25386 Viega MegaPressG tee Smart Connect technology Carbon steel, 2'' x 2'' x 3/4''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x P3
- Material Type:
- Carbon Steel
- Product Dimension:
- 2'' x 2'' x 3/4''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 7.547"
- Product Height:
- 2.894"
- Product Weight:
- 2.444 lbs
- Product Width:
- 4.402"
- Product Material:
- Carbon steel
Viega 25386 – Frequently Asked Questions
1) What pipe sizes does the Viega 25386 MegaPressG tee connect?
The MegaPressG tee, model 25386, is a 2 inch x 2 inch x 3/4 inch reducing tee. The run is 2 inch on both ends with a 3/4 inch branch outlet, so it lets you pull a 3/4 inch take-off from a 2 inch line without stepping the main down.
2) Are all three ends of the Viega 25386 tee press connections, or is the branch threaded?
All three are press. The connection type is P1 x P2 x P3, meaning press on the 2 inch run ends and press on the 3/4 inch branch. You'll need press jaws or rings sized for 2 inch and 3/4 inch MegaPress to make up the joints; nothing on this fitting threads or welds.
3) What pipe does a MegaPressG carbon steel tee press onto?
It is a carbon steel fitting made to press onto black iron pipe, which is why MegaPressG is used for gas and fuel work rather than a copper press system. The 25386 is carbon steel through the body, so it should not be used on copper tube.
4) How much room do I need to fit a 2 inch x 2 inch x 3/4 inch MegaPressG tee in a tight chase?
The fitting measures 7.547 inches long, 4.402 inches wide and 2.894 inches high. The 7.547 inch run length is what usually governs: you need that much straight pipe clearance between adjacent fittings, plus swing room for the press tool jaw around each of the three joints.
5) What does Smart Connect technology on this Viega tee actually do for me on the job?
Smart Connect is the feature built into the sealing element of the MegaPressG fitting that lets an unpressed joint leak visibly during pressure testing, so you can find a connection you skipped before the system is closed up. On a 2 inch x 2 inch x 3/4 inch tee with three separate press joints, that matters: it is easy to press two and walk away from the third.
6) What part number do I order for a 2 inch x 2 inch x 3/4 inch MegaPressG tee?
Order Viega part number 25386. That is the MegaPressG carbon steel tee in 2 inch x 2 inch x 3/4 inch with press ends on all three openings. Confirm the branch size when ordering, since the 2 inch run is offered with several different branch reductions.
7) Is this Viega MegaPressG tee made in Germany?
Yes, the 25386 is made in Germany. Specification writers and institutional buyers tracking country of origin on submittals can list it as German manufacture.
