25610 Viega MegaPress adapter Smart Connect technology Carbon steel, 1-1/2'' x 3/4''
Manufacturer Resources
Product Specs
- Connection Type:
- P x FPT
- Country Of Origin:
- Made in Germany
- Material Type:
- Carbon Steel
- Product Dimension:
- 1-1/2'' x 3/4''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 3.697"
- Product Height:
- 2.437"
- Product Weight:
- 0.86 lbs
- Product Width:
- 2.437"
Viega 25610 – Frequently Asked Questions
1) What kind of connection does the Viega MegaPress 25610 adapter have on each end?
The 25610 is a press-by-female-thread fitting: one end is a MegaPress press connection, the other is female pipe thread (FPT). You press the 1-1/2 inch side onto the pipe with a press tool and jaw, then thread into the 3/4 inch FPT port. There is no threading or welding on the press end.
2) Will the Viega 25610 MegaPress fitting work on black iron or carbon steel pipe?
Yes. The 25610 is a carbon steel MegaPress fitting, which is the Viega line made for joining carbon steel pipe such as black iron. Carbon steel press fittings are not the right choice for copper or stainless lines; those take the copper or stainless press systems instead.
3) What size pipe and what size thread does the Viega 25610 adapter take?
It is a 1-1/2 inch by 3/4 inch adapter: the press end suits 1-1/2 inch carbon steel pipe and the threaded side is a 3/4 inch female port, so it steps you down to a 3/4 inch male-threaded nipple, valve, or gauge connection.
4) How much clearance do I need around the pipe to press the Viega 25610?
Plan the fitting body itself at 3.697 inches long and 2.437 inches across in both height and width, then add room for the press jaw to close fully around the press end. In a tight chase or against a wall, that jaw swing is usually the limiting factor, not the fitting.
5) What is Smart Connect on the Viega MegaPress 25610 and why does it matter on a punch list?
Smart Connect is Viega's unpressed-connection feature: a joint that has been assembled but not pressed will leak during pressure test, so it shows itself before the walls close up. On a big mechanical run that is the difference between finding one missed press at test and finding it after drywall.
6) Do I need anything besides the 25610 fitting to make the joint?
The fitting ships as the adapter only. You supply a Viega-compatible press tool with the correct jaw for 1-1/2 inch carbon steel, properly cut and deburred pipe, and thread sealant or tape for the 3/4 inch FPT side. Nothing is threaded onto the press end.
7) Is the Viega 25610 adapter a domestic or imported fitting, and what does one weigh for a material takeoff?
The 25610 is made in Germany and weighs 0.86 lbs each, which is what you want for hanger loads and freight on a bulk order of adapters.
8) How do I make sure I am ordering the right Viega MegaPress adapter?
Order by Viega part number 25610. That number is the 1-1/2 inch press by 3/4 inch FPT carbon steel adapter; adjacent MegaPress adapters share the same body style but different press or thread sizes, so the part number is what separates them.
