Yale Edge Series - Alpharetta ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$36.90
$33.12
Yale Residential Yale Edge Series - Alpharetta Passage Door Lever Set With Round Rose YR11AL

Yale Edge Series - Alpharetta Passage Door Lever Set With Round Rose

(No reviews yet) Write a Review

Model: YR11AL-605
From the Alpharetta Collection
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$36.90
$33.12
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

YALE EDGE YR11AL ALPHARETTA PASSAGE DOOR LEVER SET WITH ROUND ROSE OVERVIEW

Meet Alpharetta Lever from Yale Edge. Yale Edge Stylish hardware that installs with just one tool.

Yale Edge Series offers attractive designs and finishes to meet the needs of today’s housing market. All Yale Edge Series product is constructed to meet Grade 3 standards. Designed to fulfill the needs of the hardware market in attractive styles and current popular finishes. Whether your project includes town homes, condos,garden homes, or a single family home, look no further than Yale Edge Series to fulfill your door hardware needs with the Yale brand.

PASSAGE FUNCTIONS

  • Ideal for closets, hallways or rooms where no locking mechanism is needed
  • Box Contents: 2x levers, 2x rose, interior chasis, strike plate, 4x screws, latch, exterior chasis

FEATURES & BENEFITS

  • Designed to meet Grade 3 standards for value and security
  • Removable cylinder for ease of re-keying without special tools
  • Non-handed levers lowers inventory needs, minimizes mistakes
  • Yale is the world's favorite lock.
  • 1Year finish and 5 year mechanical warranty

DOWNLOADS

Manufacturer Resources

Product Specs

Series:
Yale Edge Series
Collection:
Alpharetta
Warranty:
1 Year Finish / 5 Year Mechanical
Keyed Function:
Non-Keyed
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Leversets
Subcategory:
Residential Door Levers
Keyed:
No
Commercial/Residential:
Residential
Handle Type:
Lever
Lock Function:
Passage
Grade:
Grade 3
Product Attribute:
Cylindrical Locks
Product Function:
Passage/Hall/Closet
Product Design:
Round
Mounting Method:
Surface
Product Category:
Mechanical Locks
Product Substrate:
Metal
Department:
Door Hardware

Yale Residential YR11AL-605 – Frequently Asked Questions

1) Does the Yale Alpharetta passage lever need to be ordered left hand or right hand?
No handing to specify. The Alpharetta levers are non-handed, so the same set works on a left or a right hand door and installs either way. For a property manager buying a dozen at a time, that means one part number covers every opening in the building instead of splitting the order by swing.
2) Is a Grade 3 lever like the Yale Alpharetta strong enough for an apartment building or an office?
Grade 3 is the residential duty level, and the Alpharetta is built to it. For interior closet and hall doors in townhomes, condos, garden homes, and single family, that is the right spec. For a commercial corridor, a school, or anything taking daily public traffic, step up: ZenSupply carries the Falcon K101 passage lever at Grade 1 with a heavy duty rating, and the Corbin Russwin CL3110 passage lever at Grade 1 and vandal resistant. Grade 2 middle ground includes the Hager 2510 and the Falcon B101.
3) Will a Yale Edge Alpharetta lever drop into the existing bore where a knob was?
It is a cylindrical bored lockset with surface-mounted roses, which is the same prep family as a standard residential knob: a bore through the door face and a cross bore for the latch in the edge. Swapping a knob for the Alpharetta lever on a door already prepped for a bored set is normally a straight change of hardware, not a re-prep. Two things to confirm on your door before you order: that the existing latch backset matches, and that the door has enough swing clearance for a lever, which projects further than a knob.
4) What is the closest equivalent to the Yale Edge Alpharetta passage lever from another brand?
The Kwikset 200BRNL RDT Breton passage lever set is the nearest match. Like the Alpharetta, it is a Grade 3 passage lever set with a round rose, and it fits doors 1-3/8 inch to 1-3/4 inch thick. Both are non-keyed passage function, so they serve the same closets, hallways and pass-through doors with no locking mechanism. The Callan Asheville is a second Grade 3 passage leverset option, listed in a satin nickel finish, which lines up with the 619 satin nickel the Alpharetta offers.
5) The Alpharetta passage lever is going on a high-traffic corridor door in an apartment building. Is there a heavier duty passage lever?
Yes. The Alpharetta is built to Grade 3 for residential use. For corridors and other doors that see constant use, the Falcon K101 is a Grade 1 heavy duty passage cylindrical lock with non-handed levers, fire rated, covering doors 1-3/8 inch to 2-1/4 inch thick. The Falcon T101 is another Grade 1 heavy duty passage lever, and the Corbin Russwin CL3110 is a Grade 1 vandal resistant passage lever, fire rated, for doors 1-3/4 inch to 2 inch. In between, the Falcon B101 is a Grade 2 medium duty passage lever, also non-handed like the Alpharetta.
6) I need the same lever look on a bathroom or bedroom door where it has to lock. What do I use instead of the Alpharetta?
The Alpharetta is passage function and non-keyed, so it has no locking mechanism at all. For a bed or bath door, the Kwikset 300BRNL RDT Breton privacy lever set is a Grade 3 privacy lever for doors 1-3/8 inch to 1-3/4 inch. The Hager 2540 is a Grade 2 privacy cylindrical lock with the Withnell lever for doors 1-3/8 inch to 2 inch, and the Baldwin Estate 5103 privacy lever uses the same 5048 rose as the Baldwin 5103 passage version, so a run of doors can carry one trim with mixed functions.
7) The door needs to lock with a key. What replaces the Alpharetta passage lever?
The Alpharetta is non-keyed, so a keyed opening needs a different lock. In Grade 3, the Cal-Royal AUS00 is an entrance/office lever with a solid brass forged body for doors 1-3/8 inch to 1-3/4 inch, and the Callan Artino is a Grade 3 entrance leverset. Stepping up, the Hager 2525 is a Grade 2 commercial entry lever for doors 1-3/8 inch to 2 inch, the Falcon B511CP6D is a Grade 2 medium duty entry/office lever, and the Dexter C1000 entry/office is Grade 1 with clutching for doors 1-3/8 inch to 1-3/4 inch. For a storeroom door that stays locked, the Hager 2580 and the Cal-Royal AG05 are both Grade 2 storeroom levers.
8) Is a dummy lever the same thing as the Alpharetta passage lever?
No, and the difference matters on the door. The Alpharetta passage lever has a working latch, and it ships with a latch and strike plate in the box, so the lever retracts a bolt and holds the door closed. A dummy lever has no latch and no moving mechanism - it is fixed trim for a door held by a ball catch or roller, or for the inactive leaf of a pair. Dummy options include the Callan Bentley Grade 2 dummy lever, the BEST 7KC single dummy trim in Grade 2 medium duty, the BEST 9K 1DT single dummy trim in Grade 1 heavy duty, and the Baldwin Estate 5103 half dummy, which comes in left hand and right hand versions.
9) What finishes does the Yale Edge Alpharetta passage lever come in?
Three finishes: 10BP Oil Rubbed Bronze Permanent, 605 Polished Brass, and 619 Satin Nickel. The 10BP is the permanent-coated bronze rather than a living finish, so it holds its color instead of wearing through at the grip, which matters on a rental turn where every unit has to look the same five years in. If you are matching existing satin chrome or 26D hardware, 619 satin nickel is the closer of the three but it is not the same finish number.
10) What comes in the box with the Yale Edge YR11AL Alpharetta lever set?
Everything for one door: two levers, two roses, the interior chassis, the exterior chassis, the latch, a strike plate, and four screws. The Yale Edge line is built to install with one tool, so you are not chasing extra hardware. What is not in the box is the strike for a metal frame if your frame is already prepped differently, and any wood filler or shims for a worn bore.
11) I need a lever on a closet door that does not latch at all, just a pull. Is the passage Alpharetta the right one?
Not quite. A passage set like the Alpharetta includes a working latch and strike, so the door latches shut and the lever retracts it. If you want trim with no latch at all, on a false door, a closet with a ball catch, or the inactive leaf of a pair, you want a dummy lever. ZenSupply carries the Accentra 455LN Augusta single dummy, the BEST 7KC single dummy trim, the BEST 9K 1DT single dummy trim, and the Emtek Classic Cortina dummy pair.
12) Which passage lever has a square rose instead of the round rose on the Alpharetta?
The Alpharetta uses a round rose. If the job calls for square trim, the Bravura Tampa is a Grade 2 passage leverset with square trim. Staying with round trim, the Bravura Atlanta, the Bravura Orlando and the Bravura Miramar are all Grade 2 round trim passage leversets, with the Miramar listed in US4 satin brass - a close cousin to the 605 polished brass the Alpharetta offers.
13) Will the Alpharetta passage lever work on a 2 inch thick door?
The Alpharetta is a residential Grade 3 lever set. Where the opening is a thicker commercial door, the Arrow GL01 is a Grade 2 passage lever covering 1-3/4 inch to 2 inch, the Hager 2510 Grade 2 passage lever covers 1-3/8 inch to 2 inch, and the Falcon K101 Grade 1 passage lever covers 1-3/8 inch to 2-1/4 inch. The Corbin Russwin CL3110 Grade 1 passage lever is rated 1-3/4 inch to 2 inch.
14) I am standardizing a multi-family property on one passage lever. What are the alternatives to the Alpharetta at similar grade?
The Alpharetta is a Grade 3 non-handed passage lever, which keeps stocking simple because one part serves either swing. Within the same grade, the Kwikset 200BRNL Breton and the Callan Asheville are both Grade 3 passage lever sets, the Breton fitting doors 1-3/8 inch to 1-3/4 inch. If units include heavier commercial-style doors, the Accentra 5301LN Augusta and the Accentra 4601LN are both Grade 2 passage cylindrical lever locks, from the 5300 Series and 4600 Series respectively, and the Design Hardware J75 is a Grade 2 passage lever lockset for 1-3/4 inch doors.
15) Can I put a keypad or code entry lever on the door instead of the Alpharetta passage lever?
Yes, if the door needs controlled access rather than free passage. The Alpharetta is passage function with no locking mechanism, so it cannot be coded. The Lockey 1150 is a heavy duty mechanical keypad lever set with double combination that also offers a passage function, fitting doors 1-1/8 inch to 2 inch. The Delaney LP250 is a Grade 2 electronic keypad leverlock, and Emtek offers a Classic keypad leverset if the trim styling needs to match a decorative program.
16) The door is a classroom or patient room. What goes there instead of the Alpharetta?
Those openings need a keyed function the Alpharetta does not provide. For classrooms, the Dexter C1000 classroom lever is Grade 1 with clutching, keyed, for doors 1-3/8 inch to 1-3/4 inch, and the Dexter C1000 classroom security version adds an inside keyed cylinder in the same range; the Cal-Royal AG03 is a Grade 2 classroom lever with a 6-pin Schlage C keyway keyed different and a 2-3/4 inch backset. For patient rooms and utility spaces, the Dexter C1000 asylum function is Grade 1 for doors 1-3/8 inch to 2 inch, and the Arrow MK33-BD-CS is a Grade 2 heavy duty asylum lock with a ball knob and a Schlage C keyway.
17) Are the Alpharetta lever handles metal or plastic?
Metal. The Alpharetta lever and rose are metal construction, which is the difference that shows up after a few thousand cycles on a closet door in a rental. Plated zinc and steel residential levers like this are fine for interior traffic; if the opening takes commercial abuse you want a Grade 1 lever such as the Falcon T101 or the Design Hardware X75 instead.
18) The building uses knobs, not levers. Is there a knob version of a passage lock like the Alpharetta?
The Alpharetta is a lever handle set. Where an opening calls for a knob instead, the Arrow MK02-TA is a privacy cylindrical lock with a Tudor knob, non-keyed and fire rated, for doors 1-3/4 inch to 2 inch. The Arrow HK11-BB is a turn-pushbutton entrance cylindrical lock with a ball knob and conventional cylinder for doors 1-3/8 inch to 1-3/4 inch. Note that levers are the accessible choice under ADA-driven specs, which is why many multi-family and institutional programs move away from knobs.
19) What is the difference between the Design Hardware J75 and X75 passage levers if I am moving up from the Alpharetta?
Both are flat lever passage locksets for 1-3/4 inch doors, and both cover the same closet and hall function the Alpharetta serves. The J75 is from the J Series and is Grade 2; the X75 is from the X Series and is Grade 1. The Alpharetta itself is Grade 3 with a round rose, so either Design Hardware lever is a step into commercial-grade construction on the same opening type.
20) Is there a decorative passage lever that matches the Alpharetta oil rubbed bronze on a higher-end unit?
The Alpharetta comes in 10BP oil rubbed bronze permanent, along with polished brass and satin nickel. For a more decorative program, the Baldwin Estate 5103 passage lever with the 5048 rose covers the same passage function in a designer line, and the matching 5103 privacy and half dummy versions let one trim run through a whole floor. Emtek's Arts and Crafts and Hammered leversets and the Classic Cortina lever are dummy pairs, so they suit fixed-trim openings rather than latching passage doors.
