3/4X1/8 GALV MI REDUCER
Manufacturer Resources
Product Specs
- Dimensions Specification:
- ASME B16.3
- End Conn Size 1:
- FPT
- End Conn Size 2:
- FPT
- Finish Specification:
- ASTM A-153
- Material Specification:
- ASTM A-197
- Pressure Rating Specification:
- ASME B16.3
- Size 1:
- 0.75
- Size 2:
- 0.125
- Strength:
- STD
- Thread Specification:
- ASME B1.20.1
- Ul Fm:
- Yes
- Department:
- Plumbing
- Product Group:
- Pipe Fittings
- Product Subgroup:
- Reducers
- Product Type:
- Reducer
- Product Finish:
- Galvanized
- Product Material:
- Malleable Iron
- Product Weight:
- 0.25 lbs
ASC Engineered Solutions 311086607 – Frequently Asked Questions
1) What size pipe does the ASC 3/4 x 1/8 galvanized malleable iron reducer connect?
It bushes 3/4 inch down to 1/8 inch, with female pipe thread on both ends. That is a big step down in one fitting, so it's typically used to pick up a gauge, sensor, or small drain line off a 3/4 inch port.
2) Are the threads on this galvanized reducer standard NPT?
Yes, both ends are cut to ASME B1.20.1, which is the standard NPT taper thread spec, and both are female (FPT). It will thread onto any male NPT pipe nipple or fitting of the matching size with pipe dope or PTFE tape.
3) Is this galvanized malleable iron reducer UL/FM approved for fire sprinkler work?
It carries a UL/FM listing, so it can be used on fire protection piping where the AHJ requires listed fittings. Class and pressure rating follow ASME B16.3 at standard strength.
4) Can I use a galvanized malleable iron reducer on a steam or compressed air line?
Malleable iron threaded fittings to ASME B16.3 are rated for steam, air, gas, oil and water service within the class limits for their size and temperature. This one is standard (Class 150) strength, so check the B16.3 rating table against your operating pressure and temperature before you set it.
5) Will a galvanized fitting hold up outdoors or in a wet pit?
The galvanizing is hot dip to ASTM A-153, which is the heavy coating spec for threaded hardware, not a thin electroplate. That makes it suitable for damp, buried-box, and exterior exposure where a black iron fitting would rust out. Pair it with galvanized pipe so you aren't mixing coatings at the joint.
6) Will this reducer match the dimensions on my piping drawing?
Its lay length and body dimensions follow ASME B16.3, the dimensional standard for threaded malleable iron fittings, so it will drop into a takeoff figured from that standard. Material is ASTM A-197 malleable iron.
7) What is the part number and weight on the ASC 3/4 x 1/8 galvanized reducer?
Order by MPN 311086607 from ASC Engineered Solutions. It weighs a quarter pound, so a box of them adds little to a job kit.
