Viega 15448 ProPress tee Smart Connect technology Copper, 1-1/2'' x 1-1/2'' x 1/2''

The Viega 15448 is a reducing copper press tee sized 1-1/2 inch x 1-1/2 inch x 1/2 inch, so the run stays at 1-1/2 inch and the branch drops to 1/2 inch. That is the tee you use to pull a 1/2 inch takeoff (fixture drop, gauge, hose bibb, small riser) off a 1-1/2 inch copper main without stacking a full-size tee and a bushing.

All three are press. The connection type is listed as P1 x P2 x P3, meaning every outlet is a ProPress socket that gets crimped onto copper tube with a press tool and jaw of the matching size. There is no thread and no solder cup on this fitting, so if you need a threaded branch you want a press x FPT or press x MPT tee instead.

ProPress copper fittings size to the nominal outside diameter of the tube, so a 1-1/2 inch socket takes 1-1/2 inch copper water tube whether it is type M, L or K, and the 1/2 inch branch takes 1/2 inch copper tube. What it will not accept is iron pipe, PEX or CPVC, and it will not take copper that has been kinked, out of round, or left with a burr at the cut, the seal has to ride on clean square-cut tube.

Smart Connect is the feature in the sealing element that lets an unpressed joint leak on purpose during test, so a connection you missed shows itself instead of hiding until the wall is closed. Practical use: rough in the branch, fill and pressure test, and walk the line looking for weeping at the sockets. On a 1-1/2 x 1-1/2 x 1/2 tee that matters most at the small 1/2 inch branch, which is the one crews forget after pressing the two big ends.

It is a copper ProPress tee, the same fitting family used on copper tube for potable water and for hydronic heating and chilled water distribution. What decides the application on your job is the sealing element in the fitting, not the body: the standard EPDM-sealed ProPress is the potable and hydronic fitting, while fuel gas and oil service uses the separate HNBR-sealed ProPress G line. This one is catalogued as a plumbing copper press tee.

Published overall size is 3.78 inches wide, 2.902 inches high and 2.122 inches long. The 3.78 inch dimension is the long axis across the 1-1/2 inch run, so plan that much clear tube-to-tube plus the swing of the press ring around the branch. Fittings this size are usually what forces a crew to press the branch before setting the assembly into a crowded bay.

That is the main reason contractors spec it. Because all three outlets are press connections rather than solder cups, the joint is made cold with a press tool, so there is no open flame, no hot work permit, and no fire watch in a finished or occupied space. It also means the line does not have to be bone dry the way a soldered joint does.

Viega part number 15448, a copper ProPress reducing tee at 1-1/2 x 1-1/2 x 1/2 inch, manufactured in Germany. Each fitting weighs 0.726 lbs, which is the figure to use when you are pricing freight on a bulk fitting order.
