31/2 IN DPAKCBODYW/CV & GASKET
Manufacturer Resources
Product Specs
- Application:
- For Use with Rigid/IMC Conduit
- Number Of Batteries:
- 0
- Product Group:
- Conduit & Fittings
- Product Type:
- Conduit Body - Series A - Rigid/IMC
- Department:
- Electrical
- Product Subgroup:
- Conduit Bodies
- Product Material:
- Aluminum Die Cast
Red Dot DAC-9-CG – Frequently Asked Questions
1) Will the Red Dot DAC-9-CG conduit body work with rigid conduit, or is it only for EMT?
The DAC-9-CG is built for rigid and IMC conduit, with threaded hubs. It is not an EMT fitting, so if your run is thin-wall EMT you need a set-screw or compression style conduit body instead.
2) Does the DAC-9-CG come with a cover and gasket, or do I order those separately?
Cover and gasket are included with the DAC-9-CG, so it ships complete as a pull point. You do not need to add a separate cover kit to close it up.
3) Is a Series A conduit body like the Red Dot DAC-9-CG suitable for an outdoor or wet location run?
It is a die cast aluminum body supplied with a gasketed cover, which is the configuration used for outdoor and damp-location rigid conduit pulls. The gasket seals the cover to the body when it's torqued down evenly. Aluminum also means you should avoid direct contact with concrete or corrosive soil without protection.
4) Can I mix the aluminum Red Dot DAC-9-CG with galvanized rigid steel conduit?
Yes, aluminum conduit bodies are routinely threaded onto galvanized rigid steel. The DAC-9-CG body is aluminum die cast; use an approved joint compound on the threads in wet or corrosive locations to limit dissimilar metal corrosion.
5) Should I use a conduit body here or a pull box for a 3-1/2 inch rigid run?
A Series A body like the DAC-9-CG is for changing direction or getting a pull point on the conduit itself, threaded inline, with a removable gasketed cover for access. Once you need multiple conduits entering from different directions, or conductor bending space beyond what a body gives, a junction or pull box is the right call instead.
