3M Heat Shrink Thin-Wall Tubing FP-301, 48" Black

3M Heat Shrink Thin-Wall Tubing FP-301, 48" Black

(No reviews yet) Write a Review

Model: 7000133543

In Stock (leaves warehouse same day if ordered before 3pm ET)

$5.12
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
3M™ Heat Shrink Thin-Wall Tubing FP-301-3/16-48"-Black-Hdr-25 Pcs, 48 in Length sticks with header label, 25 pieces/case

  • Features

    • A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
    • FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
    • HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
    • KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
    • FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)


7000133546 - spec sheet

Product Specs

Tensile Strength Imperial:
2400 Pound-Force Per Square Inch
Shelf Life:
3600
Department:
Electrical
Ul Bug Temperature Celsius:
125 Degrees Celsius
Manufacturing Origin:
USA
Country Of Origin:
United States
Overall Length Imperial:
48.0 in
Flammability Rating:
UL 224 All Tubing Flame Test
Etim Class 7 0:
EC000217
Flame Retardant:
Yes
Maximum Operating Temperature Celsius:
135
Minimum Shrink Temperature Celsius:
100
Shrink Ratio:
2:01
Non Corrosive:
Yes
Solution For:
Access Network: FTTH/FTTB/CATV
Operating Temperature Range Celsius:
-55 °C to +135 °C
Rohs Eu Comments:
RoHS 2011/65/EU compliant without exemption
Maximum Operating Temperature Celsius Uom:
Degree
Maximum Operating Temperature Fahrenheit:
275.0 Degree
Etim Class 8 0:
EC000217
Tubing Type:
Single Wall (Thin)
Mil Spec:
SAE-AMS-DTL-23053/5, Class 1
Operating Temperature Range Fahrenheit:
-67 °F to 275 °F
Ul Approval:
Yes
Ul Bug Temperature Fahrenheit:
257 Degrees Fahrenheit
Product Color:
Black
Elongation Uom:
%
Operating Temperature Fahrenheit:
-67 °F to 275 °F
Product Material:
Polyolefin
Ul Bug Voltage:
600 Volt
Operating Temperature Celsius:
-55 to 135 Degrees Celsius
Heat Shrink Type:
Single-Wall Polyolefin Heat Shrink Tubing
Product Type:
Heat Shrink Tubing
Product Group:
Cable Management & Identification
Product Subgroup:
Electrical Sleeves

3M 7000133543 – Frequently Asked Questions

1) What size wire will 3M FP-301 heat shrink tubing cover, and how much does it shrink down?
FP-301 is a 2:1 shrink ratio tubing, so each size recovers to roughly half its supplied inside diameter. Pick the size that slides over the largest point of the splice or connector and still shrinks tight on the bare wire. Supplied diameters run 1/8, 3/16, 1/4, 3/8, 1/2, 3/4, 1 and 1-1/2 inch, all in black and all in 48 inch sticks.
2) What temperature do I need to hit to shrink FP-301 tubing, and how hot can it get in service?
Minimum shrink temperature is 100 C, so a standard electric heat gun does the job. Once installed, the polyolefin tubing holds a continuous operating range of -67 F to 275 F (-55 C to +135 C), which covers engine compartments, outdoor runs and cold storage.
3) Is 3M FP-301 heat shrink UL listed for 600 volt work?
Yes. The UL bug on FP-301 reads 600 V at 125 C, and the product is UL Listed under File E-39100. That covers the great majority of commercial and industrial building wiring insulation repairs.
4) Should I use thin-wall tubing like FP-301 or a dual-wall adhesive-lined tubing?
FP-301 is single-wall thin-wall polyolefin. It insulates, bundles, marks and strain-relieves, but there is no adhesive liner inside, so it does not seal out moisture on its own. For direct-burial splices, outdoor drop connections or anywhere water intrusion is the concern, choose an adhesive-lined dual-wall tubing instead. For panel wiring, harnessing and general wire marking, thin-wall is the lighter and lower-profile choice.
5) Does 3M FP-301 black tubing meet military spec for wire harness work?
The black FP-301 is built to SAE-AMS-DTL-23053/5, Class 1, which is the flexible polyolefin heat shrink spec used on military and aerospace harnesses. Class 1 is the flame retardant class; note that only the clear version of FP-301 falls under Class 2 and is not flame retardant.
6) Is this heat shrink flame retardant, and which flame test does it pass?
Black FP-301 is flame retardant and is tested to the UL 224 all-tubing flame test. It is also non-corrosive, so it will not attack copper conductors or terminal plating over time.
7) Is 3M FP-301 heat shrink RoHS compliant and where is it made?
FP-301 is RoHS 2011/65/EU compliant without exemption and is manufactured in the United States. Both points matter on government, healthcare and institutional purchase orders that carry domestic-origin or restricted-substance language.
8) Will FP-301 tubing hold up as strain relief on a wire harness, or will it split?
Tensile strength is 2400 psi, and the tubing is used for wire harnessing, split-resistant covering, wire bundling and component packaging. It gives mechanical abrasion protection and strain relief at a cable exit, though it is not a substitute for a molded boot on a high-flex application.
9) Can 3M FP-301 be used on fiber and coax drops in an FTTH or CATV build?
Yes, FP-301 is listed as a solution for access network work including FTTH, FTTB and CATV. The 1/8 and 3/16 inch sizes handle jacketed drop and jumper protection; step up to 1/2 inch or larger for bundled runs and connector bodies.
