25601 Viega MegaPressG adapter Smart Connect technology Carbon steel, 1-1/4'' x 1''
Manufacturer Resources
Product Specs
- Connection Type:
- P x FPT
- Material Type:
- Carbon Steel
- Product Dimension:
- 1-1/4'' x 1''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 3.319"
- Product Height:
- 2.205"
- Product Weight:
- 0.749 lbs
- Product Width:
- 2.205"
- Product Material:
- Carbon steel
Viega 25601 – Frequently Asked Questions
1) What are the two connection ends on the Viega MegaPressG 25601 adapter?
One end is a 1-1/4 inch MegaPressG press connection and the other is a 1 inch female pipe thread. Viega lists it as P x FPT, so the press side goes onto carbon steel pipe with a press tool and jaw, and the threaded side accepts a male-threaded nipple, valve, or appliance connector.
2) Is the Viega 25601 press adapter made of carbon steel or copper?
Carbon steel. That matters because the press end is built for black iron / carbon steel pipe systems, not for copper tube. If you are pressing copper, you need a copper press fitting instead.
3) Will a 1-1/4 inch MegaPressG adapter let me reduce down to a 1 inch threaded connection?
Yes. The 25601 takes 1-1/4 inch pipe on the press side and steps down to a 1 inch FPT outlet, so it handles the reduction and the press-to-thread transition in one fitting. No separate bushing needed between them.
4) What does Smart Connect mean on a MegaPressG fitting?
Smart Connect is the feature Viega builds into the sealing element so an unpressed connection leaks visibly during pressure testing instead of passing inspection and failing later. On a run with several of these adapters, it is how you find the joint the crew skipped before the wall closes.
5) Do I need to thread or weld pipe to install the Viega 25601?
Not on the press side. The 1-1/4 inch end is a cold press joint, so you cut, deburr, mark depth and press with the matching jaw, which keeps the hot work permit out of occupied spaces. Only the 1 inch FPT outlet needs thread sealant and a wrench.
6) What is the manufacturer part number and weight for ordering the Viega MegaPressG 1-1/4 x 1 adapter?
Order it as Viega part 25601. Each fitting weighs 0.749 lbs, useful if you are pricing freight on a box of them for a rough-in. It is made in Germany.
