3M H-31-POUCH 3M, Highland, Wire Connector H-31-POUCH, 18-14 AWG, Orange, 100 perPouch

3M H-31-POUCH 3M, Highland, Wire Connector H-31-POUCH, 18-14 AWG, Orange, 100 perPouch, 100 Pack

(No reviews yet) Write a Review

Model: H-31-POUCH
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.27
$30.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
3M, Highland, Wire Connector H-31-POUCH, 18-14 AWG, Orange, 100 perPouch

  • Features

    • Available in hand driver or power driver options
    • Used for connecting and insulating wire connections in a pigtail application
    • Suitable for select 3M, Peformance Plus, Wire Connectors and 3M, Secure Grip Wire Connectors


H-31-POUCH - spec sheet

Manufacturer Resources

Product Specs

Color Family Incorporate Product Color:
Orange
Connection Type:
Wire
Connector Style:
Twist On
Flame Retardant:
No
Manufacturer Catalog Number:
7010348891
Maximum Conductor Size:
14 AWG
Maximum Recommended Voltage Rating:
600 V
Maximum Wire Gauge:
14 AWG
Minimum Conductor Size:
18 AWG
Minimum Wire Gauge:
18 AWG
Package Height:
7.87000 in
Package Length:
4.72000 in
Package Weight:
0.4610 LBS
Wire Connector Type:
Twist-on Wire Connectors
Wire Size:
Twist-on Wire Connectors
Department:
Electrical
Product Subgroup:
Wire Connectors
Product Type:
Twist-On Wire Connector
Product Group:
Wire Connectors & Terminals

3M H-31-POUCH – Frequently Asked Questions

1) What wire sizes does the 3M Highland H-31 orange wire connector handle?
The orange Highland H-31 twist-on connector is rated for 18 to 14 AWG conductors. That covers the common combinations on 15-amp branch circuits and low-voltage control wiring. Anything heavier than 14 AWG, such as 12 AWG on a 20-amp circuit, needs a larger connector.
2) Can I use the H-31 orange wire nut on a 277V or 480V lighting circuit?
The H-31 carries a maximum recommended voltage rating of 600 V, so 277 V lighting and 480 V control circuits are inside its rating. The limiting factor is wire size, not voltage: it only takes 18 to 14 AWG.
3) Is the 3M H-31 wire connector flame retardant?
No. The Highland H-31 is not a flame retardant connector. If your spec or facility standard calls for a flame retardant shell, such as in a plenum or a job where the electrical spec names it, choose a different connector.
4) How many wire nuts come in a pouch of 3M H-31-POUCH?
Each pouch holds 100 orange H-31 connectors. The pouch format is meant for stocking a van or a tool pouch rather than a bin, which is why it ships flat at 7.87 by 4.72 inches and about 0.461 pounds.
5) Are these push-in connectors or do you twist them on?
Twist-on. The H-31 is a twist-on wire connector, applied by hand or with a driver over a pigtail splice, and it both connects and insulates the joint. It is not a push-in or lever style connector, so the conductors are twisted and capped rather than inserted into ports.
6) What does the orange color mean on a wire nut like the H-31?
On the 3M Highland line, orange marks the 18 to 14 AWG range, so an electrician can size the splice at a glance without reading the box. Check the AWG range rather than the color alone when mixing brands, since color coding is not uniform across every manufacturer.
7) What is the manufacturer part number to order the orange 100-count Highland pouch?
Order it as 3M H-31-POUCH. 3M also catalogs it under number 7010348891, and the pouch carries UPC 054007431176.
8) Can I drive the H-31 wire connectors with a power tool instead of by hand?
Yes. The H-31 can be run with a hand driver or a power driver, which matters on a large rough-in or a multi-family job where a crew is making hundreds of splices. Same connector either way.
