Spec Sheet
Product Specs
- Actuator:
- Mechanically interlocked, mushroom head
- Actuator Color:
- Black, red
- Actuator Material:
- Plastic
- Bezel:
- Chrome
- Illumination:
- Non-illuminated
- Operating Mode:
- Maintained
- Series:
- 10250T
- Department:
- Electrical
- Product Type:
- 30.5 mm, Heavy-Duty
- Product Length:
- 4.4 IN
- Product Details:
- 30.5 mm, Heavy-Duty
- Mounting Method:
- Flush
- Performance Rating:
- NEMA 3, 3R, 4, 4X, 12, 13
- Product Height:
- 3.2 IN
- Product Weight:
- .7 LB
- Product Width:
- 3.3 IN
B-LINE 10250TA68 – Frequently Asked Questions
1) Is the 10250TA68 a momentary or maintained pushbutton?
Maintained. The two mushroom-head buttons are mechanically interlocked, so pressing one latches it in and releases the other. That's the arrangement you want for a start/stop or forward/reverse station where the selection has to stay put, not a momentary jog button.
2) Can this B-Line heavy-duty operator go in a washdown or outdoor enclosure?
Yes. The 10250TA68 carries NEMA 3, 3R, 4, 4X, 12 and 13 ratings, which covers rain and outdoor use, hosedown, corrosion-resistant duty, and dust or oil in indoor industrial areas. Rating is only maintained when it's properly flush mounted in a correspondingly rated enclosure.
3) What do the two button colors on the 10250TA68 mean?
One actuator is black and one red, the conventional pairing for run/off or start/stop on a machine control station. Both are plastic mushroom heads, mechanically interlocked so only one can be depressed at a time.
4) Will the 10250TA68 match the other 10250T pushbuttons already in my plant?
It's part of the same 10250T heavy-duty 30.5 mm family, so it uses the same panel cutout and the same chrome bezel look as the other 10250T devices on your line. That makes it straightforward to standardize a facility on one operator series and one spares kit.
5) Is the 10250TA68 pushbutton lighted?
No, it's non-illuminated. There is no lamp or transformer module involved, so if the panel needs an indicating pilot light you'll need a separate 30.5 mm indicating light.
6) Is the exact part number 10250TA68 and who makes it?
B-Line 10250TA68 is the manufacturer part number, a 30.5 mm heavy-duty pushbutton operator in the 10250T series. Order by that number; there is no finish or size option to specify.
