Panduit EV10-8RB-Q StrongHold, EV10-8RB-Q Ring Terminal, Yellow, Vinyl, 3/20" Stud, 12-10 AWG, PK25

Panduit StrongHold Ring Terminal Yellow Vinyl Insulated 12-10 AWG #8 Stud Funnel Entry

(No reviews yet) Write a Review

Model: EV10-8RB-Q
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.56
$20.57
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit StrongHold Ring Terminal Yellow Vinyl Insulated 12-10 AWG #8 Stud Funnel Entry

Professional electrical connections with reliable vinyl insulation

Panduit StrongHold Ring Terminal delivers secure electrical connections for 12-10 AWG conductors with yellow vinyl insulation and #8 stud compatibility. Featuring tin-plated copper construction and funnel entry barrel design, this terminal provides reliable performance for professional electrical installations with UL Listed and CSA Certified quality assurance.

Professional Features & Benefits

  • 12-10 AWG Wire Range: Accommodates standard copper conductors from 12 to 10 AWG for versatile wiring applications
  • #8 Stud Compatibility: Designed for secure connection to #8 studs with precise 4.1mm hole sizing
  • Tin-Plated Copper Construction: Provides excellent conductivity and corrosion resistance for long-term reliability
  • Funnel Entry Barrel: Simplifies wire insertion and ensures proper conductor positioning during installation
  • 600V Maximum Rating: Suitable for standard electrical systems with operating temperatures up to 105�C
  • UL Listed & CSA Certified: Meets UL 587H and CSA LR31212 standards for professional electrical applications
  • Yellow Color Coding: Provides clear visual identification for 12-10 AWG wire size range

Technical Specifications

  • Arra Compliant: Y
  • Barrel Length In: 0.45
  • Barrel Length Mm: 11.3
  • Barrel Type: Funnel Entry
  • Base Material: Copper
  • Color Code: Yellow
  • Country Of Origin: Mexico
  • Ean: 74983281831
  • Finish Coating: Tin-Plated
  • Flammability Rating: UL587-H
  • For Use With: CT-100A, CT-200, CT-600-A (CT-570CH) CT-1570, CT-1701, CT-2500(CT-2570CH), CT-160, CT-260
  • Gtin Carton: 5.0075E+13
  • Gtin Package: 74983281831
  • Hazardous Material Flag: N
  • Insulation Diameter In: 0.23
  • Insulation Diameter Mm: 5.8
  • Insulation Material: Vinyl
  • Maximum Copper Conductor Size Awg: 10
  • Maximum Copper Conductor Size Awg Sol: 10
  • Maximum Copper Conductor Size Awg Str: 10
  • Maximum Metric Conductor Size Mm: 6
  • Maximum Operating Temperature C: 105
  • Maximum Operating Temperature F: 221
  • Maximum Voltage Kv: 0.6
  • Maximum Voltage V: 600
  • Maximum Wire Insulation Diameter In: 0.23
  • Maximum Wire Insulation Diameter Mm: 5.8
  • Maximum Wire Size Awg: 10
  • Mercury Content Indicator: N
  • Min Order Qty: 250
  • Minimum Copper Conductor Size Awg: 12
  • Minimum Copper Conductor Size Awg Sol: 12
  • Minimum Copper Conductor Size Awg Str: 12
  • Minimum Metric Conductor Size Mm: 1.5
  • Minimum Operating Temperature C: 105
  • Minimum Operating Temperature F: 221
  • Minimum Wire Insulation Diameter In: 0.17
  • Minimum Wire Insulation Diameter Mm: 4.3
  • Minimum Wire Size Awg: 12
  • Outer Diameter In: 0.31
  • Outer Diameter Mm: 7.9
  • Overall Length In: 1.05
  • Overall Length Mm: 26.7
  • Overall Width In: 0.31
  • Overall Width Mm: 7.9
  • Packaging Type: Bag
  • Pallet Quantity: 0
  • Pallet Volume: 0
  • Pallet Weight: 0
  • Product Segment: IEI
  • Product Type: Ring Terminal
  • Reach Status: N
  • Rohs Compliant: Compliant
  • Seam Type: Butted
  • Standard Carton Volume Ft3: 0.1031
  • Standard Carton Weight Pounds: 0.5
  • Standard Package Volume Ft3: 0.0103
  • Standard Package Weight Pounds: 0.05
  • Std Carton Height In: 4.4
  • Std Carton Height Mm: 111.76
  • Std Carton Length In: 9.15
  • Std Carton Length Mm: 232.41
  • Std Carton Width In: 4.4
  • Std Carton Width Mm: 111.76
  • Std Ctn Qty: 250
  • Std Package Height In: 0.8
  • Std Package Height Mm: 20.32
  • Std Package Length In: 4.55
  • Std Package Length Mm: 115.57
  • Std Package Width In: 2.1
  • Std Package Width Mm: 53.34
  • Std Pkg Qty: 25
  • Std Pkg Uom: Piece
  • Stud Hole Size In: #8
  • Stud Hole Size Mm: 4.1
  • Stud Size: #8
  • Tongue Length In: 0.53
  • Tongue Length Mm: 13.3
  • Tongue Thickness In: 0.04
  • Tongue Thickness Mm: 1
  • Tongue Width In: 0.31
  • Tongue Width Mm: 7.9
  • Wire Strip Length In: 16-May
  • Wire Strip Length Mm: 7.9

Installation & Operation

  1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
  2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
  3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
  4. Configure any available load management or control features as supported by the provided specifications.
  5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
  6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

  • Electrical Panel Connections
  • Control Circuit Wiring
  • Motor Terminal Connections
  • Equipment Grounding Applications
  • Industrial Control Systems
  • Commercial Electrical Installations
  • Maintenance and Repair Operations

Why Choose Panduit Quality?

Panduit StrongHold terminals deliver professional-grade reliability with UL Listed and CSA Certified quality assurance. The tin-plated copper construction and vinyl insulation provide long-term durability in demanding electrical environments, backed by comprehensive technical specifications and RoHS compliance for modern electrical installations.
