Metallics JRMB62 6-32 x 3/4 in...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.57
$0.57
Metallics JRMB62 6-32 x 3/4 in. Round Head Slotted Machine Screws - Brass - 100qty

Metallics JRMB62 6-32 x 3/4 in. Round Head Slotted Machine Screws - Brass - Each

(No reviews yet) Write a Review

Model: JRMB62
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.57
$0.57
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
6-32 x 3/4 in. Round Head Slotted Machine Screws - Brass - 100qty

  • Additional Notes

    • Other sizes and quantities available by request | Tensile strength values for stainless screws are offered as approximations only; there is no single standard for the performance requirements of stainless machine screws.

  • Features

    • Brass Material
    • Round head with slotted Drive
    • 6-32 Diameter, 3/4" Length

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Country Of Origin:
MUL
Dimensional Standard:
ASME B18.6.3
Division:
Electrical H1
Drive Type:
Slotted
Fastener Head Height:
0.091 - 0.103 in.
Fastener Head Type:
Round
Fastener Head Width:
0.24 - 0.26 in.
Fastener Length:
4-Mar
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Round_Head_Machine_Screw.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Product Family:
Electrical Supplies
Product Group:
Fasteners
Product Height:
2.15 in
Product Length:
3 in
Product Weight:
0.37 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.045 - 0.073
Slot Depth:
0.051 - 0.068
Slot Width:
0.039 - 0.048
Sub Division:
Electrical-E H2
Thread Per Inch:
32
Thread Standard:
ANSI/ASME B1.1
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Machine Screw
Type2:
Machine Screw
Series:
JRMB
Product Details:
Machine Screw
Product Material:
Brass

Metallics JRMB62 – Frequently Asked Questions

1) Will a 6-32 x 3/4 in. brass machine screw thread into a standard electrical device box or plaster ring?
6-32 is the standard machine screw thread used for device mounting in outlet boxes, switch boxes and plaster rings, and the Metallics JRMB62 is cut 6-32 with 32 threads per inch to ANSI/ASME B1.1. At 3/4 inch long it gives extra reach where a mud ring, thick wall finish or stacked yokes push the device out from the box. If the device sits flush to the box, a shorter 6-32 is usually easier to start.
2) Do these brass screws meet Buy American or ARRA requirements for a federal job?
No. The JRMB62 brass machine screws are not Buy American compliant and are not ARRA compliant, and country of origin is listed as multiple. If your contract carries a domestic sourcing clause, these will not satisfy it.
3) Why choose brass machine screws instead of steel for electrical work?
Brass is non-ferrous and corrosion resistant, which is why it gets specified in damp locations, marine and utility work, and on fittings where a steel screw would rust and seize. The JRMB62 is solid brass through the head and threads. Trade-off is strength: brass is softer than steel, so don't overtorque it, and the slotted drive will cam the blade out of the slot before the screw takes much abuse.
4) How much does the round head stand off the surface once the screw is driven?
Head height is 0.091 to 0.103 inch, so the domed head sits just under a tenth of an inch proud of whatever it is clamping. That matters if a cover plate, enclosure door or bracket has to close over the fastener. Where you need the head flush or sub-flush, a round head is the wrong profile and a flat countersunk head in a chamfered hole is what you want.
5) Are these round head machine screws made to a recognized dimensional standard?
Yes, the head and drive geometry follows ASME B18.6.3, the standard covering inch-series machine screws, and the threads follow ANSI/ASME B1.1. That means the 6-32 thread will mate with any conforming 6-32 tapped hole or nut regardless of who made it, which is what a submittal reviewer is looking for.
6) How are Metallics JRMB62 brass machine screws packaged and what is the minimum order?
They come in a jar of 100, and 100 is the order minimum. The jar itself measures 3 in. by 3 in. by 2.15 in. and weighs 0.37 lbs filled, which is the size that suits a van shelf or a service cart rather than a bulk bin.
7) Can I use these for plumbing or HVAC work, or are they electrical only?
They are stocked as an electrical item but the intended field application covers the electrical, plumbing, heating and air conditioning trades. Any 6-32 tapped hole in those trades takes them. The one caution is mixed metals: brass against dissimilar metal in a wet location can set up galvanic corrosion, so match the fastener to the base material where moisture is present.
