3M Cable Tie 15 in Black Nylon 6/6 Standard Type with 50 lbs Tensile Strength

3M Cable Tie 15 in Black Nylon 6/6 Standard Type with 50 lbs Tensile Strength

Professional Cable Management with UL Listed Plenum Rating

The 3M Cable Tie delivers reliable wire bundling and harness component management with its 15 in length and robust 50 lbs tensile strength. Constructed from durable Nylon 6/6 material in black, this standard type cable tie features a curved tip for faster threading and installation. UL Listed 62275 Type 21 or 21S and Plenum Rated AH-2 for use in air handling spaces, ensuring compliance with professional installation requirements. Made in the USA with UV resistance for long-lasting performance.

Professional Features & Benefits

• 50 lbs Tensile Strength: Provides secure bundling capacity for demanding applications without slipping or failure under load.
• UL Listed 62275 Type 21/21S & Plenum Rated AH-2: Ensures code compliance for air handling spaces and professional electrical installations.
• Nylon 6/6 Construction: Delivers exceptional durability and chemical resistance for long-term reliability in various environments.
• 15 in Length with 4 Inch Maximum Bundle Diameter: Accommodates substantial wire bundles while maintaining secure fastening capability.
• Operating Temperature Range -40�F to 185�F: Performs reliably across extreme temperature conditions from cold storage to heated environments.
• UV Resistant & Made in USA: Provides fade resistance and quality manufacturing for professional-grade applications.
• Curved Tip Design: Enables faster threading and installation, reducing labor time and improving productivity.

Technical Specifications

• Cable Length Imperial: 15 in
• Cable Length Metric: 370.84 mm
• Cable Tie Base Height: 15 in
• Cable Tie Length: 371 mm
• Cable Tie Type: Standard
• Color Family Incorporate Product Color: Black
• Flammability Rating: UL 94 V-2
• Manufacturer Catalog Number: 7000031857
• Manufacturing Origin: USA
• Maximum Bundle Diameter: 4 Inch
• Maximum Bundle Diameter Metric: 102 mm
• Maximum Insulation Outer Diameter Metric: 3.7 mm
• Maximum Insulation Outside Diameter: 0.145 in
• Maximum Operating Temperature: 85 Degree Celsius
• Maximum Operating Temperature Celsius: 85 Degree Celsius
• Maximum Operating Temperature Fahrenheit: 185 Degree Fahrenheit
• Maximum Recommended Voltage Rating: 600 V
• Minimum Bundle Diameter: 0.0625 Inch
• Minimum Bundle Diameter Metric: 1.6 mm
• Minimum Installation Temperature Celsius: -20 Degree Celsius
• Minimum Installation Temperature Fahrenheit: -4 Degree Fahrenheit
• Minimum Operating Temperature Celsius: -40 Degree Celsius
• Minimum Operating Temperature Fahrenheit: -40 Degree Fahrenheit
• Operating Temperature Celsius: 85 Degree Celsius
• Operating Temperature Fahrenheit: 185 Degree Fahrenheit
• Operating Temperature Range Celsius: -40 �C to 85 �C
• Operating Temperature Range Fahrenheit: -40 �F to 185 �F
• Overall Length Imperial: 14.6 in
• Overall Length Metric: 371 mm
• Overall Width Imperial: 0.18 in
• Overall Width Metric: 4.6 mm
• Package Height: 0.50000 in
• Package Length: 19.00000 in
• Package Weight: 0.5200 LBS
• Plenum Rated: Yes
• Product Material: Nylon 6/6
• Product Type: Standard
• Tape Type: Barricade
• Tensile Strength Imperial: 50 lbs
• Tensile Strength Metric: 22.68 kg
• Uv Resistant: Yes

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Electrical Panel Wire Management
• HVAC System Cable Organization
• Data Center Infrastructure
• Commercial Building Installations
• Industrial Equipment Harnesses
• Plenum Space Applications
• Telecommunications Installations

Why Choose 3M Quality?

3M cable ties deliver proven reliability with UL Listed certification and plenum rating compliance for professional installations. The UV resistant Nylon 6/6 construction and Made in USA manufacturing ensure consistent performance and durability. With UL 94 V-2 flammability rating and 600 V voltage rating, these cable ties meet stringent safety standards for demanding electrical applications.
