3/4 IN 90 DEG ELBOW M-F ALUM
Manufacturer Resources
Product Specs
- Customs Tariff Number:
- 7609000000
- Number Of Batteries:
- 0
- Package Level 2 Depth Length:
- 9.4 in239 mm
- Package Level 2 Height:
- 6 in152 mm
- Package Level 2 Units:
- 10 piece
- Package Level 2 Width:
- 6.9 in175 mm
- Product Group:
- Conduit & Fittings
- Product Type:
- Rigid and Intermediate Metal Conduit Fittings
- Department:
- Electrical
- Product Subgroup:
- Conduit Elbows
- Product Material:
- Malleable Iron
Thomas & Betts CHEL296SA – Frequently Asked Questions
1) Is the Thomas & Betts CHEL296SA elbow male on one end and female on the other?
Yes. The CHEL296SA is a male-female 90 degree elbow in 3/4 inch trade size, so it threads onto the end of a run of conduit on the male side and accepts a threaded conduit end on the female side. That lets you turn a corner without needing a coupling at the joint, unlike a female-female elbow.
2) What size and type of conduit does the CHEL296SA 90 degree elbow fit?
It is sized for 3/4 inch trade size conduit and is a rigid and intermediate metal conduit (RMC/IMC) fitting, so it mates with standard threaded 3/4 inch rigid or IMC. It is not intended for EMT, which is unthreaded and uses set screw or compression fittings instead.
3) Should I use a 90 degree male-female elbow or a factory conduit sweep on a 3/4 inch rigid run?
A short-radius fitting like the CHEL296SA turns the corner in a tight space, which is what you want at a box, a wall penetration, or where a large-radius bend will not fit. Because it is a sharp 90, it is not a pulling-friendly bend, so for long pulls or conductors with a minimum bend radius use a factory sweep or a field bend instead. The CHEL296SA is threaded male-female in 3/4 inch, so it drops into an existing threaded rigid or IMC run without re-threading.
4) What is the exact part number to order for the Thomas & Betts 3/4 inch male-female 90 degree elbow?
Order it as Thomas & Betts CHEL296SA. That is the single catalog number covering the 3/4 inch 90 degree male-female conduit elbow, so there are no finish or size options to specify.
5) How many CHEL296SA elbows come in a box?
The standard carton holds 10 pieces, so shops stocking for multi-run jobs are buying in tens rather than singles.
6) What are the carton dimensions for a box of 3/4 inch CHEL296SA elbows?
The 10-piece carton measures 9.4 in (239 mm) deep, 6.9 in (175 mm) wide and 6 in (152 mm) high, which is useful if you are planning van stock or shelf space for a standardized fitting kit.
