Strongarm Diamond Tip GSA Core Drill Bit 1/4 x 6, Aero Space Lubricant Provided with Each Drill

Diamond Tip GSA Core Drill Bits: The cost effective and easy way to drill GSA carbide matrix hard plate, relsom, maxalloy, etc. Additional aero space lubricant provided with each drill.

The Strongarm Diamond Tip GSA Core Drill Bit ($1/4" \times 6"$) is a specialized high-performance tool engineered specifically for safe technicians and government security professionals. This bit is the industry standard for penetrating the carbide matrix hardplates commonly found in GSA-rated containers and high-security safes.

Product Overview

Designed for precision and durability, the Strongarm Diamond Core bit features a tip electroplated with industrial diamonds. Unlike standard carbide bits that may chatter or fail against matrix plates, this core bit "cores" through the hardplate, allowing for the subsequent removal of the metal core using matching core cutter hole saws. Every bit includes a sample of Aerospace Lubricant to ensure cool operation and efficient debris removal.

Features

  • Diamond Electroplated Tip: Specifically engineered to cut through GSA carbide matrix, Relsom, and Maxalloy hardplates.

  • Coring Action: Creates a clean circular path rather than grinding the entire surface, which reduces heat and increases drilling speed.

  • Included Aerospace Lubricant: Each drill bit comes with a specialized lubricant that washes away abrasive debris and prevents the diamond tip from overheating.

  • Efficient Debris Removal: The hollow core design works in tandem with the lubricant to flush out unwanted material during the cutting process.

  • Technical Compatibility: Designed to be followed by the Strongarm SA02-A1 core cutter to finish the opening through the mild steel casing.

Specifications

  • Part Number: SA02-A (also referenced as #DC4).

  • Bit Diameter: $1/4"$.

  • Total Length: $6"$.

  • Tip Material: Electroplated Diamond.

  • Application: Carbide Matrix Hardplates, GSA Containers, Safes.

  • Lubricant Type: Aerospace Grade (provided with each bit).

  • Recommended Speed: Constant, steady pressure in rotary mode (not for use with hammer drills).

Manufacturer Resources

Product Specs

Product Type:
Access Control
Product Group:
Lubricants
Product Subgroup:
Locksmith Equipment
Pin Point Size:
.25oz
Application:
Locksmith Equipment
Department:
Tools

StrongArm Drill Bits SADDC4 – Frequently Asked Questions

1) Will a diamond core bit actually get through GSA carbide matrix hardplate?
That is exactly what the Strongarm Diamond Tip GSA core drill bit is built for. The tip is electroplated with industrial diamond and cuts carbide matrix, Relsom and Maxalloy hardplate. Standard carbide bits tend to chatter or fail on matrix plate because they try to grind the whole face; this one cores a circular path instead, which cuts heat and speeds the drill.
2) Can I run this diamond core bit in a hammer drill?
No. Run it in rotary mode only, with constant steady pressure. Hammer action will destroy an electroplated diamond tip. Keep the aerospace lubricant flowing while you cut so the tip stays cool and the swarf clears.
3) What do I need after the core bit to finish the hole through the safe body?
The core bit only gets you through the hardplate. Strongarm specifies the SA02-A1 core cutter to follow it and finish the opening through the mild steel casing, and a matching core cutter hole saw to remove the metal core the bit leaves behind. Order the cutter with the bit if you are working a GSA container start to finish.
4) What size is the Strongarm GSA core drill bit, and will it fit a standard drill chuck?
It is a 1/4 inch diameter bit, 6 inches overall. A 1/4 inch shank drops into any common 3/8 or 1/2 inch chuck, and the 6 inch length gives reach for drill rig work on a container door.
5) Is the lubricant included or do I have to buy it separately?
Aerospace grade lubricant ships with every bit, in a .25 oz pin point size. It washes abrasive debris out of the cut and keeps the diamond tip from overheating. For a heavy production day you will want a larger supply on hand, since the included amount is a working sample.
6) Why use a hollow core bit instead of drilling the hardplate solid?
Coring removes only a narrow ring of material rather than the full circle, so there is far less metal to cut, less heat built up, and a faster penetration on matrix plate. The hollow body also works with the lubricant to flush abrasive debris up and out of the hole while you cut. You then pull the remaining slug with a matching core cutter hole saw.
