1/4 XH BLK MI 90 ELL
Manufacturer Resources
Product Specs
- Dimensions Specification:
- ASME B16.3
- End Conn Size 1:
- FPT
- End Conn Size 2:
- FPT
- Material Specification:
- ASTM A-197
- Pressure Rating Specification:
- ASME B16.3
- Size 1:
- 0.25
- Size 2:
- 0.25
- Strength:
- XH
- Thread Specification:
- ASME B1.20.1
- Ul Fm:
- Yes
- Department:
- Plumbing
- Product Group:
- Pipe Fittings
- Product Subgroup:
- Elbows
- Product Type:
- 90° Elbow
- Product Finish:
- Black
- Product Material:
- Malleable Iron
- Product Weight:
- 0.2 lbs
ASC Engineered Solutions 310500202 – Frequently Asked Questions
1) What thread does the ASC 1/4 inch black malleable iron 90 degree elbow take on each end?
Both ends are 1/4 inch FPT, so it threads onto male pipe thread at each opening. Threads are cut to ASME B1.20.1 (NPT), which is what standard black steel pipe and nipples are threaded to, so it mates with 1/4 inch black pipe straight off the shelf.
2) Is this ASC 1/4 inch 90 degree elbow UL listed and FM approved for fire sprinkler work?
Yes, the fitting carries UL/FM recognition, so it can be used where the fire protection spec requires listed and approved fittings. It is extra heavy malleable iron to ASTM A-197 with NPT threads, which is the usual construction for threaded sprinkler branch piping.
3) Will this elbow match the laying length and dimensions on my piping drawing?
Dimensions are made to ASME B16.3, the standard for malleable iron threaded fittings, so center-to-end and thread engagement match any other B16.3 1/4 inch 300 class elbow. That means it drops in where a drawing or another supplier's B16.3 fitting is specified without changing your pipe cut lengths.
4) Is this a reducing elbow or same size on both ends?
Same size both ends: 1/4 inch by 1/4 inch, female thread to female thread. It turns the run 90 degrees without changing pipe size. If you need to change size at the turn, you want a reducing elbow or a separate bushing.
How fast can I get the ASC Engineered Solutions 310500202 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the
continental
U.S.
Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit,
reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the ASC Engineered Solutions 310500202 come with a warranty?
Absolutely. The ASC Engineered Solutions 310500202 is backed by a manufacturer’s warranty.
For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the ASC Engineered Solutions 310500202?
You can call, text, or email our expert support team for fast answers. We’re here to help with
product
selection,
installation tips, and troubleshooting. Contact Us
