Manufacturer Resources
Product Specs
- Amperage Rating:
- 100 Continuous Ampere
- Application:
- RV Power
- Brand Name:
- Milbank
- Bypass Provision:
- No Bypass
- Cable Entry:
- Underground
- Equipment Ground:
- 2 Barrel Ground Lug and Ground Bar
- Frequency Rating:
- 60 Hertz
- Height:
- 70 IN
- Hub Closing Plate:
- Plain Top
- Insulation:
- Glass Polyester
- Length:
- 9.438 IN
- Main Breaker Size:
- One Single Pole 20 Ampere Breaker and One Single Pole 30 Ampere Breaker and One Double Pole 50 Ampere Breaker
- Material:
- G90 Galvanized Steel with Powder Coat Finish
- Mounting:
- Pedestal
- Number Branch Circuits:
- 2
- Number Of Jaws:
- 4 Terminal
- Number Of Main Breakers:
- 3
- Number Of Meter Positions:
- Single Power Head
- Number Of Receptacles:
- 3
- Phase:
- 1 Phase
- Product Family Code:
- RVNM
- Receptacle Configuration:
- One NEMA 14-50 and One NEMA TT30 and One NEMA 5-20 Ground Fault
- Size:
- 9.438L x 8W x70H
- Special Features:
- Single Pole 20 Ampere Breaker and Single Pole 30 Ampere Breaker and Double Pole 50 Ampere Breaker
- Standard:
- UL Listed;Type 3R
- Terminal:
- Double Mechanical
- Type:
- Ring Type Meter Socket
- Unspsc Number:
- 39121102
- Voltage Rating:
- Up to 240 Volts Alternating Current
- Width:
- 8 IN
