Topaz Lighting 1141-1142 Schedule 40 PVC Conduit Body with Junction Box

Topaz Lighting 1141-1142 Schedule 40 PVC Conduit Body with Junction Box

(No reviews yet) Write a Review

Model: 1145

In Stock (leaves warehouse same day if ordered before 3pm ET)

$0.71
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Topaz Lighting 1141-1142 Schedule 40 PVC Conduit Body with Junction Box

Topaz Lighting's Schedule 40 PVC Conduit Bodies with Junction Box are available in C and LB type configurations across trade sizes from 1/2" through 4", giving installers flexible options for splicing, pulling wire, and changing direction within a conduit run. Molded from lightweight, noncorrosive, and nonconductive Schedule 40 PVC, these conduit bodies resist the corrosion that can compromise metallic fittings while remaining easy to handle and install. Each unit ships with a removable cover secured by zinc-plated screws for dependable access, and the family is UL Approved for use across commercial, industrial, and residential electrical systems.

Key Features

  • Trade Size Range: Offered in 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", and 4" to fit a wide range of conduit system requirements.
  • C and LB Type Configurations: C type bodies support straight-through wire pulling and splicing, while LB type bodies permit 90° back turns for changing conduit direction.
  • Durable Schedule 40 PVC Construction: Lightweight, noncorrosive, and nonconductive PVC material delivers reliable performance in demanding environments.
  • Junction Box Integration: Integrated junction box design provides easy access for splicing and wire management within the conduit system.
  • Removable Cover: Cover is easily removable and secured with zinc-plated screws for convenient access during installation and maintenance.
  • Easy Installation: Lightweight PVC construction enables fast, straightforward installation even in tight or small areas.
  • Zinc-Plated Hardware: Cover screws are zinc-plated for added corrosion resistance and secure retention.

Certifications & Compliance

  • UL Approved

Technical Specifications

  • Conduit Type: PVC Schedule 40
  • Angle: 90°
  • Product Material: PVC
  • Pack Size: 100

Typical Applications

  • Commercial and Industrial Conduit Raceway Systems
  • Direction Changes and 90° Back Turns in PVC Conduit Runs (LB Type)
  • Wire Splicing and Junction Access Points
  • Installations Requiring Noncorrosive, Nonconductive Fittings
  • New Construction and Renovation Electrical Projects
  • Indoor and Outdoor PVC Conduit Systems

Why Topaz Lighting?

Topaz Lighting's Schedule 40 PVC Conduit Bodies with Junction Box are engineered from lightweight, noncorrosive, nonconductive PVC and finished with zinc-plated cover hardware for long-lasting field performance. UL Approved and available across C and LB configurations in sizes from 1/2" to 4", this family delivers code-compliant reliability for professional electrical installations, whether the job calls for straight-through wire access or a 90° direction change. Backed by Topaz Lighting's electrical fitting expertise, these conduit bodies are built for fast, dependable use in the field.

Product Specs

Conduit Type:
PVC Schedule 40
Angle:
90°
Listing:
UL Listed
Department:
Electrical
Product Group:
Conduit & Raceway
Product Subgroup:
Conduit Bodies & Fittings
Product Material:
PVC
Product Type:
Conduit Body
Pack size (unit):
100
Product Size:
1/2" - 4"
Configuration:
Schedule 40

Topaz Lighting 1145 – Frequently Asked Questions

1) What is the difference between the LB and C type Topaz Schedule 40 PVC conduit bodies?
Type is the first thing to settle. The LB body turns the run 90 degrees, so it takes conduit coming along a wall and turns it back through the wall (or around a corner) with a pull point at the elbow. The C body is a straight-through pull body, same line in and out, used purely to get hands on the wire in a long run. If you need a direction change, order LB. If the run is straight and you just need a pull or splice point, order C.
2) What trade sizes do the Topaz PVC LB and C conduit bodies come in?
The LB bodies run 1/2 inch (1141), 3/4 inch (1142), 1 inch (1143), 1-1/4 inch (1144) and 1-1/2 inch (1145). The C bodies cover a wider spread: 1/2 inch (1181), 1 inch (1183), 1-1/4 inch (1184), 2 inch (1186), 2-1/2 inch (1187), 3 inch (1188) and 4 inch (1190). So if you are running 2 inch or larger PVC and need a body, the C is what exists in that size.
3) Can I use a PVC conduit body as my equipment ground path?
No. PVC is nonconductive, so the body carries no bonding continuity at all. Any circuit run in this raceway needs a separate equipment grounding conductor pulled through with the circuit conductors. If you were counting on a metal fitting and metal raceway to serve as the ground, switching to PVC changes what you pull.
4) Are Topaz PVC conduit bodies UL approved for a job that requires listed fittings?
They are UL approved, which is what an inspector or a spec calling for listed conduit fittings is looking for on a PVC raceway system. That covers both the LB and C bodies across the size range.
5) Can I use a PVC conduit body outdoors or in a corrosive area like a wash-down or coastal site?
That is the main reason to pick PVC over a metal body. The material is noncorrosive and nonconductive, so it holds up where a die cast or malleable iron body would rust out, and the description lists indoor and outdoor PVC conduit systems as intended use. Note that the cover screws are zinc plated steel, so on a heavy chemical exposure that hardware is the wear point to watch.
6) Do these PVC conduit bodies come with a cover, or do I order that separately?
The cover is part of the unit. Each body ships with a removable cover held on by zinc plated screws, so nothing else has to be ordered to close it up after you pull or splice. What is not included is the solvent cement and the conduit itself.
7) Do I have to buy Topaz conduit bodies by the case, or can I get one?
The standard pack is 100 pieces. For a contractor stocking a truck or a distributor filling a raceway package that is the buying unit to plan around, not a single fitting.
8) Can I splice wires inside a Topaz LB conduit body?
Yes, that is what the integrated junction box design is for. Pull the cover and you have access for splicing and wire management right at the fitting, which is the difference between this and a plain elbow that only redirects the run. Like any junction point, it has to stay accessible after the walls close up.
