3M ScotchCode Wire Marker Tape...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$59.74
$10.51
3M SDR-4 3M, ScotchCode, Wire Marker Tape Refill Roll SDR-4

3M ScotchCode Wire Marker Tape Refill Roll Number 4 White Acrylic Adhesive -40�F to 250�F

(No reviews yet) Write a Review

Model: SDR-4
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$59.74
$10.51
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

3M ScotchCode Wire Marker Tape Refill Roll Number 4

Professional Wire and Cable Identification Solution

3M ScotchCode Wire Marker Tape Refill Roll Number 4 delivers reliable wire and cable marking with high-tack acrylic adhesive that resists solvents, oil and water. This white pre-printed tape roll provides clear number 4 identification for professional electrical applications, operating effectively in temperatures from -40�F to 250�F with firm adhesion to insulation surfaces.

Professional Features & Benefits

  • High-Tack Acrylic Adhesive: Resists solvents, oil and water while adhering firmly to insulation surfaces for long-lasting identification
  • Wide Temperature Range: Operates reliably from -40�F (-40�C) to 250�F (121�C) for diverse environmental conditions
  • Pre-Printed Number 4: Clear white legend on white tape provides consistent, professional wire identification
  • Dispenser Compatible: Tape roll refill design works with wire marker tape dispensers for efficient application
  • Low Voltage Application: Specifically designed for safe use in low voltage electrical systems
  • USA Manufacturing: Made in USA with consistent 3M quality standards
  • Precise Dimensions: 5.46 mm width and 2.4 m length provide optimal coverage for wire marking applications

Technical Specifications

  • Adhesive Material: Acrylic
  • Application: Marking Wire and Cable
  • Color Family Incorporate Product Color: White
  • Dispenser Marker Type: Tape Roll Refill
  • Legend: 4
  • Legend Color: White
  • Manufacturer Catalog Number: 7000058258
  • Manufacturing Origin: USA
  • Marker Id Style: Pre-printed
  • Marker Type: Dispenser
  • Maximum Operating Temperature Celsius: 121 Degree Celsius
  • Maximum Operating Temperature Fahrenheit: 250 Degree Fahrenheit
  • Overall Length Metric: 2.4 m
  • Overall Width Metric: 5.46 mm
  • Package Height: 3.62500 in
  • Package Length: 0.93800 in
  • Package Weight: 0.0700 LBS
  • Printed Text Type: Number - 4
  • Tape Color: White
  • Uv Resistant: No
  • Voltage Application: Low Voltage
  • With A Protective Shoe: Wire Marker Tape Dispenser and Refill Rolls

Professional Applications

  • Electrical Panel Wire Identification
  • Control Cabinet Wiring
  • Industrial Equipment Marking
  • Commercial Building Systems
  • Maintenance and Service Documentation
  • Low Voltage System Organization
  • Professional Electrical Installations

Why Choose 3M Quality?

3M ScotchCode wire marker tapes provide professional-grade identification solutions with proven acrylic adhesive technology and USA manufacturing quality. The wide operating temperature range from -40�F to 250�F ensures reliable performance across diverse electrical environments, while the solvent, oil and water resistant adhesive maintains clear identification over time.

Manufacturer Resources

Product Specs

Adhesive Material:
Acrylic
Application:
Marking Wire and Cable
Color Family Incorporate Product Color :
White
Dispenser Marker Type:
Tape Roll Refill
Legend:
4
Legend Color:
White
Manufacturer Catalog Number:
7000058258
Manufacturing Origin:
USA
Marker Id Style:
Pre-printed
Marker Type:
Dispenser
Maximum Operating Temperature Celsius :
121 Degree Celsius
Maximum Operating Temperature Fahrenheit :
250 Degree Fahrenheit
Overall Length Metric :
2.4 m
Overall Width Metric :
5.46 mm
Package Height:
3.62500 in
Package Length:
0.93800 in
Package Weight:
0.0700 LBS
Printed Text Type:
Number - 4
Tape Color:
White
Uv Resistant:
No
Voltage Application:
Low Voltage
With A Protective Shoe:
Wire Marker Tape Dispenser and Refill Rolls
Department:
Electrical

3M SDR-4 – Frequently Asked Questions

1) Does the 3M ScotchCode SDR-4 refill roll fit a ScotchCode wire marker tape dispenser?
Yes. The SDR-4 is a tape roll refill built for 3M ScotchCode wire marker tape dispensers, so you drop it into the dispenser rather than peeling markers off a card. The tape is 5.46 mm wide and the roll holds 2.4 m of length, which is the standard cartridge format for those dispensers.
2) Will 3M ScotchCode wire marker tape hold up in a hot control cabinet or an unheated outdoor enclosure?
The tape runs from -40 F (-40 C) up to 250 F (121 C), which covers a hot motor control cabinet as well as an unheated northern mechanical room. The adhesive is acrylic and resists solvents, oil and water, so it stays put on insulation in machine shops and plant environments.
3) Can I use this wire marker tape on conductors in an outdoor or sunlit location?
Not where it will sit in direct sunlight. The SDR-4 tape is not UV resistant, so keep it to indoor panels, control cabinets, junction boxes and covered enclosures. For exposed outdoor runs, choose a marker rated for UV exposure instead.
4) Is 3M ScotchCode SDR-4 marker tape rated for medium or high voltage conductors?
No. It is specified for low voltage applications only, so use it on control wiring, branch circuits, panel conductors and signal cable. For medium or high voltage terminations you need a marking system rated for that class.
5) What is the 3M part number for the ScotchCode number 4 refill roll?
Order it as 3M SDR-4. The manufacturer catalog number on record is 7000058258, and it is made in the USA. Contractors and MRO buyers standardizing a panel typically order the full digit range under the same SDR prefix.
6) How many wires will one roll of 3M SDR-4 marker tape mark?
The roll carries 2.4 m of tape at 5.46 mm wide. How far that goes depends on how many wraps you take per conductor, which is driven by wire gauge, so a roll goes noticeably further on small control wire than on larger branch-circuit conductors. For a full panel legend, buy a roll for each digit you intend to use.
7) Is 3M ScotchCode tape a write-on marker or already printed?
Already printed. The legend is factory pre-printed, so there is nothing to write and nothing to smudge. If you need custom text such as circuit names or terminal IDs, a write-on or printable marker system is the right choice rather than a pre-printed digit roll.
