Yale Residential Yale Residential YRD642 Assure Lock - Fire Rated Electronic Key Free Touchscreen Keypad Deadbolt YRD642

Yale Residential YRD642 Assure Lock - Fire Rated Electronic Key Free Touchscreen Keypad Deadbolt

(No reviews yet) Write a Review

Model: YRD642-NR-10BP
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$537.00
$478.48
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Yale Residential YRD642 Assure Lock - Fire Rated Electronic Key Free Touchscreen Keypad Deadbolt

Yale Assure Lock provides versatility and convenience for securing your home. The locks can operate as standalone electronic deadbolts or be upgraded with a Z-Wave, Zigbee or Yale Access Module to work with your smart home

Enjoy the convenience of key free locking with this sleek touchscreen deadbolt - Lock and unlock your home without the hassle of keys.

Upgrade your deadbolt with the Assure Lock and enjoy the convenience of unlocking and locking your door using the backlit touchscreen keypad; you'll never have to carry around your keys again. Create unique entry codes for friends and family and remove codes whenever you need to. The lock is Grade 2 certified and backed Yale, the world's favorite lock since 1840. Get a Yale Smart Module to your Assure Lock to add it to your smart home.

FEATURES & BENEFITS

  • Create up to 250 unique entry codes to share with friends and family (25 for Standalone models).
  • Keypads wake with a touch and feature backlit numbers that won’t wear off.
  • Key free model features a 9V battery back-up to prevent lockouts.
  • Available Smart Modules include Z-Wave, Zigbee or Yale Access.
  • When upgraded with a Yale Smart Modules, lock and unlock remotely, view access history and share access rights from your smartphone with most Z-Wave and Zigbee systems or with the Yale
    Access app when using a Yale Access Module.
  • Available with 90 minute fire rating as YRD622/642. Please contact your sales team for more
    information.
  • Limited lifetime finish and mechanical warranty / 1year electronic warranty



  • Lose your keys, for good: Unlock your door using your entry code on the keypad, and leave the bulky keychain behind. For use with your smartphone or smart home system, Yale Access Wi-Fi Kit is required (sold separately).
  • Auto-Lock for peace of mind: You didn’t forget to lock the door, your lock did it for you. Rest easy knowing that your door is locked every time you leave the house and when you go to bed at night.
  • Easy to install on any door: Not so handy? Not a problem. Yale Assure locks are super easy to install and are guaranteed to fit standard doors (doors 1-¾” to 2-¼” thick. Doors under 1-���” require thin door kit).
  • Stop hiding keys: Sharing codes is the new hide-a-key. Give unique codes to friends, family, and other people you trust, and never put a key under the doormat again.
  • Upgrade to Wi-Fi with Yale Access: Use just the keypad for now, and upgrade to a smart lock whenever you’re ready. Our Yale Access Wi-Fi Kit (sold separately) lets you use your phone as your key.
  • Comes with a couple keys, just in case: If you’re not ready to lose your keys for good, two physical keys are included in the box.
  • Modern look for your modern life: Yale Assure locks feature clean lines, a slim profile, and come in a variety of beautiful finishes, including satin nickel, oil rubbed bronze, and black suede, to match any home’s design.
  • Works great in any weather: Yale Assure Locks can withstand temperatures from -22°F to 140°F, and the touchscreen keypad has backlit numbers that won’t wear off and is smartphone glove-friendly.
  • Long battery life: Four (4) AA batteries last an average of 18 months, and a low battery indicator will tell you when it’s time to change them.
  • Trusted every day for over 180 years: Yale locks come with a limited lifetime warranty for finish and mechanical and 24/7 customer support. A brand trusted for generations.

DOWNLOADS

Key-Free Access To Your Home

Unlock By Entering Your Code On The Keypad

When you don't have your phone on you, simply unlock the door using your unique entry code on easy-to-use keypad. Create permanent, scheduled or temporary codes for people you trust.

Automatically Locks Behind You

Never worry about whether or not you remembered to lock the door. The Assure Lock can automatically lock behind you. Optional setting.

Upgrade with Wi-Fi

Upgrade your Yale Assure Lock, with Wi-Fi, anytime by adding the Yale Access Upgrade Kit. Manage your lock from anywhere with the Yale Access app and enjoy added convenience with auto unlock via Bluetooth and voice assistant integration.

Share Access, Not Keys

Create unique codes to share with people you trust, or use your smart home app (like SmartThings) to grant access to others. Delete codes whenever you need to.

Easy To Install

Installs in minutes using just a screwdriver on most standard doors. Step by step installation and programming instructions are available with the free BILT app.

Manufacturer Resources

Product Specs

Series:
Assure Real Living
Edge Bore:
1"
Warranty:
Limited Lifetime Finish and Mechanical
Subcategory:
Electronic Keypad Locks
Cross Bore:
2-1/8"
Product Type:
Deadbolts
Commercial/Residential:
Residential
Electronic:
Yes
Product Group:
Mechanical Locks
Product Subgroup:
Deadbolts
Keyed:
No
Grade:
Grade 2
Product Attribute:
Electronic Locks
Door Thickness Range:
1-3/8" to 1-3/4"
Product Category:
Electronic Locks
Product Substrate:
Metal
Department:
Door Hardware

Yale Residential YRD642-NR-10BP – Frequently Asked Questions

1) Will the Yale YRD642 keypad deadbolt drop into my existing deadbolt prep?
It uses the standard tubular deadbolt prep: a 2-1/8 inch cross bore in the face of the door and a 1 inch edge bore. If your current deadbolt was bored to those dimensions, the Assure Lock goes in without new boring, and installation is a screwdriver job.
2) Does the Yale YRD642 Assure Lock need a key, or is it code-only?
The YRD642 is the key-free version of the Assure touchscreen deadbolt, so there is no keyway or cylinder in it. Entry is by code on the backlit touchscreen. It carries a 9V battery terminal on the exterior so you can jump it and get in if the AA batteries die. If you want a mechanical key override on the same lock, that is the keyed Assure variant, not this one.
3) What do the technology options on the Yale YRD642 mean, and can I add smart home control later?
Four choices: NR (no module, standalone keypad only), ZW2 (Z-Wave Plus), HA2 (Zigbee), and CBA (Yale Access). The standalone version works entirely on its own with entry codes. Adding a module is what gives you remote lock/unlock, access history, and shared access from a phone or a Z-Wave/Zigbee panel. The module is a slot-in upgrade, so you can start standalone and add it whenever you are ready.
4) What is another electronic keypad deadbolt if the Yale YRD642 Assure key free touchscreen deadbolt is not the right fit?
The Delaney KP400 is a Grade 2 electronic deadbolt with a programmable remote, matching the YRD642 Assure on Grade 2 rating while using remote-based operation rather than a touchscreen keypad. For multifamily or hospitality openings, the Dormakaba Nova-D is an RFID multihousing smart electronic deadbolt in the Nova Series, and the Dormakaba Saffire LX-D is an RFID electronic deadbolt with BLE and Electronic Lock Override. The Codelocks CL2200 is a medium duty electronic surface deadbolt in a brushed steel finish, which mounts to the door face instead of a standard 2-1/8 inch cross bore.
5) What mechanical keyed deadbolt can replace a Yale YRD642 Assure touchscreen deadbolt on the same door prep?
The YRD642 Assure is a non-keyed electronic deadbolt sized for a 2-1/8 inch cross bore, 1 inch edge bore, and doors 1-3/8 inch to 1-3/4 inch thick. Mechanical deadbolts sharing that 1-3/8 inch to 1-3/4 inch door thickness range include the Dexter DB2000 single cylinder, a Grade 2 cylinder x thumbturn, and the Hager 3215 single cylinder Grade 2 deadbolt with a 1 inch throw. For a heavier opening, the Accentra D111 is a Grade 1 cylinder x thumbturn deadbolt with a 2-3/8 inch backset covering the same door thickness range.
6) Which deadbolt should I use instead of the Yale YRD642 Assure on a commercial fire door?
The YRD642 Assure is a residential-duty Grade 2 deadbolt. For commercial openings where a fire rating is called out, the Hager 3115 is a Grade 2 cylinder x thumbturn deadbolt with a Schlage C keyway and a fire rating, and the Hager 3118 is a Grade 1 classroom deadbolt with a Schlage C keyway and 6-pin cylinder, also fire rated; both cover 1-3/8 inch to 1-3/4 inch doors. The Cal-Royal CRB800 is a Grade 1 heavy duty single cylinder deadbolt with a UL 3-hour fire rated latch.
7) How many user codes can I program into the Yale Assure keypad deadbolt for a rental unit?
Up to 250 unique entry codes when the lock is running a Smart Module, or 25 codes on the standalone version. Codes can be permanent, scheduled, or temporary, and you can delete any of them, which is what makes it workable for turnover, cleaners, and contractors.
8) Is the Yale YRD642 strong enough for a rental entry door, and what grade is it?
Grade 2, and Yale lists it as a residential product, so it is aimed at homes, apartments, and multi-family entry doors rather than high-traffic commercial openings. If you need a Grade 1 deadbolt on the same door, the Design Hardware D1 Series and the Dexter DB1000 Series are Grade 1 mechanical deadbolts, though neither is electronic.
9) What finishes does the Yale Assure YRD642 come in, and can I match it across a building?
Four finishes across every technology option: Satin Nickel (619), Oil Rubbed Bronze Permanent (10BP), Black Suede Powder Coat (BSP), and Lifetime Brass (P05). Every finish is offered with all four module choices, so you can standardize one finish and still mix standalone units with Z-Wave or Yale Access units in the same building.
10) I want an electronic deadbolt but not a keypad on the outside. What else is there?
The Yale YRD642 is a touchscreen code-entry deadbolt, so the keypad is the whole exterior trim. If you want credential-based access instead of a keypad, the Dormakaba Saffire LX-D is an RFID electronic deadbolt with BLE and electronic lock override, and the Dormakaba Nova-D is an RFID multihousing smart deadbolt. For a hardwired access-control deadbolt tied to a panel rather than a battery lock, the DynaLock 1300 Series is a heavy duty mortise electric deadbolt.
11) Is there a cheaper electronic keypad deadbolt if I do not need smart home integration?
Within electronic deadbolts, the Delaney KP400 is a Grade 2 electronic deadbolt with a programmable remote, and the Codelocks CL2200 is a medium duty electronic surface deadbolt in brushed steel. The Yale YRD642 differs in that it is the key-free touchscreen version and takes a slot-in Z-Wave Plus, Zigbee, or Yale Access module if you later want app or panel control.
12) What is a simpler alternative to the Yale YRD642 Assure keypad deadbolt for a rental unit?
If code-based entry is not required, a keyed mechanical deadbolt covers the same 2-1/8 inch cross bore prep with no batteries or modules. The Arrow DBX61 is a Grade 2 single cylinder deadbolt, cylinder x thumbturn, and the Cal-Royal CB160 is a Grade 2 single cylinder deadbolt with a tamper-resistant cylinder guard. The Cal-Royal ED500 is a Grade 3 single cylinder deadbolt with an adjustable backset for 1-3/8 inch to 1-3/4 inch doors, and the Cal-Royal LSD is a Grade 3 single cylinder deadbolt with an ADA ergonomic thumbturn over the same thickness range.
13) Is the Codelocks CL200 the same kind of lock as the Yale YRD642 Assure deadbolt?
No. The YRD642 Assure is a bored deadbolt that drops into a 2-1/8 inch cross bore with a 1 inch edge bore and runs a backlit touchscreen keypad. The Codelocks CL200 is a light duty surface deadbolt with key override, and the CL2210 is an electronic mortise deadbolt - a mortise pocket prep rather than a bored door. The Codelocks CL160 is a mortise latch with QuickCode function, not a deadbolt body. Confirm the existing door prep before swapping between these.
14) I need a non-keyed deadbolt like the Yale YRD642 Assure but without electronics - what are my options?
The YRD642 Assure is non-keyed and opens by touchscreen code. A purely mechanical non-keyed option is the Arrow E60 Grade 2 exit deadlock, a blank plate by thumbturn function for doors 1-3/8 inch to 1-3/4 inch thick - same door thickness range, with a blank plate outside so there is no outside operation at all. The Callan 205S is a Grade 3 one-sided half-bore deadbolt if the opening only needs inside control.
15) Can I standardize a facility on the Yale YRD642 Assure, or should I look at a Grade 1 deadbolt?
The YRD642 Assure is a residential Grade 2 deadbolt. Where a Grade 1 mechanical deadbolt is specified, the Design Hardware D1 Series is an extra heavy duty Grade 1 double cylinder deadbolt for 1-3/4 inch doors, the Falcon D111 is a Grade 1 classroom deadbolt with adjustable backset, and the Delaney LM Series is a Grade 1 single cylinder less core deadbolt in dull chrome US26D for keying into an existing interchangeable core system.
16) Will the Yale Assure touchscreen deadbolt hold up on an unprotected exterior door in cold weather?
Yale rates the Assure Lock for operation from -22F to 140F, and the touchscreen numbers are backlit rather than printed, so they do not wear off with use. The touchscreen also reads through smartphone-style gloves. Four AA batteries run about 18 months on average, with a low battery indicator.
17) Does the Yale Assure YRD642 lock itself after someone leaves?
Auto-Lock is an optional setting on the Assure Lock, so it can relock on its own after the door closes. Turn it off if you have tenants who prop doors. Note this is a key-free model, so if Auto-Lock engages behind someone without a code, there is no mechanical key to fall back on.
18) What is the closest match to the Yale YRD642 Assure deadbolt for a decorative or designer entry?
The YRD642 Assure comes in satin nickel, oil rubbed bronze, black suede powder coat, and lifetime brass with a slim touchscreen face. If the entry calls for traditional or sculpted trim instead, the Emtek #11 Tuscany is a lost wax cast bronze deadbolt, cylinder x thumbturn, and the Emtek 8323 Modern Disc is a brass double cylinder deadbolt. The Baldwin Reserve contemporary round and square double cylinder deadbolts are further double-cylinder options. All of these are keyed mechanical rather than code entry.
