3M SDR-6 3M, ScotchCode, Wire Marker Tape Refill Roll SDR-6

3M ScotchCode Wire Marker Tape Refill Roll Number 6 White Acrylic Adhesive -40�F to 250�F

(No reviews yet) Write a Review

Model: SDR-6
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$59.74
$10.51
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

3M ScotchCode Wire Marker Tape Refill Roll Number 6

Professional Wire and Cable Identification Solution

3M ScotchCode Wire Marker Tape Refill Roll Number 6 delivers reliable wire and cable marking for professional electrical applications. This white tape refill features pre-printed number 6 legend with high-tack acrylic adhesive designed for operating temperatures from -40�F to 250�F, ensuring durable identification in demanding environments.

Professional Features & Benefits

  • Wide Temperature Range (-40�F to 250�F): Maintains adhesion and legibility in extreme temperature conditions for versatile application environments.
  • High-Tack Acrylic Adhesive: Resists solvents, oil and water while adhering firmly to insulation surfaces for long-lasting identification.
  • Pre-Printed Number 6 Legend: Provides clear, consistent wire identification with professional white-on-white marking for easy visibility.
  • Dispenser Compatible Design: Tape roll refill format integrates seamlessly with 3M ScotchCode dispensers for efficient application.
  • Low Voltage Application Rated: Specifically designed for safe use in low voltage electrical systems and installations.
  • USA Manufacturing: Manufactured in USA ensuring consistent quality and reliable supply chain for professional contractors.

Technical Specifications

  • Adhesive Material: Acrylic
  • Application: Marking Wire and Cable
  • Color Family Incorporate Product Color: White
  • Dispenser Marker Type: Tape Roll Refill
  • Legend: 6
  • Legend Color: White
  • Manufacturer Catalog Number: 7000058260
  • Manufacturing Origin: USA
  • Marker Id Style: Pre-printed
  • Marker Type: Dispenser
  • Maximum Operating Temperature Celsius: 121 Degree Celsius
  • Maximum Operating Temperature Fahrenheit: 250 Degree Fahrenheit
  • Overall Length Metric: 2.4 m
  • Overall Width Metric: 5.46 mm
  • Package Height: 3.62500 in
  • Package Length: 0.93800 in
  • Package Weight: 0.0700 LBS
  • Printed Text Type: Number - 6
  • Tape Color: White
  • Uv Resistant: No
  • Voltage Application: Low Voltage
  • With A Protective Shoe: Wire Marker Tape Dispenser and Refill Rolls

Professional Applications

  • Electrical Panel Wire Identification
  • Control Cabinet Wiring Systems
  • Industrial Equipment Wire Marking
  • Commercial Building Electrical Systems
  • Maintenance and Retrofit Projects
  • Low Voltage Control Circuits
  • Professional Electrical Installations

Why Choose 3M Quality?

3M ScotchCode wire marker tapes provide professional-grade identification solutions with proven acrylic adhesive technology and USA manufacturing quality. The extreme temperature rating from -40�F to 250�F ensures reliable performance across diverse installation environments, while the solvent, oil and water resistant adhesive delivers long-term durability for critical wire identification applications.

Manufacturer Resources

Product Specs

Adhesive Material:
Acrylic
Application:
Marking Wire and Cable
Color Family Incorporate Product Color :
White
Dispenser Marker Type:
Tape Roll Refill
Legend:
6
Legend Color:
White
Manufacturer Catalog Number:
7000058260
Manufacturing Origin:
USA
Marker Id Style:
Pre-printed
Marker Type:
Dispenser
Maximum Operating Temperature Celsius :
121 Degree Celsius
Maximum Operating Temperature Fahrenheit :
250 Degree Fahrenheit
Overall Length Metric :
2.4 m
Overall Width Metric :
5.46 mm
Package Height:
3.62500 in
Package Length:
0.93800 in
Package Weight:
0.0700 LBS
Printed Text Type:
Number - 6
Tape Color:
White
Uv Resistant:
No
Voltage Application:
Low Voltage
With A Protective Shoe:
Wire Marker Tape Dispenser and Refill Rolls
Department:
Electrical

3M SDR-6 – Frequently Asked Questions

1) Does the 3M ScotchCode SDR-6 refill roll fit a ScotchCode wire marker tape dispenser?
Yes. The SDR-6 is a tape roll refill made for the 3M ScotchCode wire marker tape dispenser system, so it drops into the dispenser body rather than being applied off the roll by hand. The tape itself runs 2.4 m long and 5.46 mm wide.
2) Does the SDR-6 roll print more than one number, or is it only the digit 6?
Only the digit 6. The SDR-6 is pre-printed with a single repeating legend, so numbering a multi-conductor run means stocking a separate refill roll for each digit you need. Electricians building out a panel legend typically carry the full 0 through 9 set plus the letter rolls.
3) Can I use ScotchCode SDR-6 wire markers outdoors in direct sun?
No, not for sustained sun exposure. The SDR-6 tape is not UV resistant, so outdoor or daylit runs will degrade the marker over time. Keep it to panels, control cabinets, and other enclosed or indoor work. Temperature is not the limiting factor here, it handles -40 F up to 250 F (121 C).
4) Will ScotchCode marker tape hold up on wire in a hot motor control cabinet?
Up to 250 F (121 C) it will. The acrylic adhesive on the SDR-6 is a high-tack formulation that resists solvents, oil, and water, which is what keeps it on the insulation in machine rooms and industrial enclosures where cutting oil and cleaners get on the conductors.
5) Is the number on the SDR-6 tape white on white? How do you read it?
The tape is white and the printed legend is also white, so the digit reads as a subtle relief against the tape rather than as a high-contrast black-on-white marker. If your spec or facility standard calls for high-contrast legend colors, this is not the roll to buy.
6) Is 3M ScotchCode SDR-6 tape rated for line voltage branch circuits?
It is specified for low voltage applications, which covers control circuits, signal and instrumentation wiring, and similar low voltage systems. Use it for identifying conductors in those systems rather than as any kind of insulating or voltage-rated wrap.
7) What part number do I order for the 3M ScotchCode number 6 tape refill?
Order model SDR-6. The corresponding 3M catalog number is 7000058260. It is made in the USA.
8) How many wires will one SDR-6 refill roll mark?
Each roll carries 2.4 m of tape at 5.46 mm wide, so the count depends on how much length you tear off per conductor. On typical small-gauge control wire where a marker wrap takes an inch or two, one roll covers dozens of conductors. For a large panel build, buy spares of the digits your circuit numbering uses most.
