Yale YH Collection Norwood Passage Door Leverset

Yale YH Collection Norwood Passage Door Leverset

(No reviews yet) Write a Review

Model: YR11NW-626-RH
From the Norwood Collection
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$66.02
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

YALE YH COLLECTION YR11NW NORWOOD PASSAGE LEVER SET WITH ROUND ROSE OVERVIEW

Meet the Norwood Lever from Yale's YH Collection. Solid, stylish hardware with concealed screws install with just one tool.

YH Collection levers offer a range of designs with sculptured roses and delicately crafted curves. The “non-handed” design and strength of the interior sub-assemblies allow for quick and easy installation and years of secure operation. All YH Collection products are ANSI Grade 2 superior light commercial quality.

PASSAGE FUNCTIONS

  • Ideal for bathrooms, bedrooms or rooms where a locking mechanism is needed
  • Box Contents: 2x lever, 2x rose, interior chasis, strike plate, 4x screws, latch, exterior chasis

FEATURES & BENEFITS

  • Exceeds criteria for ANSI/BHMA A156.2 Grade 2 certification
  • Constructed from quality materials with a focus on durability
  • Easy Install Mounting System — Square Spindle Simplifies Installation - Knobs, Levers
  • Pre-Installed Mounting Screws
  • Concealed Mounting Screws — Clean Upgraded Look
  • Provide easy re-keying
  • Reduces wear and provides smooth operation
  • Limited Lifetime Mechanical and Finish Warranty

DOWNLOADS

Manufacturer Resources

Product Specs

Series:
YH Collection
Collection:
Norwood
Features:
Concealed Screws
Edge Bore:
1"
Warranty:
Limited Lifetime Mechanical
Keyed Function:
Non-Keyed
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Leversets
Subcategory:
Residential Door Levers
Cross Bore:
2-1/8"
Keyed:
No
Commercial/Residential:
Residential
Handle Type:
Lever
Lock Function:
Passage
Grade:
Grade 2
Product Attribute:
Cylindrical Locks
Product Function:
Passage/Hall/Closet
Door Thickness Range:
1-3/8" to 1-3/4"
Product Design:
Round
Mounting Method:
Surface
Product Category:
Mechanical Locks
Product Substrate:
Metal
Department:
Door Hardware

Yale Residential YR11NW-626-RH – Frequently Asked Questions

1) Will the Yale Norwood passage lever fit a 1-3/8 inch interior door, or does it need a 1-3/4 inch door?
Both work. The YH Collection Norwood passage leverset covers a 1-3/8 to 1-3/4 inch door thickness range, so it handles older residential interior doors and standard modern ones without a spacer or a different chassis.
2) What bore sizes do I need for the Yale Norwood lever, and will it drop into an existing prep?
Standard prep. The Norwood lever needs a 2-1/8 inch cross bore in the door face and a 1 inch edge bore for the latch. That is the same bore pattern used by nearly every residential cylindrical knob or lever, so on a door already prepped for a bored lockset you are usually just pulling the old set and setting this one in the same holes.
3) Does a passage lever lock? I need something for a bathroom door.
It does not lock. The Norwood is a passage function, non-keyed set: both levers always retract the latch, with no key, no button, and no thumbturn. For a bathroom or bedroom that needs to lock from the inside you want a privacy set instead, such as the Kwikset 300BRNL Breton privacy lever or the Baldwin Estate 5103 privacy lever. Use the Norwood on halls, closets, and pantry doors where you only need a latch to keep the door closed.
4) I have to order left hand and right hand for the Yale Norwood lever. How do I tell which one I need?
Handing is a real choice on this one, and it is ordered per door: every finish in the Norwood line comes in a left hand and a right hand version. Stand on the outside of the door, the side it opens away from. If the hinges are on your left, it is left hand; hinges on the right, right hand. The lever curve has to point back toward the latch edge, which is why the two are not the same part.
5) Is the Yale YH Norwood lever strong enough for an apartment building or a light commercial hallway?
It carries ANSI/BHMA A156.2 Grade 2 certification, which is the light commercial tier, above the Grade 3 residential sets like the Kwikset 200BRNL Breton passage or the Callan Asheville passage lever. Yale positions the YH Collection as residential product built to that light commercial standard. For a heavy traffic corridor, a stairwell, or an institutional opening, step up to a Grade 1 passage set such as the Falcon K101 or the Corbin Russwin CL3110.
6) My doors are 2 inches thick - will the Yale Norwood passage lever fit, and what fits if it does not?
The Norwood YR11NW covers a door thickness range of 1-3/8 to 1-3/4 inches, so a 2 inch door is outside it. Passage levers that reach 2 inches include the Hager 2510 Grade 2 passage lever with the Withnell design at 1-3/8 to 2 inches, the Falcon K101 Grade 1 passage lock at 1-3/8 to 2-1/4 inches, the Arrow GL01 Grade 2 Sierra lever passage lock at 1-3/4 to 2 inches, and the Corbin Russwin CL3110 passage/closet lever at 1-3/4 to 2 inches.
7) What is a straight equivalent to the Yale Norwood YR11NW passage lever from another brand?
The Norwood YR11NW is a Grade 2 non-keyed passage lever on a round rose. The closest like-for-like swaps are the Bravura Atlanta BV333002 and Bravura Orlando BV333602, both Grade 2 passage leversets with round trim, and the Bravura Miramar BV940-106, a Grade 2 passage leverset with round trim in US4 satin brass. If the room wants a square rose instead of round, the Bravura Tampa BV333702 is the same Grade 2 passage function on square trim.
8) The Norwood passage lever is residential Grade 2 - what should I use on a commercial corridor or classroom door instead?
The Norwood YR11NW is a Grade 2 residential lever. For a heavier commercial opening in the same passage function, the Falcon K101 is a Grade 1 heavy duty passage cylindrical lock with non-handed levers, fire rated, covering 1-3/8 to 2-1/4 inch doors; the Falcon T101 is a Grade 1 heavy duty passage lever with pressure release technology; and the Corbin Russwin CL3110 is a Grade 1 vandal resistant passage/closet lever, fire rated, for 1-3/4 to 2 inch doors. Design Hardware X75 is another Grade 1 passage lever lockset for 1-3/4 inch doors.
9) The Norwood passage lever does not lock - what do I order for a bedroom or bathroom that needs privacy?
The Norwood YR11NW is non-keyed passage function, so it latches but does not lock. For a door that needs a privacy lock, the Hager 2540 is a Grade 2 privacy cylindrical lock with the Withnell lever for 1-3/8 to 2 inch doors, the Kwikset 300BRNL Breton privacy lever is Grade 3 for 1-3/8 to 1-3/4 inch doors, and the Baldwin Estate 5103 privacy lever uses the 5048 rose. Ordering the passage version for a bath door is the most common mis-order on this function.
10) What looks like a substitute for the Norwood passage lever but will not work?
Dummy trim is the trap. The Norwood YR11NW is a working passage lever with a latch, while the Accentra 455LN Augusta, BEST 9K 1DT, BEST 7KC 1DT, Callan Bentley BN5051, and Baldwin Estate 5103 half dummy in left hand or right hand are all dummy function - they mount as a pull with no latch and no operating mechanism. On a door that must latch closed, dummy trim leaves the door swinging. The Emtek Arts and Crafts and Cortina dummy pairs are also dummy function and ship as pairs rather than as a latching set.
11) What finishes does the Yale Norwood passage lever come in?
Ten, and they run from traditional to modern: 605 Polished Brass, 609 Antique Brass, 10BP Oil Rubbed Bronze Permanent, 613E Dark Oxidized Satin Bronze, 619 Satin Nickel, 620 Antique Nickel, 625 Polished Chrome, 626 Satin Chrome, BSP Black Suede Powder Coat, and GM Gun Metal. Every one of those is available in both left and right hand, so a property manager standardizing a building can hold one finish across every door regardless of swing.
12) What comes in the box with the Yale Norwood passage leverset, and do I need to buy anything else?
The carton is a complete opening: two levers, two roses, interior and exterior chassis, the latch, the strike plate, and four screws. Mounting screws come pre-installed. You need the door bored 2-1/8 inch face and 1 inch edge, and the frame mortised for the strike; beyond that no separate trim, cylinder, or latch purchase is required.
13) I need matching levers on hall doors and bedroom doors. Can I get the Norwood in other functions?
The Norwood name here is the passage function only, non-keyed. If you need a locking function on the same doors and want to stay in one look across the house, plan the openings by function first: the Baldwin Estate 5103 family runs passage, privacy, and half dummy in a matched lever, and the Accentra 5301LN Augusta covers passage in a Grade 2 cylindrical set. Match the finish code across whatever you pick, since the 605, 619, and 626 numbers are BHMA finish standards and read the same brand to brand.
14) What is the difference between a passage leverset and a dummy lever?
A passage set like the Norwood has a working latch: the lever turns, the latchbolt retracts, and the door stays shut when you let go. A dummy is a fixed pull screwed to the face with no latch and no moving mechanism, used on a closet door held by a ball catch or on the inactive leaf of a pair. If the door needs to stay closed on its own, you need the passage set. If it just needs something to grab, a dummy such as the BEST 7KC single dummy trim or the Callan Bentley dummy lever is the part.
15) Is there a lighter or simpler passage lever than the Yale Norwood for interior hall and closet doors?
The Norwood YR11NW is Grade 2. If a lighter interior lever suits the door, the Kwikset 200BRNL Breton passage lever is Grade 3 for 1-3/8 to 1-3/4 inch doors, and the Callan Asheville AH5011 is a Grade 3 passage leverset in satin nickel. Both are passage function like the Norwood, at Grade 3 rather than Grade 2. The Kwikset 200DL Delta is another interior hall/closet passage lever, and the 200DL-RCALFD version ships with a round corner adjustable 20 minute UL latch and round corner strike.
16) I need a keyed lever on the same door style as the Norwood - what are my options?
The Norwood YR11NW is non-keyed. For a keyed opening, the Cal-Royal AG00 entrance lever is Grade 2 with a 6-pin Schlage C keyway keyed different on a 2-3/8 inch backset for 1-3/8 to 1-3/4 inch doors, and the AG05 is a Grade 2 storeroom lever with a deadlocking latchbolt over the same door thickness range. The Cal-Royal AG03 classroom lever uses a 6-pin Schlage C keyway keyed different on a 2-3/4 inch backset. The Hager 2525 is a Grade 2 commercial entry lock and the Hager 2580 a Grade 2 storeroom lock with the Withnell lever, both for 1-3/8 to 2 inch doors.
17) Are there other Grade 2 passage levers I can standardize on across a building alongside the Yale Norwood?
The Norwood YR11NW is Grade 2 passage function. Other Grade 2 passage levers to standardize against are the Accentra 5301LN Augusta in the 5300 Series and the Accentra 4601LN with Augusta trim in the 4600 Series, the Falcon B101 medium duty passage lever with a non-handed design in the B Series, the Hager 2510 with the Withnell design, and the Design Hardware J75 passage lever lockset with a flat lever for 1-3/4 inch doors. Matching the lever style across a floor usually matters more than matching the brand, since all of these hold the same grade and function.
18) Does handing matter when cross-shopping the Yale Norwood against other passage levers?
The Norwood YR11NW ships in a left hand and a right hand version in each finish, so the hand of the door is part of the order. Several comparable passage levers are built non-handed instead: the Falcon B101 Grade 2 passage lever and the Falcon K101 Grade 1 passage lock both carry a non-handed design, and the Baldwin Estate 5103 half dummy trim splits into left hand and right hand parts the way the Norwood does. Confirm the swing before ordering any handed set.
19) I want a keypad lever on a door where the rest of the openings use the Norwood - what carries that?
The Norwood YR11NW is a mechanical non-keyed lever with no code entry. For a code-entry lever on a matching opening, the Delaney LP250 is a Grade 2 electronic keypad leverlock, the Lockey 1150 is a heavy duty mechanical keypad lever set with double combination in passage function covering 1-1/8 to 2 inch doors, and the Emtek Classic keypad leverset is offered in the Classic series. The mechanical Lockey needs no power at the door.
20) Will screws show on the rose after the Yale Norwood lever is installed?
No visible fasteners. The Norwood uses a concealed screw round rose, so the finished face is clean metal with nothing showing, and the whole set installs with a single tool using a square spindle drive. That is the main visual difference from a builder-grade passage lever with exposed rose screws.
