Product Specs
- Country Of Origin:
- India (IN)
- Insulation Material:
- No
- Material Of Conductor:
- Copper
- Product Group:
- Grounding & Bonding
- Product Net Depth Length:
- 3-7/16 in
- Product Type:
- Ground Clamp
- Selling Unit Of Measure:
- each
- Standards:
- UL E3060, CSA 12798
- Type2:
- Grounding devices or assemblies
- Department:
- Electrical
- Product Subgroup:
- Ground Clamps
Blackburn GUV13825 – Frequently Asked Questions
1) Is the Blackburn GUV13825 ground clamp UL listed for grounding electrode connections?
The GUV13825 U-bolt ground clamp carries UL E3060 and CSA 12798 listings. That is the pair of listings an inspector looks for on a grounding connector, so it can go into a permitted commercial or institutional job without a substitution request.
2) Is the Blackburn GUV13825 clamp body copper or steel?
Copper is the conductor material on the GUV13825. That matters on a ground electrode connection because a copper clamp on a copper conductor avoids the dissimilar-metal corrosion you get pairing copper wire with a steel or zinc body in a damp vault or a direct-buried application.
3) How big a pipe or rod will the GUV13825 U bolt ground clamp go around?
The published dimension on the GUV13825 is a 3-7/16 inch net depth/length, which is the working span of the U-bolt assembly. Measure the outside diameter of your pipe or ground rod, not the nominal trade size, and check it against that figure before ordering a quantity for a run of services.
4) Is a U bolt ground clamp the right choice, or should I use a pipe clamp or exothermic weld?
A U-bolt clamp like the GUV13825 is the mechanical, removable option: it bolts a copper conductor to a rod or pipe and can be loosened later for testing or replacement, which is why maintenance and MRO crews standardize on them. An exothermic weld is permanent and typically used on direct-buried grid work where nothing will be serviced. Pick the U-bolt where the connection stays accessible.
5) Is the Blackburn GUV13825 an insulated ground clamp?
No insulation on this one. The GUV13825 is a bare copper U-bolt clamp, which is normal for a grounding electrode or bonding connection where the metallic path is the point. If your spec calls for an insulated or coated connector, this is not that part.
6) What is the manufacturer part number for the Blackburn U bolt grounding clamp?
Order it as Blackburn GUV13825. That is the manufacturer part number, and the clamp is made in India. Distributors cross-referencing a bid should quote against that number rather than a generic U-bolt clamp description.
