Metallics JFMP94SS 10-32 x 3 in. Flat Head Phillips Machine Screws - 18-8 Stainless - 100qty

Metallics JFMP94SS 10-32 x 3 in. Flat Head Phillips Machine Screws - 18-8 Stainless - Each

(No reviews yet) Write a Review

Model: JFMP94SS
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$192.86
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10-32 x 3 in. Flat Head Phillips Machine Screws - 18-8 Stainless - 100qty

  • Additional Notes

    • Other sizes and quantities available by request | Hardness and tensile strength standards are offered as guides only for stainless machine screws. There is currently no national standard for these performance requirements for stainless machine screws.

  • Features

    • Stainless is also superior to steel in withstanding some elevation in application operating temperature while maintaining its strength.
    • 10-32 Diameter, 3" Length
    • 18-8 Stainless Material
    • Flat head with Phillips Drive
    • Stainless steel machine screws are used in applications which require general atmospheric corrosion resistance, in food processing machinery and refrigeration equipment.

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.3-1998
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.098 - 0.116 in.
Fastener Head Type:
Flat
Fastener Head Width:
0.333 - 0.362 in.
Fastener Length:
3
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Gaging Diameter:
0.313
Hardness:
Rockwell B85-B95
Language Code:
EN
Material Standard:
SAE
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Flat_Head_Mach_Screw.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Phillips Recess Depth:
0.124
Phillips Recess Diameter:
0.198
Phillips Recess Width:
0.032
Product Group:
Fasteners
Product Height:
4.57 in
Product Length:
3 in
Product Weight:
1.95 lbs
Product Width:
3 in
Protrusion Gaging Diameter:
0.025 - 0.042 Above
Sub Division:
Electrical-E H2
Tensile Strength:
1200 lb minimum
Thread Per Inch:
32
Thread Standard:
ANSI/ASME B1.1
Thread Type:
UNF
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Machine Screw
Type2:
Machine Screw
Series:
FM and FMP
Product Details:
Machine Screw
Product Material:
18-8 Stainless

Metallics JFMP94SS – Frequently Asked Questions

1) Will a 10-32 machine screw thread into my existing device box or fixture tapped holes?
The Metallics JFMP94SS is a 10-32 UNF machine screw cut to the ANSI/ASME B1.1 thread standard, 32 threads per inch. That is the same 10-32 thread used in tapped holes on electrical boxes, covers, and fixture straps, so it threads straight into any hole tapped 10-32. It will not work in a 8-32 or 1/4-20 hole.
2) How deep a buildup can a 3 inch 10-32 flat head screw reach through?
Fastener length is 3 inches, measured from the flat head bearing surface since this is a flat (countersunk) head. That gives usable reach through about 3 inches of combined plaster ring, mud ring, drywall layers, and spacers before it bottoms in the tapped hole. If you only need to pass through a cover and a box ear, a much shorter 10-32 is the better choice.
3) Will the head sit flush, and what size countersink do I need?
Yes, it is made to sit flush. The flat head measures 0.333 to 0.362 inches across with a head height of 0.098 to 0.116 inches, built to ASME B18.6.3-1998, so an 82 degree countersink sized for a #10 flat head takes it level with the surface. In an uncountersunk hole the head will stand proud by roughly the head height.
4) Can I use these Metallics JFMP94SS screws on a Buy American or ARRA funded job?
No. The JFMP94SS is not Buy American compliant and is not ARRA compliant, with country of origin listed as multiple. If your project has domestic sourcing requirements written into the spec, this screw will not satisfy them.
5) What screwdriver or bit do these Metallics flat head Phillips machine screws take?
A #2 Phillips. The recess is 0.198 inches in diameter and 0.124 inches deep, so a #2 bit seats fully; a #1 will cam out and a #3 won't seat. Worth noting for anyone driving a hundred of these with a drill, stainless is softer than hardened steel and the recess will strip if you lean on an impact driver.
6) Are stainless machine screws the right pick for a damp or corrosive location, or should I use plated steel?
18-8 stainless is the choice where you need general atmospheric corrosion resistance, which covers exterior boxes, wash-down areas, food processing machinery, and refrigeration equipment. It also holds its strength better than plated steel at elevated operating temperatures. Indoors in a dry location, a plated steel 10-32 does the same mechanical job; the reason to pay for stainless is moisture, chemicals, or heat.
7) How are these sold, loose or in a package?
They ship in a jar of 100, which is the order minimum. Jar weight is 1.95 lbs. Metallics notes other sizes and quantities in the FM and FMP series are available by request if 3 inch is longer than you need.
