Product Specs
- Body Material:
- FRPP
- Connection Type:
- No Hub
- Fitting Name:
- 45 Degree Wye
- Series:
- 45 Wyes Blueline FRPP NH
- Wall Thickness:
- 0.22 IN
- Department:
- Plumbing
- Product Group:
- Plumbing
- Product Subgroup:
- Valves
- Product Type:
- General Valve
- Pipe Size Dimension:
- 3 IN
Watts 710205 – Frequently Asked Questions
1) Will the Watts 710205 wye connect to 3 inch no-hub cast iron drainage pipe?
The 710205 is a 3 inch no-hub fitting, so the ends are plain spigots sized for 3 inch no-hub couplings, the same shielded band-and-gasket couplings used on cast iron soil pipe. It joins to any 3 inch no-hub pipe or fitting that a standard 3 inch coupling will clamp, whether that is the Blueline polypropylene line or cast iron. The coupling itself is a separate item and is not supplied with the fitting.
2) Is the Watts 710205 wye plastic or metal, and what does FRPP mean for a lab waste line?
Body material is FRPP, flame retardant polypropylene, not metal. That is the reason this fitting shows up on laboratory and industrial acid waste systems: polypropylene takes the aggressive drainage that would attack cast iron, and the flame retardant grade is what specifiers call for on above-ground runs. If your drawing calls for cast iron or a coated metal DWV fitting, this is not a substitute.
3) Can I solvent weld or mechanically fuse this Watts Blueline wye?
No. The 710205 is the no-hub version, so it is joined mechanically with couplings, not fused. Polypropylene does not solvent weld, and Blueline FRPP systems that are joined permanently use the electrofusion or mechanical-joint fitting versions instead. If your system is fused, order the fusion-end wye rather than this no-hub one.
4) What is the exact part number to order for the Watts 3 inch 45 degree no-hub Blueline wye?
Order Watts 710205. It is the 3 inch, 45 degree wye in the 45 Wyes Blueline FRPP NH series, no-hub ends. Adjacent part numbers in that series cover the other pipe sizes, so confirm the size on the drawing before substituting a neighbouring number.
5) Is the branch on this 3 inch wye also 3 inch, or is it reduced?
Both the run and the branch are 3 inch. The listed pipe size for the 710205 is 3 IN with no reducing designation, so it is a straight 3 x 3 x 3 wye. For a smaller branch coming into a 3 inch main you need a reducing wye, a different part number in the same Blueline series.
6) What wall thickness does the 3 inch Blueline no-hub wye have?
Wall thickness is 0.22 inch. That matters when you are checking a submittal against a spec that calls out a minimum wall for FRPP drainage fittings, and it is also why the fitting can be joined with standard no-hub couplings without a stiffener insert on the plastic side.
