Metallics JTEKD20SS 12 x 3/4 i...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$192.86
Metallics JTEKD20SS 12 x 3/4 in. 5/16 Indented Hex Head Self-Drilling & Tapping Screws with Washer - #3 Drill Point - 410 Stainless Steel - 100qty

Metallics JTEKD20SS 12 x 3/4 in. 5/16 Indented Hex Head Self-Drilling & Tapping Screws with Washer - #3 Drill Point - 410 Stainless Steel - Each

(No reviews yet) Write a Review

Model: JTEKD20SS
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$192.86
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
12 x 3/4 in. 5/16 Indented Hex Head Self-Drilling & Tapping Screws with Washer - #3 Drill Point - 410 Stainless Steel - 100qty

  • Features

    • Minimum torques are the same for stainless and steel self-drill screws. Drill time is 2.5 seconds for a 1 mm thick plate.
    • 410 Stainless Steel Coating
    • 12 Diameter, 3/4" Length
    • 5/16 Indented Hex Head with Hex Drive
    • #3 Drill Point

  • Additional Notes

    • Other sizes and quantities available by request. | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#3
Drive Type:
Hex
Fastener Head Height:
0.139 - 0.155 in.
Fastener Head Type:
Indented Hex
Fastener Head Width:
0.305 - 0.312 in.
Fastener Length:
4-Mar
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Hardness:
Rockwell C38-46
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Head_Self-Drill_TS_Indent_Hex_Washer.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Panel Thickness:
0.110 - 0.210 IN
Product Group:
Fasteners
Product Height:
2.15 in
Product Length:
3 in
Product Weight:
0.85 lbs
Product Width:
3 in
Screw Point Type:
Drill Point
Slot Depth:
0.077 - 0.093
Slot Width:
0.056 - 0.067
Sub Division:
Electrical-E H2
Thread Per Inch:
14
Thread Standard:
SAE J78 - 2013
Torsional Strength:
92 lb-in minimum
Washer Od:
0.398 - 0.432 in.
Washer Thickness:
0.022 - 0.039 IN
Width Across Corners:
0.34
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEKD
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
410 Stainless Steel

Metallics JTEKD20SS – Frequently Asked Questions

1) Are these Metallics stainless self-drilling screws Buy American or ARRA compliant for a government job?
No. The JTEKD20SS is not Buy American compliant and is not ARRA compliant, with multiple countries of origin. If your contract carries a domestic sourcing clause, this part will not satisfy it.
2) Is the JTEKD20SS screw stainless all the way through or just coated?
The material is 410 stainless steel, a hardenable martensitic stainless. That is what lets the point be heat treated to Rockwell C38-46 and still drill its own hole, which 300 series stainless cannot do. Note 410 is corrosion resistant but not to the level of 304 or 316, so for coastal or chemical exposure it is the wrong choice.
3) Does this screw come with a sealing washer or just a bonded flat washer?
An integral washer head with an outside diameter of 0.398 to 0.432 inches and washer thickness of 0.022 to 0.039 inches. It spreads bearing load over sheet metal and strap, which is what keeps the head from pulling through thin panel. It is a metal washer, not an EPDM sealing washer, so it is not intended as a weathertight roofing fastener.
4) What are these self-drilling hex head screws actually used for on the job?
They are the general purpose Type BSD self-drill and tap screw for electrical, plumbing, heating and air conditioning work: hanging strut and strap, fastening boxes and enclosures to metal studs, duct and sheet metal connections. Because they drill and tap in one pass, there is no pilot hole step. Drill time runs about 2.5 seconds through a 1 mm plate.
5) How much torque can a #12 410 stainless self-drill screw take before it snaps?
Minimum torsional strength is 92 lb-in. Stainless and steel self-drillers carry the same minimum torque figures, so you do not need to back off your driver clutch compared to a plated carbon screw. Set the clutch rather than running an impact wide open, since the drill point work hardens the hole and overdriving at the seating point is where these break.
6) How are the JTEKD20SS screws packaged and what is the minimum order?
They ship in a jar of 100, which is the order minimum. Jar weight is 0.85 lbs. Other sizes and quantities can be had by request if you need a different length or diameter for the same panel range.
