77317 Viega ProPress 90° elbow Smart Connect technology Copper, 1/2'' x 1/2''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2
- Country Of Origin:
- Made in USA
- Material Type:
- Copper
- Product Dimension:
- 1/2'' x 1/2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Elbows
- Product Type:
- Elbow
- Product Length:
- 0.957"
- Product Height:
- 1.976"
- Product Weight:
- 0.116 lbs
- Product Width:
- 1.976"
Viega 77317 – Frequently Asked Questions
1) Is the Viega 77317 ProPress elbow press on both ends, or does one end solder?
Both ends press. The 77317 is a P1 x P2 fitting, meaning press connection on both sides, so it goes on 1/2 inch copper tube with a press tool and jaw. There is no solder cup, no thread, and no torch work on either end.
2) What size copper tube does the Viega 77317 ProPress 90 degree elbow fit?
It takes 1/2 inch copper on both ends, an even 1/2 x 1/2 turn. The body itself is copper, so it is a like material joint on copper tube rather than a bronze or stainless adapter.
3) How much room do I need to fit a Viega 1/2 inch ProPress elbow in a tight wall cavity?
The 77317 measures 1.976 x 1.976 x 0.957 inches, so the fitting body itself is under two inches across the turn. Plan clearance beyond that for the press jaw to close around the collar, which needs more space than the fitting alone.
4) What does Smart Connect mean on a Viega ProPress fitting, and does it change how I install it?
Smart Connect is Viega's feature that lets water or air escape past the sealing element on a connection that has not been pressed, so an unpressed joint shows itself during pressure testing instead of hiding in a wall. It does not change the install: insert the 1/2 inch tube fully, mark the insertion depth, and press. It is a verification aid, not a substitute for pressing every joint.
5) Is the Viega 77317 elbow made in the USA for a Buy American job?
Yes, the 77317 ProPress elbow is listed as made in the USA, which is what a federally funded or public agency spec usually wants documented. The manufacturer part number to put on the submittal is 77317.
