94772 Viega ProPress tee Smart Connect technology Copper, 2'' x 2'' x 1''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x P3
- Country Of Origin:
- Made In Germany
- Material Type:
- Copper
- Product Dimension:
- 2'' x 2'' x 1''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 2.594"
- Product Height:
- 3.488"
- Product Weight:
- 1.118 lbs
- Product Width:
- 4.984"
Viega 94772 – Frequently Asked Questions
1) What size branch does the Viega 94772 ProPress tee reduce to?
The Viega 94772 is a reducing tee: 2 inch run on both ends with a 1 inch branch outlet. Use it where you are taking a 1 inch takeoff off a 2 inch copper main without dropping the main size.
2) Are all three ends of the Viega 94772 tee press connections, or is one threaded or sweat?
All three ends are press. The connection type is P1 x P2 x P3, so the two 2 inch run ends and the 1 inch branch all get crimped with a press tool and jaws sized to each end. There is no threaded or solder end on this fitting, so if you need to land on threads you will need an adapter downstream.
3) Does the Viega 94772 tee go on copper tube or on PEX?
Copper. The 94772 is a copper ProPress fitting made to press onto copper tube, not a PEX fitting. Sizing the branch and run to copper tube is what the 2 x 2 x 1 designation refers to.
4) What does Smart Connect do on a Viega ProPress tee, and does it mean I can skip pressing a joint?
Smart Connect is a feature of the sealing element that lets an unpressed connection leak during pressure testing so you can find it before the wall closes up. It is a way to catch a missed crimp, not a substitute for pressing. Every one of the three ends on the 94772 still has to be pressed.
5) Can I use a ProPress tee like this instead of soldering a 2 inch copper tee in an occupied building?
That is the usual reason to reach for it. A pressed copper tee like the 94772 is made up cold with a press tool and jaws, so there is no torch, no hot work permit and no draining and drying the line the way a 2 inch sweat joint would need. The trade-off is that you need the tool and correctly sized jaws for both the 2 inch and the 1 inch ends on hand before you cut in.
6) Is the Viega 94772 heavy enough to need support near the branch?
The fitting weighs 1.118 lbs on its own, which is light, but it sits in a 2 inch copper run. Support the main to code on both sides of the tee and hang the 1 inch branch so the press joints are not carrying pipe weight or vibration.
7) Where is the Viega 94772 ProPress tee made, and what part number do I give my supplier?
Order it as Viega part 94772, a copper ProPress 2 x 2 x 1 tee, made in Germany. That manufacturer number is what identifies the exact reducing configuration, since Viega catalogs a separate number for each size combination.
