Von Duprin 609DT Dummy Pull Trim for 55 Series Exit Devices, Non-Handed Heavy Duty Grade 1

Von Duprin 609DT Dummy Pull Trim for 55 Series Exit Devices, Non-Handed Heavy Duty Grade 1

(No reviews yet) Write a Review

Model: 609DT 26D
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$543.00
$397.04
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Von Duprin 609DT Dummy Pull Trim for 55 Series Exit Devices, Non-Handed Heavy Duty Grade 1

Professional Narrow Stile Exit Device Trim for Commercial and Historical Applications

The Von Duprin 609DT Dummy Pull Trim is a Heavy Duty, Grade 1 exit device trim designed specifically for compatibility with Von Duprin 55 Series Exit Devices. Featuring a non-handed configuration and a projection of 2 5/8" x 1 7/8", this trim integrates seamlessly with the 55 Series narrow stile platform, which is ideal for retro-inspired architecture and historical buildings. The 609DT provides a clean, classic aesthetic while delivering the robust construction and flexible design that Von Duprin products are engineered to offer.

Professional Features & Benefits

  • Dummy Pull Trim Function: Provides a non-operable pull trim function for use on the inactive leaf or non-latching side, delivering a finished appearance without mechanical operation.
  • Non-Handed Design: The non-handed configuration eliminates handing concerns during specification and installation, simplifying ordering and reducing inventory requirements.
  • Product Projection: Trim projects at 2 5/8" x 1 7/8", providing a proportional, professional profile suited to narrow stile door applications.
  • Heavy Duty Grade 1 Construction: Rated at Grade 1 Heavy Duty, this trim meets the demands of high-traffic commercial environments where long-term durability is essential.
  • 55 Series Compatibility: Engineered exclusively for Von Duprin 55 Series Exit Devices, ensuring precise fit and reliable performance across surface-mounted vertical rod and rim applications.
  • Narrow Stile Platform: Designed for the 55 Series narrow stile device, making it well-suited for retro-inspired and historical building applications where a classic look is required.
  • Flexible Field Sizing: The 55 Series platform supports flexible field sizing, allowing trim to be adapted to a variety of door configurations and installation requirements.
  • Universal Center Case Architecture: The underlying 55 Series universal center case design allows users to change or upgrade features as security needs evolve, protecting long-term investment value.

Technical Specifications

  • Subcategory: Exit Device Trim
  • Series: 55 Exit Trim
  • Grade: Grade 1
  • Duty Level: Heavy Duty
  • Compatibilty: 55 Series Exit Devices
  • Product Group: Exit Devices and Trim
  • Product Subgroup: Exit Device Trim
  • Product Type: Exit Device Trim
  • Commercial/Residential: Commercial
  • Product Model: 609DT
  • Product Function: Dummy Pull Trim
  • Door Hand Direction: Non-Handed
  • Product Projection: 2 5/8" x 1 7/8"
  • Product Category: Exit Devices and Trim
  • Department: Door Hardware

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Historical and Retro-Inspired Architecture
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Von Duprin Quality?

Von Duprin exit device trim products are engineered with robust materials and unique construction to deliver long-term value and reliability in demanding commercial applications. The 609DT carries a Grade 1 Heavy Duty rating, reflecting its suitability for high-traffic environments where consistent performance is non-negotiable. Backed by Von Duprin's commitment to industry-leading expertise and support, this trim is a trusted choice for architects, specifiers, and installers seeking professional-grade door hardware solutions.

Manufacturer Resources

Von Duprin 55 Series Catalog

Product Specs

Subcategory:
Exit Device Trim
Series:
55 Exit Trim
Grade:
Grade 1
Duty Level:
Heavy Duty
Compatibility:
55 Series Exit Devices
Product Group:
Exit Devices and Trim
Product Subgroup:
Exit Device Trim
Product Type:
Exit Device Trims
Commercial/Residential:
Commercial
Product Model:
609DT
Product Function:
Dummy Pull Trim
Door Hand Direction:
Non-Handed
Product Projection:
2 5 /8" x 1 7 /8"
Product Category:
Exit Devices and Trim
Department:
Door Hardware

Von Duprin 609DT 26D – Frequently Asked Questions

1) Does the Von Duprin 609DT trim unlock the exit device from outside?
No. The 609DT is a dummy pull trim, so it is non-operable. It gives you something to grab and a finished look on the outside face, but it will not retract a latch and takes no cylinder. If you need key access from the pull side, you want a nightlatch or keyed lever trim instead, not the 609DT.
2) I need a pull trim on the inactive leaf of a pair of doors. Is this the right part?
That is the case the 609DT is made for. A dummy pull gives the inactive leaf or the non-latching side a matching grab point with no mechanical operation behind it, so nothing needs to be prepped for a cylinder or a latch retraction linkage. The active leaf still gets whatever operating trim the opening calls for.
3) What is the closest equivalent to the Von Duprin 609DT dummy pull trim from another manufacturer?
The 609DT is a non-operable dummy pull trim for Von Duprin 55 Series exit devices. The closest functional match from another brand is the Dexter ED1500T-DUMM-PULL, a dummy function exit device trim with a handle pull plate built for the ED1500 Series. Detex also offers the 02BN, a dummy trim, though it uses an S-lever with a blank escutcheon rather than a pull. All three give a finished exterior with no mechanical operation; the difference is the device platform each is cut for and whether you want a pull or a lever on the outside.
4) I need the outside trim to retract the latch with a key, not just be a dummy pull. What should I order instead of the 609DT?
The 609DT is a dummy pull only - it is non-operable and will not retract a latch. For key-retract exterior operation, look at nightlatch trims: the Sargent 704ET is a Grade 1 heavy duty night latch lever trim with field reversible operation for 700 Series devices, the Sargent 704-ETL is the night latch lever for PE Series, and the Corbin Russwin VT957ET-LC is a nightlatch escutcheon trim in stamped or formed stainless for ED5000 Series devices. Accentra's 121NL is also a nightlatch exit device trim. Match the trim to the exit device family already on the door.
5) Is a nightlatch pull trim the same thing as the 609DT dummy pull?
No. They look similar from the outside but operate differently. The 609DT is a dummy pull with no mechanical operation and no cylinder. A nightlatch pull such as the Dexter ED1500T-PULL-NC uses a raised lip pull plate with nightlatch function, the Tell EDPT pull trim has a cylinder hole and ships less cylinder, and the Design Hardware 2P-03NL-32D is a Grade 1 pull trim with a cylinder hole for 1000R and 2000R devices. If the opening needs keyed re-entry, the dummy pull is the wrong part.
6) We want the outside to always be locked but keyable for staff. Is the 609DT suitable?
No - the 609DT is a dummy pull with no key function at all. For a locked exterior that staff can key, storeroom function trims are the right call: the Design Hardware KIL storeroom trim uses a Schlage C keyway with a flat lever for 1000 and 2000 Series devices, the Tell EDELT80 is a storeroom function escutcheon lever trim, the Marks USA M195F is a storeroom lever and rose trim with spring loaded roses for M9900 touchbar devices, and the Pamex E9000 is a Grade 1 storeroom L3 lever trim fitting 1-3/8 inch to 2 inch doors.
7) Do I have to order the 609DT trim left or right hand?
No handing to specify. The 609DT is non-handed, so one part number covers both leaves, which is useful if you are stocking spares for a building with doors swinging both ways.
8) How far does the 609DT pull stick out from the door face?
Projection is listed at 2-5/8 x 1-7/8 inches. That is worth checking against anything close to the door: an adjacent leaf in a pair, a return wall, a gate, or a door that swings past a jamb detail. It is a proportionally small profile intended for narrow stile aluminum doors.
9) Is the 609DT heavy duty enough for a school or hospital entrance?
It carries a Grade 1 Heavy Duty rating, which is the commercial-duty tier used on high traffic openings. It is specified as a commercial product, and pull trim on a school, healthcare or office entry is exactly the application. Keep in mind it is a pull only, so the security function stays with the exit device itself.
10) Is there a version of this trim that takes a cylinder so a key can pull the latch back?
Not in the 609DT itself, which is dummy only. For keyed access on an exit device you would move to a nightlatch or keyed pull trim, such as the Tell exit device pull trim with cylinder hole (less cylinder) or the Dexter ED1500 nightlatch trim with raised lip pull plate. Note those are trims for their own device families, so match the trim to the device in the door.
11) Can I use a lever trim in place of the Von Duprin 609DT pull?
Only if the door does not need a fixed pull. The 609DT is a non-handed dummy pull with a 2 5/8 inch by 1 7/8 inch projection. If a lever is preferred and the outside should be free-turning or non-locking, the Arrow SRX01 is a passage function Sierra lever trim with rose for ED910, S1150 and S1250 devices, and the Corbin Russwin 3310AET is a passage function trim for ED3000 Series rim, surface vertical rod and mortise devices. Both give lever operation rather than a static pull, and both are tied to their own device series.
12) The 609DT is Grade 1 heavy duty. Which other exit trims carry the same rating?
The 609DT is rated Grade 1 heavy duty for high traffic commercial use. Peers carrying a Grade 1 rating include the Sargent 704ET and 704-ETL, both Grade 1 heavy duty night latch lever trims, the Sargent 744 freewheeling Grade 1 trim for 8700 and 8900 Series devices, the Pamex E9000 Grade 1 storeroom lever trim, the Dexter ED1500T Grade 1 lever trim, and Design Hardware's KIL entry and storeroom trims. Falcon's 510L is listed heavy duty, while the Falcon 179L and 212L are medium duty.
13) I need a thumbpiece instead of a pull on the outside of the exit door. What are my options?
The 609DT is a pull style dummy trim, so it has no thumbpiece. For thumbpiece operation, the Tell EDTHP53 is a thumbpiece exit device trim with keyed entry function, and the Dexter ED1000T-CLRM-TP-NC is a Grade 1 classroom function trim combining a thumbpiece with a pull plate and cylinder, supplied less cylinder. Both give a lift-to-operate exterior instead of the fixed pull.
14) What is the difference between the 609DT and an entrance function lever trim like the Delaney 500L?
The 609DT is a non-handed dummy pull that does not operate the device - it is there for appearance and grip on a leaf that is not latched from outside. The Delaney 500L is an entrance function exterior lever trim, offered in CT, MD and SD lever styles, meaning it actively operates the device from the outside when unlocked. Choose the dummy pull for inactive leaves and exit-only doors, and an entrance function trim where the outside must let people in.
15) What finishes can I get the 609DT pull trim in?
Nine finishes: 605 bright brass, 606 satin brass, 612 satin bronze, 613 oil rubbed bronze, 622 matte black, 625 bright chrome, 626 satin chrome, 643E aged bronze, and 693/SPBLK black painted. The bronze and black options are the usual picks when matching older or retro-styled storefront hardware.
16) Why would a historical building renovation specify the Von Duprin 55 Series and this trim?
The 55 Series is Von Duprin's narrow stile platform aimed at retro-inspired and historical architecture, with a universal center case that lets features be changed or upgraded later and field sizing flexibility for varied door widths. The 609DT dummy pull carries that classic look onto the pull side of the door without adding key function, which is often what a restoration spec wants on a secondary leaf.
17) Can the 609DT be used on a fire rated opening?
Fire rating on exit trim follows the exit device and the opening assembly, not the pull itself. Worth noting when comparing: the Accentra 121NL, 426F, 441F and 446F exit device trims are all listed as not fire rated. For a fire rated opening, confirm the listing of the exit device and frame assembly before selecting any exterior trim, including the 609DT.
