Progress Lighting P3192-09 Three-Light Brushed Nickel Bath Bracket

The P3192-09 Trinity bath bracket measures 24 inches long by 8.125 inches high, projecting 7.375 inches from the wall. That 24-inch width sits well over a 30-inch or wider vanity top and lines up flush with a 24-inch cabinet. The 7-3/8 inch projection is the number to watch in a tight powder room or next to a swinging door.

Either way. The fixture is built to mount shades up or shades down, so one part number covers both looks. Mounted down it throws light onto the counter; mounted up it bounces light off the ceiling for softer fill at the mirror.

It is UL/cUL Listed for damp locations and rated indoor only, so bathroom steam is fine. Do not use it in a wet location such as directly inside a shower spray zone or anywhere outdoors.

A mounting strap for the outlet box is included along with installation instructions, and the fixture arrives prewired with 6 inches of lead wire. It hardwires to a standard 120 V branch circuit on a wall-mounted box. At 10.4 lb it is noted as not exceeding NEC fixture weight limits, so a standard listed wall box with a strap will carry it.

Height to center on the P3192-09 is 5.875 inches, measured from the mounting point to the fixture center. Use that to set your box height relative to the mirror or backsplash, and remember the figure flips meaning depending on whether you hang the shades up or down.

No. The P3192-09 is not Energy Star certified, is not JA8 compliant, and is not Title 24 compliant, because it is a socketed fixture rather than an integrated LED. It does comply with Title 20. If your jurisdiction enforces Title 24 high-efficacy lighting in bathrooms, you will need a JA8-listed integrated LED fixture instead.

Yes, fully dimmable, but the dimming comes from the bulbs. The fixture has no driver of its own, so you need dimmable lamps in all three sockets and a dimmer matched to the lamp technology you choose.

The housing is a plated brushed nickel, cataloged generically as grey/nickel, paired with etched glass shades. It is a transitional and traditional styling, so it reads consistently with standard brushed nickel faucets and towel bars. For a property manager standardizing across units, ordering the same P3192-09 part number is the only way to guarantee identical finish across openings.

No, it is not ADA compliant. With a 7.375 inch projection from the wall it exceeds the 4 inch protrusion limit ADA allows for objects mounted in that height range, so for a public restroom corridor or anywhere protrusion limits apply, specify a shallower sconce.

Yes. A Proposition 65 warning is required for the P3192-09, and Proposition 65 is the certification agency flagged on the product record. If you are shipping into California or specifying for a public project, plan on that warning accompanying the fixture.

Sold each, one unit per carton, with an order multiple of 1. Carton size is 10.43 x 24.21 x 9.25 inches at 10.4 lb gross. There is no case pack to break, so a 40-unit rehab order is simply 40 individual cartons.
