4 Terminal Ringless Plain Top 520GR 620GB 520GR Surface Mount
Manufacturer Resources
Product Specs
- Amperage Rating:
- 100 Continuous Ampere
- Application:
- Temporary Power
- Brand Name:
- Milbank
- Bypass Provision:
- No Bypass
- Cable Entry:
- Underground
- Equipment Ground:
- Ground Bar
- Frequency Rating:
- 60 Hertz
- Height:
- 25.938 IN
- Hub Closing Plate:
- Plain Top
- Insulation:
- Glass Polyester
- Length:
- 5.188 IN
- Line Side Wire Range:
- 6 AWG - 350 kcmil
- Load Side Wire Range:
- 6 AWG - 350 kcmil
- Main Breaker Size:
- Breaker Provision
- Material:
- G90 Galvanized Steel with Powder Coat Finish
- Mounting:
- Surface Mount
- Number Branch Circuits:
- 6
- Number Of Jaws:
- 4 Terminal
- Number Of Main Breakers:
- 6
- Number Of Meter Positions:
- 1 Position
- Number Of Receptacles:
- 3
- Phase:
- 1 Phase
- Product Family Code:
- POMT
- Receptacle Configuration:
- Two NEMA 5-20 Ground Fault and One NEMA 6-20
- Size:
- 5.188L x 9W x 25.938H
- Standard:
- UL Listed;Type 3R
- Terminal:
- Lay in
- Type:
- Ringless Meter Socket
- Unspsc Number:
- 39121102
- Voltage Rating:
- Up to 240 Volts Alternating Current
- Width:
- 9 IN
