Viega 15538 ProPress tee Smart Connect technology Copper, 2'' x 2'' x 1/2''

The Viega 15538 is a reducing press tee sized 2 inch x 2 inch x 1/2 inch. The run is 2 inch on both ends and the branch drops to 1/2 inch, so it's the fitting you use to pull a small branch (a fixture drop, a hose bibb, a gauge or sensor tap) off a 2 inch copper main without adding a reducer and a coupling.

All three ends are press. The connection type is P1 x P2 x P3, meaning press on both 2 inch run ends and press on the 1/2 inch branch. There is no thread or solder cup on this fitting, so the 1/2 inch branch needs a press adapter downstream if you're transitioning to threaded pipe.

It's a copper fitting for copper tubing systems. The body material is copper, and ProPress copper fittings press onto hard-drawn copper tube in the matching nominal sizes, 2 inch on the run and 1/2 inch on the branch. Carbon steel and stainless lines take Viega's MegaPress or ProPress stainless lines instead, not this one.

Smart Connect is a feature of the sealing element that lets an unpressed connection leak visibly during pressure testing, so a joint you skipped gets found before the walls close up. It doesn't change the installation itself: you still cut square, deburr, mark insertion depth, seat the tube fully, and press. It's a verification aid, not a substitute for pressing every joint.

Plan the pocket around the fitting body first: it measures 4.252 inches wide, 3.331 inches high, and 2.594 inches long. On top of that you need swing room for a 2 inch press ring and actuator, which is considerably larger than the fitting itself. Tight joist bays and close-spaced racked mains are where a 2 inch press job goes wrong, so set your hanger spacing with the ring in mind before you cut in the tee.

Yes, two different tools come into play on one fitting. The 1/2 inch branch presses with a standard 1/2 inch jaw, while the 2 inch run ends take a 2 inch press ring with an actuator jaw. Have both on the lift before you set the tee, because the 2 inch run ends are the awkward ones and you don't want to press the branch first and lose your working angle.

Order Viega part number 15538. That number covers the copper ProPress tee in 2 inch x 2 inch x 1/2 inch with press ends on all three openings. There are no finish or configuration options to specify with it.

The fitting itself weighs 1.001 lbs, which is not the issue on its own. What matters is that a 1/2 inch branch coming off a 2 inch main is a stress riser: support the 2 inch run on both sides of the tee per your hanger spacing and don't let the branch piping hang unsupported off the press joint.

Made in Germany. For spec jobs and institutional procurement where country of origin has to be documented on the submittal, that's the declared origin for this copper ProPress tee.
