Name: Yale YRL216 Assure Lever - Electronic Single Cylinder Keypad Lever Lock
Brand: Yale Residential
SKU: YRL216-NR-619
Price: 332.24 USD
Availability: InStock

Product Overview
FAQs

Yale YRL216 Assure Lock - Electronic Single Cylinder Keypad Lever Lock

Introducing the new Yale Assure Lever Locks, the sleekest and most convenient electronic lever locks on the market. Available in standalone or with a Yale Smart Module for seamless integration into your smart home or security system.

REPLACES YOUR EXISTING LEVER OR KNOB with the Assure Lever, a keypad lever lock, and enjoy the convenience of unlocking and locking your door using the backlit keypad; you'll never have to carry around your keys again. Create unique entry codes for friends and family and remove codes whenever you need to. Great for side entry doors, garage entry, basement doors, home offices - any door with a single hole prep. The lock is Grade 2 certified and backed Yale, one of the world's best known brands in the lock industry that's been securing homes since 1840, ensuring that your home and family is always safe. The Assure Lever can be upgraded with a Yale Network Module or Connected by August Kit to integrate into most home automation and security systems so that you can control and monitor the lock from anywhere

Meet the Assure Lever, a new lever lock designed for single-hole doors (doors without a deadbolt) from side entries, garages basements, interior rooms and more. Unlock and lock your door by entering your code on the keypad — the levers come in both key-free and keyed options. The Assure Levers can be used as standalone keypad locks, or as smart locks that can be fully integrated into a smart home or alarm system with the addition of a Connected by August, Z-Wave Plus or Yale Smart Module. The standalone version can be upgraded with any Yale Smart Module at any time.

FEATURES & BENEFITS

Certified ANSI/BHMA Grade 2
Available with acrylic push button keypad or capacitive touchscreen - both with backlit numbers that won't wear off
Comes in keyed and key-free options
Wake the screen by simply pressing the Yale logo
For use on all standard interior and exterior doors with a single hole prep
Manage unique entry codes to share with people you trust - delete codes when you need to delete
Touchscreen version has voice guidance for programming
Auto unlock can be enabled to ensure your door is always locked
Sleek touchscreen or acrylic keypad
One-touch locking and keypad wake-up
Create upto 250 unique 4-8 digit enrty code
Keypad has backlit numbers that wont wear off
Optional auto re-lock privacy mode and tamper alarms
Limited lifetime finish and mechanical warranty / 1year electronic warranty

REPLACES YOUR EXISTING LEVER OR KNOB on doors with a single hole (no deadbolt) that are 1-3/8" to 1-3/4" thick with just a screwdriver
LOCK AND UNLOCK YOUR DOOR FROM ANYWHERE by adding the lock to a compatible Z-Wave smart home or alarm system and app (i.e. Samsung SmartThings, , Ring Alarm, Wink, ADT, Alarm.com, Qolsys, Honeywell etc.). Requires compatible hub and app - no Yale app is used for this lock.
CONTROL ACCESS TO YOUR HOME: Never hide a key again, create unique entry codes for the people you trust. Delete codes anytime you need to.
ENABLE AUTO-LOCK to ensure your door always locks behind you.
BACKED BY YALE, the world's favorite lock brand since 1840 with a lifetime limited warranty on finish and mechanical hardware.
NEVER GET LOCKED OUT: Don't worry about dead batteries, the lever comes with 2 physical keys and has a 9V back-up charger on the keypad
MATCHES YOUR EXISITING HARDWARE'S FINISH and pairs with contemporary or traditional knobs, levers and handlesets.
REVERSIBLE HANDING, fits left handed or right handed doors
DON'T WORRY ABOUT MARKING YOUR DOOR: The lock has a rubber gasket to protect your door's finish.
The lock's touchscreen keypad is backlit so it's easy to see at night and the numbers won't wear off

DOWNLOADS

Unlock By Entering Your Code On The Keypad

When you don't have your phone on you, simply unlock the door using your unique entry code on easy-to-use keypad. Create permanent, scheduled or temporary codes for people you trust.

Automatically Locks Behind You

Never worry about whether or not you remembered to lock the door. The Assure Lock can automatically lock behind you. Optional setting.

Upgrade with Wi-Fi

Upgrade your Yale Assure Lock, with Wi-Fi, anytime by adding the Yale Access Upgrade Kit. Manage your lock from anywhere with the Yale Access app and enjoy added convenience with auto unlock via Bluetooth and voice assistant integration.

Share Access, Not Keys

Create unique codes to share with people you trust, or use your smart home app (like SmartThings) to grant access to others. Delete codes whenever you need to.

Easy To Install

Installs in minutes using just a screwdriver on most standard doors. Step by step installation and programming instructions are available with the free BILT app.

Manufacturer Resources

Product Specs

Series:: Assure Lock
Edge Bore:: 1"
Warranty:: Limited Lifetime Finish and Mechanical
Product Group:: Mechanical Locks
Product Subgroup:: Bored Locksets
Product Type:: Leversets
Subcategory:: Residential Door Levers
Cross Bore:: 2-1/8"
Commercial/Residential:: Residential
Cylinder and Keyways:: KW-1 5 Pin
Handle Type:: Lever
Reader Type:: Keypad
Product Attribute:: Electronic Locks
Tags:: yrl216 cba 619
Backset (Distance):: 2-3/8 or 2-3/4
Door Thickness Range:: 1-3/8" to 1-3/4"
Product Category:: Electronic Locks
Product Substrate:: Metal
Department:: Door Hardware

Yale Residential YRL216-NR-619 – Frequently Asked Questions

1) Do I have to order the Yale YRL216 Assure Lever for a left hand or right hand door?

No handing to specify. The Assure Lever is reversible and works on left hand or right hand doors, so one part number covers both swings. The same unit also covers either standard backset, 2-3/8 or 2-3/4 inches, so you are not committing to a backset at the order form either.

2) What is the difference between the NR, CBA and ZW2 versions of the Yale Assure Lever?

That option decides how the lock talks to anything outside the door. NR is standalone: keypad only, no radio, and it can be upgraded with a Yale Smart Module later. CBA is the Connected by August build, which brings the lock onto the Yale Access app. ZW2 is Z-Wave Plus, for pairing to a compatible Z-Wave hub or alarm panel such as SmartThings, Ring Alarm, ADT, Alarm.com, Qolsys or Honeywell; that route needs the hub and its app, not a Yale app. All three keypad functions (codes, auto-lock, one-touch locking) work the same regardless.

3) Can the Yale Assure Lever be keyed alike with the other locks on my building?

It uses a KW-1 5-pin cylinder, the Kwikset keyway, so a locksmith can key it into an existing KW-1 system. Keyed alike and keyed different are both orderable, so a set of doors can be pinned to one key at the time of order. Two physical keys ship with the lever, and there is a 9V contact on the keypad if the batteries die.

4) Is the Yale Assure Lever rated for commercial use, or is it a residential lock?

Residential. The Assure Lever is certified ANSI/BHMA Grade 2 and catalogued for residential openings, which suits multi-family units, single-family rentals and light-traffic side doors. For a commercial opening under real traffic, a Grade 1 cylindrical lever is the right class of product: the Corbin Russwin CL3110 and the Falcon K101 are both Grade 1 cylindrical levers, and the Falcon covers 1-3/8 to 2-1/4 inch doors. Neither is a keypad lock, so if you need code access on a commercial door that is a different search.

5) What other electronic keypad lever locks are there besides the Yale Assure Lever?

Two close alternatives. The Delaney LP250 is an electronic keypad leverlock, also Grade 2, and is the straight equivalent if you just want code entry with no smart-home tie-in. The Lockey 1150 is a mechanical keypad lever, no batteries and no electronics at all, and it covers a much wider door range at 1-1/8 to 2 inches. Pick the Lockey when the door is thin, thick, or somewhere you do not want to change batteries; pick the Yale when you want remote control or app-managed codes.

6) My door is 2 inches thick. Will the Yale Assure Lever YRL216 work?

No. The Assure Lever tops out at 1-3/4 inches; its range is 1-3/8 to 1-3/4. For a 2 inch door you need a lockset rated that far, such as the Hager 2525 Grade 2 entry lever at 1-3/8 to 2 inches, the Deltana 6201 Manchester entry lever at 1-3/8 to 2 inches, or the Lockey 1150 keypad lever at 1-1/8 to 2 inches if code entry is the point.

7) My door is 2 inches thick - the Yale YRL216 Assure Lever will not fit, so what lever will?

The YRL216 Assure Lever is built for doors 1-3/8 inch to 1-3/4 inch thick, so a 2 inch door needs a different body. The Hager 2510 passage lever and Hager 2580 storeroom lever with Withnell lever both cover 1-3/8 inch to 2 inch. Deltana's Manchester 6201, Morant 6411 and Linstead 6431 entry levers also cover 1-3/8 inch to 2 inch. On the Grade 1 side, the Dexter C1000 asylum lever spans 1-3/8 inch to 2 inch and the Corbin Russwin CL3110 vandal resistant passage lever is built for 1-3/4 inch to 2 inch. All of these are mechanical, so keypad entry does not carry over.

8) What is a mechanical alternative to the Yale YRL216 Assure Lever keypad lock if I do not want batteries or electronics on the door?

The Lockey 1150 is a heavy duty mechanical keypad lever set with double combination in a passage function, so the code is entered on a mechanical pushbutton keypad with no battery, no wiring and no smart module. It fits doors from 1-1/8 inch to 2 inch thick, which covers a wider range than the YRL216's 1-3/8 inch to 1-3/4 inch. Note the function difference: the 1150 is passage function, so it is code entry on the outside without the keyed override and the 250 user codes the YRL216 carries.

9) I need a keyed lever on a commercial door instead of a keypad - what takes the same single hole prep?

For a keyed mechanical entry lever, the Cal-Royal AG00 is an entrance lever with a 6-pin Schlage C keyway keyed different on a 2-3/8 inch backset, and it fits doors 1-3/8 inch to 1-3/4 inch thick - the same door thickness range as the YRL216 Assure Lever. The Hager 2525 is a Grade 2 commercial cylindrical entry lock with a lever handle for doors 1-3/8 inch to 2 inch. Keyway is the deciding detail: the YRL216 is cut to KW-1 5 pin, so an AG00 or a Schlage C keyed building will not key alike with it.

10) The Yale YRL216 Assure Lever is Grade 2 residential - what should I use on a high traffic commercial opening instead?

Step up to a Grade 1 cylindrical lever. The Dexter C1000 Series Grade 1 entry/office lever is keyed with a clutching lever and fits doors 1-3/8 inch to 1-3/4 inch, the same thickness window the YRL216 covers. For a classroom function on the same body, the Dexter C1000 classroom lever is also Grade 1 clutching keyed. The Falcon K101 is a Grade 1 heavy duty passage lock, non-handed and fire rated, for doors 1-3/8 inch to 2-1/4 inch. The YRL216 is a Grade 2 lock catalogued for residential use, so on a heavy traffic commercial opening these are the heavier bodies.

11) The opening needs a fire rated lever - does the Yale YRL216 Assure Lever cover that?

For a fire rated opening, look at the Falcon K101 Grade 1 passage cylindrical lock, which is fire rated and non-handed for doors 1-3/8 inch to 2-1/4 inch, or the Corbin Russwin CL3110 Grade 1 vandal resistant passage lever, which is fire rated for doors 1-3/4 inch to 2 inch. The YRL216 Assure Lever is a Grade 2 residential keypad lever for standard interior and exterior doors with a single hole prep, so on a rated opening the Falcon or Corbin Russwin body is the one to spec.

12) I want access control wired to the panel rather than a battery keypad - what replaces the Yale YRL216 Assure Lever?

For a wired opening, the Corbin Russwin CL33903 is a Grade 1 fail safe electrified cylindrical lever lock running on 12VAC/DC, offered with an NZ lever and D rose, for doors 1-3/4 inch to 2 inch. That is a hardwired lock released by the access control system. The YRL216 Assure Lever takes the opposite approach - it is battery powered with a backlit keypad and joins a system wirelessly through a Z-Wave Plus or Connected by August module, so no wire is pulled to the door.

13) Can I add Wi-Fi or a smart hub to the standalone Yale Assure Lever later, or do I have to buy the connected version up front?

You can start standalone. The NR build works as a keypad lock on its own and accepts any Yale Smart Module afterward, including the Yale Access upgrade kit for Wi-Fi, app control, auto unlock over Bluetooth and voice assistants. Buying CBA or ZW2 up front just saves the second step. Property managers often take NR for units where nothing is networked yet, then add the module on the doors that need remote code management.

14) How many entry codes can the Yale Assure Lever hold, and can I give a cleaner or contractor a temporary one?

Up to 250 unique codes, each 4 to 8 digits, and they can be added or deleted at any time. Permanent, scheduled and temporary codes are all supported, which is how most landlords handle turnover, cleaners and trades without rekeying. Auto re-lock, privacy mode and tamper alarms are optional settings on top of that.

15) Do I need a keyed cylinder on a keypad lever, or is key-free fine?

Both exist in the Assure Lever line. The keyed build carries a KW-1 5-pin cylinder and ships with two physical keys, which is the safer choice on an exterior or garage entry where a dead battery would leave someone outside. Key-free suits interior rooms and home offices where nobody is getting locked out of the building. The keypad also has a 9V jump contact either way.

16) Does swapping in a Yale Assure Lever require drilling or a new door prep?

Not on a standard bored door. It drops into the existing prep left by a knob or lever, so long as that prep is the usual 2-1/8 inch cross bore with a 1 inch edge bore, and the door is 1-3/8 to 1-3/4 inches. Installation is a screwdriver job. Where it will not go is a door already prepped for a separate deadbolt above the lever, since the Assure Lever is a single-hole lock and does not fill that second bore.

17) I need the doors around the keypad opening to match - what non-locking levers pair with a Yale YRL216 Assure Lever run?

Use passage and dummy levers on the openings that do not need to lock. Passage options include the Accentra 5301LN Augusta Grade 2 passage/closet lever, the Accentra 4601LN Grade 2 passage lever with Augusta trim, the Arrow GL01 Grade 2 Sierra lever passage lock, and the Falcon B101 Grade 2 non-handed passage lever. For a closet or a fixed pull, the BEST 7KC Series single dummy trim lever is Grade 2 non-keyed and the Callan Bentley is a Grade 2 dummy lever. These are all Grade 2, matching the YRL216's Grade 2 certification. Confirm finish separately, since these are different manufacturers than the Assure Lever's 619 satin nickel, 605 polished brass, 10BP oil rubbed bronze and BSP black suede offerings.

18) Can I put a Schlage cylinder in the Yale YRL216 Assure Lever using the Accentra 107S adapter kit?

No. The Accentra 107S is a Schlage cylinder adapter kit for Yale hardware in a Grade 1 apartment exit/public toilet function - it is a commercial cylindrical lock component, not trim for a residential Assure keypad lever. The YRL216 Assure Lever is supplied with a KW-1 5 pin cylinder in its keyed configuration. If you need the opening on a Schlage C keyway, change the lock rather than the cylinder: the Cal-Royal AG00 entrance lever and AG03 classroom lever are cut to a 6-pin Schlage C keyway.

19) What keyed mechanical lever gives a storeroom function instead of the Yale YRL216 Assure Lever keypad?

The Cal-Royal AG05 is a Grade 2 storeroom lever lockset with a deadlocking latchbolt for doors 1-3/8 inch to 1-3/4 inch, matching the YRL216 Assure Lever's door thickness range. The Hager 2580 with Withnell lever is also a Grade 2 storeroom lock, covering 1-3/8 inch to 2 inch. Storeroom function keeps the outside lever locked at all times and requires a key each entry, where the YRL216 is opened by a code on the keypad or by its KW-1 key.

20) Which lever should I use on an institutional or utility door where the Yale YRL216 Assure Lever is not the right function?

For asylum, institution and utility function, the Dexter C1000 Series F87 asylum lock is Grade 1 for doors 1-3/8 inch to 2 inch, and the Arrow MK33-BD-CS is a heavy duty asylum cylindrical lock with a ball knob and conventional cylinder on a Schlage C keyway. Both are keyed on both sides, which is the behavior an institutional opening usually calls for and is different from the YRL216 Assure Lever, a Grade 2 residential keypad lever with a single keyed cylinder.

21) What is the difference between the Yale YRL216 Assure Lever and a Grade 3 entrance lever like the Callan Artino?

The Callan Artino is a Grade 3 entrance leverset and the Cal-Royal AUS00 is a Grade 3 entrance/office lever with a solid brass forged body for doors 1-3/8 inch to 1-3/4 inch. The YRL216 Assure Lever is certified ANSI/BHMA Grade 2, a step above Grade 3 on the BHMA scale, and it is opened by a backlit keypad code rather than a key alone. If the opening also needs a deadbolt, the Callan Bennett is a Grade 3 entrance leverset and deadbolt combo, whereas the Assure Lever is designed for single hole doors with no deadbolt prep.

22) Will the Yale Assure Lever match the finish on the rest of my doors?

Four finishes are offered: satin nickel (619), polished brass (605), oil rubbed bronze permanent (10BP), and black suede powder coat (BSP). Each is available across all three technology builds, so you are not forced into a finish by the module choice. The lever is metal-bodied and carries a rubber gasket at the door face so it does not scuff the door finish when it seats.

23) I want a decorative lever with the same look on both sides of the door - what pairs with the Yale YRL216 Assure Lever approach?

For decorative openings, Baldwin Estate 5103 is offered as a passage lever, a privacy lever, and left hand and right hand half dummy levers, all with the 5048 rose, so a run of doors carries one lever design across functions. Emtek's Athena and Helios cast stainless steel leversets and the Arts and Crafts and Hammered leversets are sold as dummy pairs for both faces of a fixed door. These are mechanical decorative trim; the YRL216 Assure Lever is the keypad opening in that run, and its reversible handing means it fits either a left or right hand door without a hand-specific part number the way the Baldwin half dummies do.

How fast can I get the Yale Residential YRL216-NR-619 delivered?

Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.

Can I return it if it doesn’t work for me?

Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.

Does the Yale Residential YRL216-NR-619 come with a warranty?

Absolutely. The Yale Residential YRL216-NR-619 is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.

How do I get technical support or installation help for the Yale Residential YRL216-NR-619?

You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us

Why buy the Yale Residential YRL216-NR-619 from ZenSupply?

ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support, and rewards on every order. Our team is always ready to help you choose the right product for your project.
