Metallics JTEKD3V 10 x 3/4 in....
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.23
$0.23
Metallics JTEKD3V 10 x 3/4 in. 1/4 Indented Hex Head Self-Drilling & Tapping Screws with Washer - #2 Drill Point - Steel Zinc - 500qty

Metallics JTEKD3V 10 x 3/4 in. 1/4 Indented Hex Head Self-Drilling & Tapping Screws with Washer - #2 Drill Point - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTEKD3V
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.23
$0.23
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10 x 3/4 in. 1/4 Indented Hex Head Self-Drilling & Tapping Screws with Washer - #2 Drill Point - Steel Zinc - 500qty

  • Additional Notes

    • Other sizes and quantities available by request. | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

  • Features

    • Minimum torques are the same for stainless and steel self-drill screws. Drill time is 2.5 seconds for a 1 mm thick plate.
    • 10 Diameter, 3/4" Length
    • Steel Zinc Material
    • 1/4 Indented Hex Head with Hex Drive
    • #2 Drill Point

Manufacturer Resources

Product Specs

Minimum Purchase:
500 units
Arra Compliant:
C
Buy American Compliant:
C
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#2
Drive Type:
Hex
Fastener Head Color:
Silver
Fastener Head Height:
0.105 - 0.12 in.
Fastener Head Type:
Indented Hex
Fastener Head Width:
0.305 - 0.312 in.
Fastener Length:
4-Mar
Hardness:
Rockwell C32-40
Language Code:
EN
Material Standard:
AISI 1016 - 1024
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Head_Self-Drill_TS_Indent_Hex_Washer.pdf
Order Minimum Imperial:
500
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Panel Thickness:
0.035 - 0.110 IN
Product Group:
Fasteners
Product Height:
5.75 in
Product Length:
3.5 in
Product Weight:
2.7 lbs
Product Width:
3.5 in
Screw Point Type:
Drill Point
Slot Depth:
0.057 - 0.072
Slot Width:
0.05 - 0.06
Sub Division:
Electrical-E H2
Thread Per Inch:
16
Thread Standard:
SAE J78 - 2013
Thread Type:
UNC
Torsional Strength:
61 lb-in minimum
Washer Od:
0.384 - 0.414 in.
Washer Thickness:
0.019 - 0.031 IN
Width Across Corners:
0.34
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEKD
Product Finish:
Zinc
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
Steel Zinc

Metallics JTEKD3V – Frequently Asked Questions

1) How thick a metal panel can the Metallics JTEKD3V #10 self-drilling screw go through?
The #2 drill point on the JTEKD3V is rated for panel thickness of 0.035 to 0.110 inch. That covers typical light-gauge steel studs, strut, hat channel and sheet metal. Thicker structural steel needs a heavier drill point, not this one.
2) Do I need to pre-drill a pilot hole for these #10 x 3/4 in. hex head screws?
No. The JTEKD3V is a Type BSD self-drilling and tapping screw, so the drill point cuts its own hole and the 16 threads per inch UNC thread taps it in one pass. No pilot hole, no separate tap.
3) Does the washer on this screw seal, or is it just a bearing surface?
It is an integral steel washer head, not a sealing washer. Washer OD runs 0.384 to 0.414 inch with a thickness of 0.019 to 0.031 inch, which spreads clamp load over sheet metal and keeps the head from pulling through thin panel. For a weathertight roof or siding application you want a bonded EPDM-washer screw instead.
4) Are these zinc-plated screws okay for outdoor or damp electrical work?
The JTEKD3V is zinc-plated carbon steel (AISI 1016-1024), which is a dry-interior finish. Use it indoors on strut, raceway, boxes and light-gauge framing. Outdoors, in corrosive or coastal conditions, or in direct contact with treated lumber, go to a stainless or coated self-drilling screw.
5) Will the Metallics JTEKD3V snap off in an impact driver?
Torsional strength is 61 lb-in minimum, with a case hardness of Rockwell C32-40. Metallics notes that minimum torques are the same for stainless and steel self-drill screws and drill time is 2.5 seconds through a 1 mm plate. Keep the driver speed up and the pressure steady; backing off pressure or stalling the point is what shears a drill screw, not the torque rating.
6) Do these screws meet Buy American requirements for a public job?
Metallics lists the JTEKD3V as both ARRA compliant and Buy American compliant. Country of origin is listed as multiple. Dimensionally it is built to ASME B18.6.3-2010 with threads to SAE J78-2013, which is the spec language most government and institutional submittals ask for on self-drilling screws.
7) Is a 3/4 inch length long enough to fasten strut or a box to a metal stud?
At 3/4 inch overall with a 0.035 to 0.110 inch panel thickness rating, there is plenty of thread left to engage past light-gauge steel. Where it falls short is stacked material: if your combined grip (channel plus flange plus a bracket) pushes the drilled layer beyond 0.110 inch, step up to a longer screw with a heavier drill point.
8) How are these #10 x 3/4 in. drill screws packaged, and is there a minimum order?
They ship in a jar of 500, and 500 count is the order minimum. The packed jar weighs 2.7 lbs. Metallics notes other sizes and quantities are available by request.
