400 AL TP COMP LUG 1HL 5/8IN GRN
Manufacturer Resources
Product Specs
- Country Of Origin:
- Mexico (MX)
- Product Group:
- Wire Termination
- Product Type:
- Aluminum One-Hole Lug
- Selling Unit Of Measure:
- each
- Standards:
- UL E9809
- Stud Size:
- 5/8 in
- Sub Brand Label:
- Blackburn
- Type2:
- Cable or wire lug
- Voltage Rating:
- 35 kV
- Department:
- Electrical
- Product Subgroup:
- Lugs
- Product Color:
- Green
- Product Material:
- Aluminum
Blackburn ATL400-58 – Frequently Asked Questions
1) What wire size does the Blackburn ATL400-58 compression lug take?
The ATL400-58 is a 400 kcmil aluminum compression lug. The 400 in the part number is the conductor size it is die-crimped onto, and the green color code identifies that 400 kcmil die/lug combination on the crimp tool chart. It terminates one conductor per lug and is sold each.
2) Will this lug bolt to a 5/8 inch stud on my switchgear pad?
Yes. The ATL400-58 has a single bolt hole sized for a 5/8 inch stud, so it lands directly on a 5/8 inch bus stud or pad bolt. One hole means one bolt point, so it is not a two-hole NEMA-spaced pad lug; if your pad requires two-hole mounting for anti-rotation, you need a two-hole version instead.
3) Is this Blackburn lug rated for medium voltage work?
It carries a 35 kV voltage rating, which covers medium-voltage terminations up to 35 kV class as well as any 600 V application. It is UL listed under file E9809.
4) Can I use this aluminum lug on copper conductor?
The ATL400-58 is an aluminum-bodied compression lug. Aluminum compression barrels in the Blackburn AL series are dual-rated AL/CU only when the lug is marked as such, so treat this one as an aluminum-conductor lug and use a copper or AL9CU-marked barrel for 400 kcmil copper. Aluminum body on a copper pad is fine electrically as long as the connection is made with the correct hardware and an inhibitor.
5) Is this a compression lug or a mechanical set-screw lug?
Compression. The ATL400-58 is die-crimped onto the conductor with a hydraulic crimp tool, not tightened with a set screw. That means no re-torque maintenance and a sealed barrel, but you need the matching die for the green 400 kcmil range. If you want a terminal you can install with a hex key and no press, look at a mechanical set-screw lug instead.
6) Do I need anything else to complete the termination with this lug?
The lug itself is the only piece supplied. You provide the 5/8 inch bolt, nut, and washers for the pad, a hydraulic crimper with the die matching the green 400 kcmil code, and joint compound if you are landing aluminum. Heat shrink or tape over the barrel is job-specific and not included.
7) What is the correct Blackburn part number to order and how does it ship?
Order Blackburn ATL400-58. It is sold as a single lug, each, so a three-phase plus neutral termination needs four pieces. Country of origin is Mexico.
