Product Specs
- Accessory Device:
- No
- Cec T20:
- No
- Cri:
- >80
- Dimming:
- 0-10V
- Dlc:
- No
- Dlc Premium:
- Yes
- Energy Star:
- No
- Housing Color:
- Bronze
- Input Voltage:
- 120-277
- Led Module Included:
- No
- Legacy Equivalent:
- 320W MH
- Mounting Method:
- Wall
- Not Suitable For Sale In California:
- No
- Product Weight:
- 5.55 lbs
- Rated Life Hours:
- 50000
- Selectable Color Temperature:
- 3000/4000/5000
- Selectable Lumens Output:
- 10130/8700/6750
- Selectable Power:
- 75/60/45
- Sensor Type:
- Photocell
- T24 Ja8:
- No
- Ul:
- No
- Warranty Years:
- 5
- Wireless Control:
- No
- Product Nominal Size:
- Medium Housing
Keystone KT-WPLED75PS-M3-8CSB-VDIM – Frequently Asked Questions
1) What HID wall pack can I replace with the Keystone 75W LED wall pack?
The KT-WPLED75PS-M3-8CSB-VDIM is built as a replacement for a 320W metal halide wall pack. At its top setting it draws 75W and puts out 10,130 lumens, so you get the light level of the old HID head at a fraction of the load, with no ballast to maintain.
2) How do I set the wattage and color temperature on this Keystone Color Select wall pack?
It's field-selectable on both counts. Power switches between 75W, 60W and 45W, with matching output of 10,130, 8,700 or 6,750 lumens, and color temperature sets to 3000K, 4000K or 5000K. One fixture covers a warm entry door or a bright 5000K parking-lot wall, so a property manager can stock a single SKU and dial it in per opening at install.
3) Will this wall pack run on 277V, or do I need a separate model?
One fixture covers both. The KT-WPLED75PS accepts 120-277V input, so the same unit wires to 120V on a residential or small commercial panel and 277V off a 480/277 three-phase system in a warehouse or retail center. No voltage-specific ordering.
4) Does this wall pack turn itself on at dusk, or do I need a separate photocontrol?
A photocell is built in, so the fixture switches on at dark and off at daylight without a contactor, timeclock or external button photocontrol on the circuit. Wire it to a constant hot feed rather than a switched leg so the photocell can do its job.
5) Can I dim this LED wall pack from a building control system?
Yes, it's 0-10V dimmable, so it lands on a standard low-voltage dimming pair from a building management system, an occupancy/daylight controller or a 0-10V wall dimmer. That means pulling two control conductors along with the line voltage feed. There is no wireless control built in, so any scheduling or remote setback has to come through the 0-10V wiring.
6) What color is the housing and how heavy is this wall pack for mounting?
Bronze housing, 5.55 lbs, medium housing size. At that weight it mounts to a standard wall-mounted outdoor junction box without supplemental bracing, and the bronze finish is the usual match for existing HID wall packs on masonry, EIFS and brick facades.
7) Do I need to order LED modules or a driver separately for this wall pack?
No separate LED module is ordered with this one. The KT-WPLED75PS is a sealed, integrated LED wall pack, not a retrofit kit that goes into an existing HID housing, so you replace the whole head. It is also not an accessory device, meaning it's a complete luminaire rather than a component for another fixture. Rated life is 50,000 hours.
8) Is 75W enough for a loading dock or back-of-house exterior wall?
At the 75W setting the fixture delivers 10,130 lumens, matching what a 320W metal halide wall pack produced, which is the typical spec for loading docks, service drives and rear building walls. If it's an apartment breezeway or an entry door where 320W HID was overkill, step it down to 45W and 6,750 lumens rather than buying a smaller fixture.
9) What's the exact part number to order this Keystone adjustable wall pack?
Order Keystone KT-WPLED75PS-M3-8CSB-VDIM. That string decodes the fixture you're getting: 75W selectable power, medium housing, Color Select, bronze, with 0-10V dimming and an integral photocell. If you are standardizing a portfolio, that's the number to put on the spec so every building gets the same head.
