Straps 1-Hole X 3/4 EMT Conduit Stp (Box 100)
Additional Notes
- Other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Country Of Origin:
- United States
- Division:
- Electrical H1
- Language Code:
- EN
- Number Of Holes:
- 1
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- CT
- Pack Type:
- Box
- Product Group:
- Hardware
- Product Height:
- 3.25 in
- Product Length:
- 7.25 in
- Product Weight:
- 5 lbs
- Product Width:
- 6.75 in
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Straps and Clips
- Product Type:
- One Hole EMT Pipe Strap
- Type2:
- One Hole EMT Pipe Strap
- Product Finish:
- Zinc
- Product Details:
- One Hole EMT Pipe Strap
- Product Material:
- Steel
Metallics 75EOS – Frequently Asked Questions
1) How many 3/4 inch EMT straps come in a box of Metallics 75EOS, and is there an order minimum?
They ship as a box of 100 straps, and 100 count is the order minimum. So one purchase unit equals one box of 100 pieces, not a single strap. The packed box weighs 5 lbs.
2) Are Metallics 75EOS EMT straps made in the USA and Buy American compliant?
Country of origin is the United States, and the 75EOS is flagged compliant for both Buy American and ARRA requirements. That matters on federal, state, and institutional jobs where the spec requires domestic material for conduit supports.
3) Do Metallics 75EOS straps come with screws or anchors?
No fasteners are included. The 75EOS is the strap only, with a single mounting hole, so you supply the screw or anchor suited to the substrate: wood screws into studs and joists, self-drilling screws into metal studs, or a masonry anchor into concrete and block. Order fasteners separately when you order the box of 100.
4) Is the 75EOS conduit strap one-hole or two-hole, and does that matter for my run?
It is a one-hole strap, so it takes a single fastener through the tab. One-hole straps are the common choice for securing EMT flat to wood studs, joists, or masonry on general branch-circuit work. If you need the conduit held off the surface or want two points of fastening for heavier mechanical support, a two-hole strap or a standoff strap is the better call.
5) What material and finish are the Metallics 75EOS straps, and can they go in a damp location?
Steel with a zinc finish. Zinc-plated steel straps are standard for dry and damp indoor work such as mechanical rooms, parking structures, and exposed interior runs. For direct outdoor exposure, corrosive, or wash-down areas, a stainless or PVC-coated strap holds up better than zinc plating.
6) What size carton do the 100-count Metallics 75EOS straps ship in?
The packed box measures 7.25 x 6.75 x 3.25 inches and weighs 5 lbs. That is useful if you are stocking a shop shelf, a service van bin, or an MRO crib and need to know how much room 100 straps take up.
