Metallics JRM130SLT 3/8-16 x 3...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$96.43
Metallics JRM130SLT 3/8-16 x 3 in. Round Head Slotted Machine Screws - Steel Zinc - 50qty

Metallics JRM130SLT 3/8-16 x 3 in. Round Head Slotted Machine Screws - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JRM130SLT
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$96.43
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
3/8-16 x 3 in. Round Head Slotted Machine Screws - Steel Zinc - 50qty

  • Features

    • Round head with slotted Drive
    • Steel Zinc Material
    • 3/8-16 Diameter, 3" Length

  • Additional Notes

    • In 1985, Metallics was the first fastener company in America to offer a full line of Combo’s! | Other sizes and quantities available by request | Tensile strength values for stainless screws are offered as approximations only; there is no single standard for the performance requirements of stainless machine screws.

Manufacturer Resources

Product Specs

Minimum Purchase:
50 units
Arra Compliant:
C
Buy American Compliant:
C
Division:
Electrical H1
Drive Type:
Slotted
Fastener Head Height:
0.237 - 0.256 in.
Fastener Head Type:
Round
Fastener Head Width:
0.67 - 0.708 in.
Fastener Length:
3
Hardness:
Rockwell B70-B100
Language Code:
EN
Material Standard:
AISI 1006 - 1022
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Round_Head_Machine_Screw.pdf
Order Minimum Imperial:
50
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Product Group:
Fasteners
Product Height:
7.25 in
Product Length:
4.5 in
Product Weight:
4.34 lbs
Product Width:
4.5 in
Recess Penetration Gaging Depth:
0.182 - 0.208
Slot Depth:
0.117 - 0.155
Slot Width:
0.081 - 0.094
Sub Division:
Electrical-E H2
Tensile Strength:
60000 psi minimum
Thread Per Inch:
16
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Machine Screw
Type2:
Machine Screw
Series:
JRM
Product Finish:
Zinc
Product Details:
Machine Screw
Product Material:
Steel Zinc

Metallics JRM130SLT – Frequently Asked Questions

1) How many screws come in a jar of Metallics JRM130SLT machine screws?
The JRM130SLT ships 50 pieces to a jar, and 50 count is the order minimum. Jar weight works out to 4.34 lbs for the pack, so plan on that if you're carrying a few up a ladder or stocking a van bin.
2) Will a 3/8-16 x 3 in. round head machine screw thread into a standard 3/8-16 strut nut or tapped channel?
Yes. The JRM130SLT is cut 3/8-16, meaning 3/8 inch nominal diameter at 16 threads per inch, which is the standard UNC coarse pitch for that diameter. It mates with any 3/8-16 tapped hole, channel nut, or hex nut. At 3 inches of length you get plenty of reach for stacking a bracket and washers before the nut.
3) Are these zinc plated steel screws OK for outdoor or damp locations?
Zinc plating over carbon steel gives moderate corrosion resistance, which suits dry interior electrical work, panel and enclosure assembly, and covered locations. For direct weather exposure, wet wells, coastal air, or chemical exposure, go with a stainless machine screw instead. The base material here is low carbon steel per AISI 1006 to 1022 with a zinc finish, not stainless.
4) Do these machine screws meet Buy American or ARRA requirements for a public project?
The JRM130SLT is flagged compliant for both ARRA and Buy American in the product record, with China listed as country of origin. If your contract carries a strict domestic end product clause, submit those two data points to the specifying authority before you install, since compliance programs differ on what they accept.
5) Can I get the same 3/8-16 x 3 in. round head screw in a different quantity or a Phillips drive?
The JRM130SLT is the slotted drive version, sold 50 to a jar. Metallics notes that other sizes and quantities in the round head machine screw line are available by request, so if you need a larger bulk count or a different length in the same JRM family, ask for it rather than assuming the jar is the only option. For a Phillips or combo head you'd be looking at a different Metallics catalog number.
