Topaz Lighting Weatherproof Double Gang Box

Topaz Lighting Weatherproof Double Gang Box, 3-Hole Die-Cast Aluminum with Powder Coat Finish

The Topaz Lighting Weatherproof Double Gang Box is a commercial-grade electrical enclosure engineered for demanding indoor and outdoor installations. Constructed from die-cast aluminum with a premium powder coat finish, this 3-hole double gang box delivers exceptional strength and resilience across a wide range of applications. With a 31 cubic inch capacity and threaded hub sizes available in 1/2", 3/4", and 1", this box accommodates multiple conduit configurations and is available in gray, bronze, and white finishes. UL Listed and NEMA 3R compliant, it meets the requirements of the 2011 NEC for reliable, code-compliant performance.

Key Features

• Generous Box Capacity: 31 cubic inch interior volume accommodates multiple wiring configurations in single and double gang weatherproof applications.
• Threaded Hub Sizes: Available with threaded hubs in 1/2", 3/4", and 1" trade sizes to suit a variety of conduit system requirements.
• Die-Cast Aluminum Construction: Superior commercial-grade die-cast aluminum body provides outstanding strength, corrosion resistance, and long-term durability.
• Premium Powder Coat Finish: Factory-applied powder coat finish enhances resilience against weathering, UV exposure, and mechanical wear.
• 3-Hole Double Gang Configuration: Three-hole layout on a double gang footprint supports multiple device and conduit entry combinations for versatile installations.
• Complete Hardware Included: Ships with closure plugs, mounting lugs, and grounding screws for fast and easy installation right out of the box.
• Color Options: Available in gray, bronze, and white to match architectural and project requirements.
• NEMA 3R Weatherproof Rating: Rated NEMA 3R for protection against rain, sleet, and external ice formation in outdoor and wet-location environments.

Certifications & Compliance

• UL Listed
• NEMA 3R Raintight / Weatherproof
• 2011 NEC Compliant
• Suitable for Outdoor and Wet Locations

Technical Specifications

• Spec Sheet: https://media.distributordatasolutions.com/topaz/2021q3/documents/5d8688b695a445d715b43d2b18fedc9ced7da4de.pdf

Typical Applications

• Outdoor Weatherproof Electrical Installations
• Commercial and Industrial Conduit Raceway Systems
• Exterior Receptacle and Switch Enclosures
• Wet and Damp Location Wiring Applications
• New Construction and Renovation Projects Requiring NEMA 3R Protection
• Multi-Gang Device Mounting in Exposed Conduit Systems

Why Topaz Lighting?

Topaz Lighting's weatherproof electrical fittings are built to commercial-grade standards, combining die-cast aluminum construction with a premium powder coat finish for lasting strength and resilience in the field. Every double gang box ships complete with closure plugs, mounting lugs, and grounding screws, ensuring electricians have everything needed for a fast, code-compliant installation. With UL Listing, NEMA 3R compliance, and 2011 NEC conformance, Topaz Lighting weatherproof boxes are a trusted choice for professional electrical contractors.
