Topaz Lighting 572MHDG Malleable Iron Conduit Body Cover, Hot-Dip Galvanized

Topaz Lighting 572MHDG Malleable Iron Conduit Body Cover, Hot-Dip Galvanized

(No reviews yet) Write a Review

Model: 572MHDG

In Stock (leaves warehouse same day if ordered before 3pm ET)

$631.96
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Topaz Lighting 572MHDG Malleable Iron Conduit Body Cover, Hot-Dip Galvanized

The Topaz Lighting 572MHDG Malleable Iron Conduit Body Cover is engineered for dependable performance in demanding electrical raceway systems, available in 3/4", 1", and 2" sizes to fit Rigid Type LR conduit bodies. Constructed from malleable iron and finished with Topaz's proprietary Hot Dip Galvanizing process, the cover delivers superior corrosion protection for harsh weather conditions. An integral gasket creates a raintight seal, making it suitable for both indoor and outdoor installations. This cover is UL 514B listed and NEMA FB1 compliant for code-required electrical work.

Key Features

  • Trade Size: Available in 3/4", 1", and 2" to fit a range of Rigid Type LR conduit body applications.
  • Durable Construction: Malleable iron body provides exceptional strength and impact resistance for long-term reliability in commercial and industrial environments.
  • Hot-Dip Galvanized Finish: Topaz's Hot Dip Galvanizing process conforms to ASTM A123/123M finish thickness standards, delivering superior corrosion protection that withstands harsh weather and moisture exposure.
  • Raintight Performance: Integral gasket creates a raintight seal when used with Rigid Type LR Conduit Bodies, protecting wiring connections from moisture ingress.
  • Galvanized Steel Cover Screws: Included cover screws are galvanized steel for added resilience and ease of installation, maintaining the corrosion-resistant integrity of the assembly.
  • Code-Compliant Design: UL 514B listed, NEMA FB1 compliant, and meets Federal Specification A-A-50563 for confidence in code-required installations.

Certifications & Compliance

  • UL 514B Listed
  • NEMA FB1 Compliant
  • Meets Federal Specification A-A-50563
  • Finish Thickness Conforms to ASTM A123/123M
  • Suitable for Raintight (Outdoor/Wet Location) Use

Technical Specifications

  • Conduit Type: Rigid/IMC
  • Pack Size: 100

Typical Applications

  • Rigid Type LR Conduit Body Cover Replacement or New Installation
  • Commercial and Industrial Electrical Raceway Systems
  • Outdoor and Wet-Location Conduit Installations
  • Exposed Conduit Systems Requiring Raintight Protection
  • New Construction and Renovation Electrical Projects
  • Harsh-Environment and Corrosive-Atmosphere Installations

Why Topaz Lighting?

Topaz Lighting's conduit body covers are manufactured from malleable iron and finished with a proprietary Hot Dip Galvanizing process that conforms to ASTM A123/123M, ensuring consistent coating thickness and long-term corrosion resistance. Each cover is UL 514B listed and NEMA FB1 compliant, giving electrical professionals the assurance of code-compliant performance in the most demanding environments. With galvanized steel cover screws and an integral raintight gasket included across the 3/4" to 2" size range, Topaz delivers a complete, reliable solution for protecting conduit body connections.

Product Specs

Product Type:
Conduit Body Cover
Conduit Type:
Rigid/IMC
Listing:
UL 514B Listed
Department:
Electrical
Product Group:
Conduit & Raceway
Product Subgroup:
Conduit Bodies & Fittings
Product Material:
Malleable Iron
Product Color:
Hot-Dip Galvanized
Pack size (unit):
100
Product Finish:
Hot-Dip Galvanized
Product Size:
3/4" - 2"
Standards:
NEMA FB1

Topaz Lighting 572MHDG – Frequently Asked Questions

1) Will the Topaz 572MHDG cover fit any conduit body, or only Type LR?
It is built for Rigid Type LR conduit bodies. The integral gasket seats against an LR body to make the raintight seal, and the cover is sized to LR openings in 3/4 inch, 1 inch and 2 inch trade sizes. If you are covering an LB, LL, T or C body, this is the wrong cover.
2) Can this conduit body cover be used outdoors in a wet location?
Yes. The cover has an integral gasket that makes a raintight seal when installed on a Rigid Type LR body, and the hot-dip galvanized malleable iron holds up to weather and moisture. It is listed for indoor and outdoor use, which covers exposed rooftop, exterior wall and yard raceway runs.
3) Do I need to buy a separate gasket and screws with the Topaz 572MHDG cover?
No. The gasket is integral to the cover and galvanized steel cover screws are included, so nothing else is needed to close up the LR body. Using galvanized screws keeps the whole assembly corrosion resistant instead of putting plain steel fasteners into a hot-dip galvanized cover.
4) Does this Topaz cover meet spec for a code-required commercial electrical job?
It is UL 514B listed, NEMA FB1 compliant, and meets Federal Specification A-A-50563. The hot-dip galvanized finish thickness conforms to ASTM A123/A123M. That set is what most commercial and government raceway specs call out for a rigid conduit body cover.
5) Can I replace a cracked or missing cover on an existing LR conduit body with this one?
That is one of its main uses. As long as the existing body is a Rigid Type LR in 3/4, 1 or 2 inch trade size, this malleable iron cover drops on with its own gasket and screws and restores the raintight seal. Check the body itself for corrosion while you have it open, since a pitted body will not seal against a new gasket.
6) What trade sizes does the Topaz MHDG malleable iron LR cover come in?
Three: 3/4 inch (572MHDG), 1 inch (573MHDG) and 2 inch (576MHDG). There is no 1-1/4, 1-1/2 or larger-than-2-inch option in this group, so match the trade size of the body already on the run.
7) Is hot-dip galvanized worth it over a standard zinc-plated conduit body cover?
On anything exposed, yes. Hot-dip galvanizing lays down a heavier coating than electroplated zinc, and Topaz's process conforms to ASTM A123/A123M for finish thickness, which is what specs reference for coastal, corrosive-atmosphere and outdoor work. For a dry indoor run inside a conditioned building, a zinc-plated cover does the same job for less coating.
8) Can I use this cover on IMC conduit bodies as well as rigid?
The cover is specified for Rigid/IMC systems, so an LR body on an intermediate metal conduit run takes the same cover as one on rigid. Trade size still has to match: 3/4, 1 or 2 inch.
9) How many Topaz MHDG conduit body covers come in a pack?
They are packed 100 to a carton. That works for a contractor stocking a truck or an MRO storeroom standardizing one cover across a facility, but it is worth knowing before you order a single replacement cover for one damaged LR body.
10) Why malleable iron instead of a stamped steel or aluminum conduit body cover?
Malleable iron takes impact without cracking, which matters on exposed industrial runs, loading docks and equipment yards where a cover gets hit. It also matches the material of standard rigid iron conduit bodies, so you are not mixing dissimilar metals at a gasketed joint in a wet location.
