Metallics JRM95 10-24 x 1-1/2 ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.19
$0.19
Metallics JRM95 10-24 x 1-1/2 in. Round Head Combo Machine Screws - Steel Zinc - 100qty

Metallics JRM95 10-24 x 1-1/2 in. Round Head Combo Machine Screws - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JRM95
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.19
$0.19
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10-24 x 1-1/2 in. Round Head Combo Machine Screws - Steel Zinc - 100qty

  • Features

    • Two Drives in one Head
    • Round head with slotted and Phillips Drive
    • 10-24 Diameter, 1-1/2" Length
    • Steel Zinc Material

  • Additional Notes

    • In 1985, Metallics was the first fastener company in America to offer a full line of Combo’s! | Other sizes and quantities available by request | Tensile strength values for stainless screws are offered as approximations only; there is no single standard for the performance requirements of stainless machine screws.

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Division:
Electrical H1
Drive Type:
Slotted/Phillips
Driver Size:
#2
Fastener Head Height:
0.123 - 0.137 in.
Fastener Head Type:
Round
Fastener Head Width:
0.334 - 0.359 in.
Fastener Length:
1/1/02
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Hardness:
Rockwell B70-B100
Language Code:
EN
Material Standard:
AISI 1006 - 1022
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Round_Head_Machine_Screw.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Phillips Recess Depth:
0.093 - 0.119
Phillips Recess Diameter:
0.182 - 0.195
Phillips Recess Width:
0.031
Product Group:
Fasteners
Product Height:
2.7 in
Product Length:
3 in
Product Weight:
1.12 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.082 - 0.108
Slot Depth:
0.065 - 0.087
Slot Width:
0.05 - 0.06
Sub Division:
Electrical-E H2
Tensile Strength:
60000 psi minimum
Thread Per Inch:
24
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Machine Screw
Type2:
Machine Screw
Series:
JRM
Product Finish:
Zinc
Product Details:
Machine Screw
Product Material:
Steel Zinc

Metallics JRM95 – Frequently Asked Questions

1) Can I drive these with a Phillips bit, or do I need a flat blade?
Either. The head is a combo drive, slotted and Phillips in one head, so a #2 Phillips bit or a flat blade both work. That is useful on a service call where you are reaching into a box one handed and only have one driver on the belt.
2) Do these Metallics screws meet Buy American or ARRA requirements for a public project?
No. The JRM95 is not Buy American compliant and not ARRA compliant, with country of origin listed as multiple. On a federally funded job with domestic sourcing language in the spec, you will need a domestically produced fastener instead.
3) How much does the round head stand up off the surface?
Head height runs 0.123 to 0.137 in. with a head width of 0.334 to 0.359 in. A round head sits proud of the surface rather than pulling flush, so if you need the fastener flush in a countersunk hole, choose a flat head machine screw instead of the JRM95.
4) Are these strong enough for structural or load-carrying use?
Tensile strength is 60,000 psi minimum with hardness of Rockwell B70-B100, made from AISI 1006-1022 steel. That is a general-purpose low-carbon machine screw intended for electrical, plumbing, and HVAC work, not a graded structural bolt. For load-bearing connections specify a graded hex cap screw instead.
5) Will zinc-plated steel screws hold up outdoors or in a damp location?
Zinc plating over steel is a mild corrosion barrier suited to dry interior work. For wet locations, exterior boxes, or coastal and wash-down environments, go with a stainless machine screw in the same 10-24 x 1-1/2 size rather than the zinc-plated JRM95.
6) How are the JRM95 screws packaged and what is the smallest quantity I can buy?
They ship in a jar of 100, which is the order minimum. The filled jar weighs 1.12 lbs. Handy for a van stock or a shop drawer rather than a loose handful at the counter.
7) Is a machine screw the right choice, or should I be using a sheet metal screw?
A machine screw like the JRM95 has a straight, uniform 24 TPI machine thread meant to turn into a pre-tapped hole or a nut, which is why it suits tapped box ears and threaded brackets. If you are fastening into unthreaded sheet metal with no tapped hole, use a self-tapping sheet metal screw instead.
8) Will a #2 Phillips bit cam out of these heads?
The Phillips recess is specified at 0.182 to 0.195 in. diameter with a 0.093 to 0.119 in. depth and gaging depth of 0.082 to 0.108 in., which is matched to a #2 driver. Using a #1 or #3 bit is what strips a combo head, so stay with the #2. The slot side measures 0.05 to 0.06 in. wide by 0.065 to 0.087 in. deep if you prefer a flat blade.
9) I need 10-24 combo screws in a different length. Does Metallics make other sizes in the JRM series?
Yes, the JRM series covers other sizes and quantities by request beyond the JRM95's 10-24 x 1-1/2 in. If you are standardizing a stockroom on one drive style, the combo head carries across the line.
