78067 Viega ProPress coupling With stop Smart Connect technology Copper, 1-1/2'' x 1-1/2''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2
- Country Of Origin:
- Made In Germany
- Material Type:
- Copper
- Product Dimension:
- 1-1/2'' x 1-1/2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Couplings
- Product Type:
- Coupling
- Product Length:
- 2.122"
- Product Height:
- 2.122"
- Product Weight:
- 0.468 lbs
- Product Width:
- 2.992"
Viega 78067 – Frequently Asked Questions
1) What size copper pipe does the Viega 78067 ProPress coupling fit?
The Viega 78067 is a 1-1/2 inch by 1-1/2 inch press coupling, so it joins two lengths of 1-1/2 inch copper tube. Both ends are press ends (P1 x P2), nothing threaded or soldered.
2) What does "with stop" mean on a ProPress coupling, and when would I want one without a stop?
A coupling with a stop has an internal shoulder in the middle, so each pipe end butts against it and seats at a fixed insertion depth. That is what you want on a normal tube-to-tube joint because it sets your depth for you. A coupling without a stop (a slip or repair coupling) has no shoulder, so it can slide along an existing run, which is what you use to repair a cut section in place where you cannot pull the pipe apart. The Viega 78067 is the with-stop version, 1-1/2 inch on both ends.
3) Do I need a special press tool jaw for a 1-1/2 inch ProPress fitting?
Yes. Press jaws are size specific, so a 1-1/2 inch fitting needs 1-1/2 inch tooling. On larger ProPress sizes that is typically a press ring plus an actuator rather than a standard jaw. The coupling itself ships as the fitting only, with the sealing element already installed; no separate gasket, solder, or flux is needed.
4) What is Smart Connect on Viega press fittings and why does it matter on a job?
Smart Connect is a feature of the Viega sealing element that leaks deliberately at an unpressed connection during test, so a missed press shows up when you pressurize instead of after the walls are closed. On a 1-1/2 inch riser or main, that is the difference between finding the joint at test and finding it later. It is built into the 78067 coupling, not an add-on.
5) How much room do I need around the pipe to press the Viega 78067?
The fitting body itself measures 2.122 x 2.122 x 2.992 inches, so plan clearance for the press ring around that envelope, not just the pipe OD. In tight joist bays or against a wall, check the swing of the actuator before you commit to the joint location.
