ABB XT5N 400 Molded Case Circuit Breaker, 3-Pole

ABB XT5N 400 Molded Case Circuit Breaker, 3-Pole

(No reviews yet) Write a Review

Model: XT5NU330AEFF000XXX

In Stock (leaves warehouse same day if ordered before 3pm ET)

$12,593.30
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ABB XT5N 400 Molded Case Circuit Breaker, 3-Pole

The ABB XT5N 400 is a fixed, three-pole molded case circuit breaker from the Tmax XT5N platform, built to UL/CSA requirements with front terminals for straightforward panel and switchboard wiring. It integrates a solid-state Ekip Dip LS/I R electronic release factory-configured at 300, delivering long-time and short-time/instantaneous overcurrent protection for demanding commercial and industrial power distribution systems. Supplied 1 each, this breaker is engineered for dependable, code-compliant circuit protection.

Key Features

  • Frame Rating: XT5N 400 frame circuit breaker platform for mid-range commercial and industrial feeder and branch circuit protection.
  • Configuration: Fixed, three-pole (3P) design with front terminals for simplified panel and switchboard installation.
  • Solid-State Trip Release: Ekip Dip LS/I R electronic release factory-set at 300, providing long-time (L) and short-time/instantaneous (S/I) overcurrent protection functions.
  • Compliance: Manufactured to UL/CSA requirements for use in North American electrical distribution systems.
  • Packaging: Supplied 1 each for straightforward stocking and installation planning.

Certifications & Compliance

  • UL/CSA Compliant Molded Case Circuit Breaker

Technical Specifications

  • Country of Origin: UKN

Typical Applications

  • Commercial and Industrial Power Distribution
  • Panelboard and Switchboard Circuit Protection
  • Feeder and Branch Circuit Overcurrent Protection
  • New Construction and Electrical System Upgrades

Why ABB?

ABB's Tmax XT5N series pairs a robust fixed three-pole molded case design with solid-state Ekip Dip electronic trip technology, giving electrical professionals precise, adjustable overcurrent protection backed by UL/CSA compliance. It's a dependable choice for commercial and industrial power distribution projects that demand code-compliant, long-lasting circuit protection.

Manufacturer Resources

Spec Sheet

Product Specs

Product Type:
Circuit Breaker
Series:
XT5N
Configuration:
3-Pole
Amperage Rating:
400A
Standards:
UL/CSA
Department:
Electrical
Product Group:
Wiring Devices
Product Subgroup:
Circuit Breakers

ABB XT5NU330AEFF000XXX – Frequently Asked Questions

1) What is the amperage rating of the ABB XT5N 400 three-pole breaker, and what is the trip unit set at?
The XT5N 400 is a 400A frame breaker in a fixed three-pole configuration. The Ekip Dip LS/I R solid-state electronic release ships factory-configured at 300, so the protection setting out of the box sits below the frame rating. The trip unit is adjustable, which is the point of the Ekip Dip release: you set the long-time and short-time/instantaneous pickups to the feeder you are actually protecting rather than swapping the breaker.
2) Does the Ekip Dip LS/I R trip unit include ground fault protection?
No. The LS/I R release on the XT5N 400 covers long-time (L) and short-time/instantaneous (S/I) functions only. If your drawing calls for ground fault protection at this breaker, an LS/I trip unit will not satisfy it and you need a release that carries the G function.
3) Is the ABB XT5N 400 a plug-in or draw-out breaker, and how does it terminate?
It is a fixed-mount breaker, not plug-in or draw-out, and it comes with front terminals. That means it lands in the panel or switchboard with conductors brought to the front of the case. If your gear is built around a draw-out cassette or rear-connected studs, this version will not drop into it.
4) Can I use a DIN rail miniature circuit breaker instead of the ABB XT5N 400?
No - they solve different problems. The XT5N 400 is a 400A three-pole molded case breaker for feeder and branch protection in panelboards and switchboards. The Square D C60 UL489 is a miniature circuit breaker that mounts on DIN rail, the format used for control panels and small branch circuits. An MCB will not carry a 400A feeder, and the XT5N does not mount on DIN rail - it lands on front terminals in a panel or switchboard.
5) What is the closest alternative to the ABB XT5N 400 if I need a molded case breaker with a thermal magnetic trip instead of electronic?
The ABB XT5N 400 uses a solid-state Ekip Dip LS/I R electronic release, which gives you adjustable long-time and short-time/instantaneous settings. If the application calls for a fixed thermal magnetic trip instead, the Square D PowerPacT B is a molded case breaker with a thermal magnetic trip unit. The tradeoff is adjustability: the Ekip Dip release lets you dial in coordination settings, while a thermal magnetic unit protects on its built-in curve.
6) I need a three-pole breaker for an I-Line panelboard - will the ABB XT5N 400 fit?
The XT5N 400 is a fixed-mount breaker with front terminals, wired into a panel or switchboard rather than plugged onto an I-Line bus. For an I-Line bus connection, the Square D PowerPacT Q is the I-Line style breaker. Choose by how the breaker lands: front-terminal fixed mounting for the XT5N 400, I-Line bus stab for the PowerPacT Q.
7) What are the alternatives to the ABB XT5N 400 if I want a thermal magnetic breaker instead of electronic trip?
The XT5N 400 carries a solid-state Ekip Dip release rather than a thermal magnetic trip. If you want a conventional thermal magnetic molded case breaker, the Square D PowerPacT B is that style. For I-Line style gear, Square D PowerPacT Q is the I-Line mounting family. Note the mounting difference: the ABB is a fixed front-terminal unit, so it is not an I-Line bus-stab replacement.
8) What part number do I order for the ABB XT5N 400 3-pole breaker with the Ekip Dip trip unit?
The catalog number is XT5NU330AEFF000XXX, ABB Tmax XT5N platform, 400A frame, three-pole, fixed, front terminals, Ekip Dip LS/I R release. It is supplied one each, so quantity ordered equals breakers received.
9) What should I use for a single-pole 120V control or lighting circuit instead of the ABB XT5N 400?
The XT5N 400 is a 3-pole 400A device sized for feeders, not for a single 120V branch. For a single-pole 120V AC circuit, the Square D Multi9 C60 1-pole C-curve miniature breaker is built for that duty; the C curve suits general lighting and mixed loads with modest inrush. Keep the XT5N 400 for the three-phase feeder ahead of those branches.
10) Is the Square D C60 UL489 a substitute for the ABB XT5N 400 in a switchboard?
It is not. Both are UL 489 listed overcurrent devices, so they can look interchangeable on a submittal line, but the C60 UL489 is a DIN rail mount miniature breaker and the XT5N 400 is a 400A three-pole molded case breaker with front terminals for panelboard and switchboard wiring. Frame size, mounting method, and current rating all differ - swapping one for the other will not match the enclosure prep or the feeder ampacity.
11) Can the ABB XT5N 400 be used as a service main as well as a feeder breaker?
The XT5N 400 is applied for feeder and branch circuit overcurrent protection in commercial and industrial distribution, including new construction and system upgrades. Whether it can serve as a service disconnect depends on how your gear is listed and labeled, so that call comes off the switchboard listing rather than the breaker alone.
12) Where can I get the full technical data for the ABB XT5N 400 breaker for submittal?
ABB publishes a spec sheet for the XT5N 400 covering the Tmax XT5N platform data, and it is linked in the product specifications as a PDF. That document is what to attach for submittals when an engineer wants interrupting ratings and dimensional data on record.
