an electric mortise lock and an access control reader on the same door?
Yes, that is the intended use. Six conductors let you run the electric lock or exit device on one pair and reader or door position signal on the others back to the panel. The hinge itself is a transfer, not a switch, so the locking logic still lives in your power supply and controller.
11) For a light interior office door that does not see heavy traffic, is there a lighter electrified hinge than the BEST CEFBB199-66?
Yes. The Design Hardware ETW2-BB5 is a 4.5 inch by 4.5 inch electrified standard weight ball bearing hinge rated medium duty, in the BB5 series. It matches the 4.5 x 4.5 size of the BEST CEFBB199-66 and uses ball bearings as well, but the BEST unit is specified heavy duty for higher-traffic commercial openings.
12) Our spec calls out a cycle-rated power transfer hinge - does the BEST CEFBB199-66 meet that, or do I need a different part?
If the drawing requires a published cycle count, look at the SDC PTH Series electrified power transfer hinges, which are rated to 800,000 cycles. The BEST CEFBB199-66 is specified as a heavy duty full mortise ball bearing electrified hinge with a 6-wire concealed conductor and square corners, and is chosen on construction and conductor count rather than a cycle figure.
13) Is the Securitron EH a drop-in substitute for the BEST CEFBB199-66?
Not automatically. The Securitron EH is a double duty electric hinge in the EH series and serves the same purpose of passing current through the door, but the BEST CEFBB199-66 is a full mortise five knuckle ball bearing hinge in 4.5 inch by 4.5 inch with a 6-wire concealed conductor and square corners. Confirm the existing door and frame prep matches the 4.5 x 4.5 square corner mortise cutout and that your conductor count is six before treating them as interchangeable.
14) Is the pin removable for servicing, or is it security pinned?
The CEFBB199-66 uses a permanent fast pin, so the pin is not meant to be pulled. Combined with the concealed conductor it means the hinge cannot be separated or tapped from the hinge side, which is why it gets specified on out-swinging secured doors.
15) I need the electrified hinge to match satin chrome hardware already on the building - which options come in that finish?
The BEST CEFBB199-66 is offered in 626 satin chrome in 4.5 inch by 4.5 inch. The Detex EWH8 is also a 4.5 inch by 4.5 inch electric hinge supplied with a satin chrome finish, so either will sit consistently alongside 626 lever and exit hardware; the Detex unit carries 8 wires versus six on the BEST hinge.
