Accentra D222 Double Cylinder Grade 2 Deadbolt with 2-3/4" Backset

Commercial-Grade Security Solution

The Accentra D222 Double Cylinder Grade 2 Deadbolt delivers reliable commercial security with a 1" throw solid steel deadbolt and 2-3/4" backset configuration. This ANSI/BHMA Grade 2 certified deadbolt features field reversible operation for doors ranging from 1-3/8" to 1-3/4" thickness, making it ideal for diverse commercial applications requiring consistent quality and ease of installation.

Professional Features & Benefits

  • ANSI/BHMA Certified Grade 1 or 2, depending on model
  • Available with visual occupancy indicators, displaying "In Use" or "Vacant" that displays current status of the deadbolt
  • Indicators are provided as standard on both sides of the door for the D291 and D292 functions
  • 1" throw solid steel deadbolt with hardened, free spinning steel pin insert
  • Non-handed functions are easily field reversible
  • 2-3/4" backset
  • Several SFIC functions feature concealed interior screws that only the control key can access

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and/or frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Accentra Quality?

Accentra D Series deadbolts deliver professional-grade reliability with solid steel construction and hardened pin insert technology rated for ANSI/BHMA Grade 2 performance. The 1 Year Mechanical warranty provides added confidence for commercial installations. Engineered for demanding commercial applications where dependable security performance is essential.

Product Specs

Series:
D Series
Grade:
Grade 2
Warranty:
1 Year Mechanical
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Deadbolts
Subcategory:
Deadbolts
Latch Throw:
1" (deadbolt)
Commercial/Residential:
Commercial
Lock Type:
Cylindrical
Lock Function:
Deadbolt
Product Attribute:
Deadbolts
Standard Strike:
2-3/4" x 1-1/8" (70mm x 29mm)
Keyed Function:
Single Cylinder
Product Function:
Double Cylinder
Door Hand Direction:
Field Reversible
Door Thickness Range:
1-3/8" to 1-3/4"
Product Category:
Mechanical Locks
Backset (Distance):
2-3/4"
Department:
Door Hardware

Accentra D222 626 – Frequently Asked Questions

1) Will the Accentra D222 deadbolt fit a 1-3/8 inch door, or does it need a 1-3/4 inch door?
Both. The D222 covers a door thickness range of 1-3/8 inches to 1-3/4 inches, so it works on older interior doors at 1-3/8 as well as standard commercial doors at 1-3/4. The bolt itself is bored for a 2-3/4 inch backset, so the cross bore has to sit 2-3/4 inches back from the door edge, not the 2-3/8 common on residential prep.
2) Will the Accentra D222 bolt land in my existing strike, or do I have to re-mortise the frame?
The D222 throws a 1 inch solid steel bolt into a standard 2-3/4 by 1-1/8 inch (70mm x 29mm) strike. If the frame already carries a strike of that size at the right height, the bolt drops straight in. A 1 inch throw needs a full 1 inch of pocket depth behind the strike, so on a hollow metal frame confirm the existing pocket is deep enough before you reuse it.
3) What is the difference between a double cylinder deadbolt like the Accentra D222 and a single cylinder with a thumbturn?
The D222 is keyed on both sides, so there is no thumbturn and no way to retract the bolt from inside without a key. That is what you want on a glass front door or a door with a light beside it, where someone could reach through and turn a thumbturn. The tradeoff is egress: with the bolt thrown, anyone inside needs a key to get out, which many jurisdictions restrict on required exit doors. If you need inside thumbturn operation instead, the same family and grade is available as a cylinder x thumbturn deadbolt, and comparable Grade 2 options include the Dexter DB2000 single cylinder and the Deltana CL200LA, which is also a 2-3/4 inch backset Grade 2.
4) What is the closest Grade 2 double cylinder deadbolt to the Accentra D222 from another manufacturer?
The Dexter DB2000 double cylinder deadbolt is the nearest match. It is ANSI/BHMA Grade 2 with a double cylinder function and fits doors 1-3/8 inch to 1-3/4 inch thick, the same door thickness range the D222 covers. Both are keyed on both sides, so neither can be released from inside without a key. The Delaney LU Series 320601 is another Grade 2 double cylinder deadbolt, supplied in a stainless steel US32D finish, where the D222 comes in eight finishes including 626 satin chrome and 613E dark oxidized satin bronze.
5) I need a heavier deadbolt than a Grade 2 for a high-traffic entry - what double cylinder options step up?
Two double cylinder deadbolts carry a Grade 1 rating. The Design Hardware D1 Series double cylinder deadbolt is Grade 1, rated extra heavy duty, and is built for 1-3/4 inch doors only. The Dexter DB1000 double cylinder deadbolt is also Grade 1 and covers 1-3/8 inch to 1-7/8 inch thickness, so it spans a wider door range than the D1. The Accentra D222 is Grade 2 with a 1 inch solid steel throw and fits 1-3/8 inch to 1-3/4 inch doors.
6) Egress code will not allow a key on the inside - what do I use instead of the D222?
Switch to a cylinder by thumbturn deadbolt, which keys the outside and turns free from the inside. In the same Grade 2 class, the Dexter DB2000 single cylinder deadbolt covers 1-3/8 inch to 1-3/4 inch doors, and the Hager 3215 is a Grade 2 single cylinder deadbolt with a 1 inch throw over the same thickness range and a fire rating. The Cal-Royal CB160 is a Grade 2 cylinder by thumbturn deadbolt with a tamper-resistant cylinder guard. The Accentra D222 is keyed on both sides, which is what the code objection is to.
7) Which double cylinder deadbolt should I use on a door thicker than 1-3/4 inch?
The Accentra D222 is built for 1-3/8 inch to 1-3/4 inch doors. For a thicker leaf, the Deltana 7312KA2 double cylinder deadbolt is Grade 3 and covers 1-3/8 inch to 2 inch. The Corbin Russwin DL3011 cylindrical deadlock is Grade 1 and rated for 1-3/4 inch to 2-1/4 inch doors, though it is a cylinder by blank plate function rather than keyed both sides. The Dexter DB1000 double cylinder reaches 1-7/8 inch at Grade 1.
8) The opening needs a fire rated deadbolt - which one carries the rating?
The Hager 3214 is a Grade 2 double cylinder deadbolt with a Schlage C keyway, carries a fire rating, and fits 1-3/8 inch to 1-3/4 inch doors - the same function and thickness range as the Accentra D222. If a turn on the inside is acceptable, the Hager 3215 single cylinder is Grade 2 and fire rated over the same range, and the Cal-Royal CRB800 is a Grade 1 heavy duty cylinder by thumbturn deadbolt with a UL 3-hour fire rated latch.
9) Do I have to specify handing when I order an Accentra D222 deadbolt?
No handing to specify. The D222 is field reversible, so the same part goes on a left hand or right hand door and you set it at install. That matters if you are stocking spares for a building: one part number covers every opening regardless of swing.
10) Is the Accentra D222 deadbolt strong enough for a commercial building, or is it a residential lock?
It is built for commercial use and carries ANSI/BHMA Grade 2. Grade 2 is the standard commercial duty tier, above the Grade 3 residential level and below Grade 1 heavy duty. For a high traffic or high abuse opening, step up to a Grade 1 double cylinder such as the Design Hardware D1 Series or the Dexter DB1000 double cylinder.
11) Is the Accentra D222 a mortise deadbolt or a bored one?
Bored, cylindrical type. It drops into a standard cross bore and edge bore rather than a routed mortise pocket, which is why it installs faster on an existing door. If your frames are prepped for a mortise case instead, that is a different animal, and options there include the Dormakaba D900 small case mortise deadbolt or the Emtek 2050 European mortise deadbolt with integrated roller latch.
12) Can I add an Accentra D222 deadbolt above an existing lockset to upgrade security on an apartment door?
Yes, that is a common use. The D222 is a standalone bored deadbolt, not part of a lockset, so it installs in its own bore above the existing knob or lever and adds a 1 inch solid steel bolt. Two things to confirm: the door has to be 1-3/8 to 1-3/4 inches thick, and the new bore has to be at 2-3/4 inch backset. Because it is keyed both sides, think about egress before putting it on a dwelling unit entry door.
13) The doors have different backset prep - is there a deadbolt that adjusts instead of a fixed 2-3/4 inch?
The Accentra D222 is a fixed 2-3/4 inch backset with a 2-3/4 inch by 1-1/8 inch strike. For mixed prep, the Cal-Royal ED500 is a Grade 3 deadbolt with an adjustable backset covering 1-3/8 inch to 1-3/4 inch doors, and the Falcon D111 is a Grade 1 classroom deadbolt with an adjustable backset. The Brinks Raleigh E2401 offers a 4-way adjustable backset in a single cylinder round trim. All three are keyed one side with a turn rather than keyed both sides.
14) Is the Callan 210S a drop-in alternative to the Accentra D222?
The Callan 210S matches on function - it is a double cylinder deadbolt, keyed both sides like the D222. It differs on certification: the 210S is ANSI/BHMA Grade 3, where the D222 is Grade 2 with a 1 inch solid steel throw. On a spec calling out Grade 2, the Dexter DB2000 double cylinder or the Delaney LU Series 320601, both Grade 2 double cylinder deadbolts, hold the rating.
15) Which single cylinder deadbolt matches the D222 backset for standardizing across a building?
The Deltana CL200LA is a Grade 2 single cylinder deadbolt on a 2-3/4 inch backset, the same backset as the Accentra D222, so both hit the same bore location in the door. The CL200LAIC is the same bolt prepped for an interchangeable core. Where a facility mixes keyed-both-sides and keyed-outside openings, running the D222 for the double cylinder doors and the CL200LA for the thumbturn doors keeps the prep consistent.
16) What is the difference between the Accentra D222 and the Falcon D211?
Both are Grade 2 deadbolts in a 200-level D series. The Falcon D211 is a classroom function with single cylinder operation, rated medium duty - keyed outside with a turn inside. The Accentra D222 is a double cylinder, keyed from both sides, with a 1 inch solid steel throw on a 2-3/4 inch backset and field reversible operation. If the requirement is a Grade 1 classroom deadbolt instead, the Falcon D111 is heavy duty with an adjustable backset.
17) Will a Baldwin Reserve double cylinder deadbolt work as a substitute for the D222?
The Baldwin Reserve double cylinder deadbolt comes in a contemporary round and a contemporary square trim and matches the D222 on function - keyed from both sides. The Emtek 8323 Modern Disc is another brass double cylinder deadbolt. These are decorative-trim products; the Accentra D222 is an ANSI/BHMA Grade 2 commercial deadbolt with a 1 inch solid steel throw and a hardened free spinning pin insert, on a 2-3/4 inch backset. For a commercial opening where the grade is called out, stay with a Grade 2 double cylinder such as the Dexter DB2000.
18) I only need a thumbturn on the inside with no keying at all - what replaces the D222?
The Arrow E60 exit deadlock is Grade 2, non-keyed, with a blank plate outside and a thumbturn inside, and fits 1-3/8 inch to 1-3/4 inch doors - the same thickness range the Accentra D222 covers. The Callan 205S is a Grade 3 one-sided half-bore deadbolt for openings where nothing is needed on the outside face at all. The D222 is keyed on both sides, so it takes a cylinder in each face.
19) We want to drop keys and go to a code or credential - what electronic deadbolt replaces the D222?
Several electronic bolts cover the same job without a key on either side. The Codelocks CL2200 is a medium duty electronic surface deadbolt in brushed steel, and the CL2210 is an electronic mortise deadbolt. The Delaney KP400 is a Grade 2 electronic deadbolt with a programmable remote, matching the Accentra D222 Grade 2 rating. For credential-based access, the Dormakaba Saffire LX-D is an RFID electronic deadbolt with BLE and electronic lock override. Note the CL2200 is surface mounted and the CL2210 is mortise, so the door prep differs from the D222 cylindrical bore.
20) What is the equivalent bolt if the door is prepped for a mortise case rather than a cylindrical bore?
The Accentra D222 is a cylindrical deadbolt and needs a bored prep. For a mortise pocket, the Dormakaba D900 small case mortise deadbolt is a cylinder by turn bolt supplied keyed different with SC keyways, and the Emtek 2050 and 2051 are European mortise deadbolts with an integrated roller latch in square and round trim. The International Door Closers DH-1821 is a hook bolt deadlock with a flat faceplate for sliding or high-force openings.
21) What finishes does the Accentra D222 deadbolt come in?
Eight finishes, and they cover both brass-family and chrome-family openings: 605 bright brass, 606 satin brass, 612 satin bronze, 613E dark oxidized satin bronze equivalent, 619 satin nickel, 625 bright chrome, 626 satin chrome, and BSP black suede powder coat. If you are matching existing commercial hardware in a building, 626 satin chrome is the usual standard.
22) Is the Baldwin 8BR0618001 deadbolt spacer an alternative to the D222?
No. The Baldwin Reserve 8BR0618001 is a deadbolt spacer - a part carried under a double cylinder listing to adapt an existing bolt, not a lock in itself. The Accentra D222 is a complete cylindrical double cylinder deadbolt with a 1 inch solid steel throw and a 2-3/4 inch by 1-1/8 inch strike. If a full Baldwin double cylinder bolt is wanted, that is the Reserve contemporary round or square deadbolt, or the Estates 8011 contemporary 1-5/8 inch double cylinder deadbolt.
