Metallics JRM106SLT 8-32 x 1-3...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.26
$0.26
Metallics JRM106SLT 8-32 x 1-3/4 in. Round Head Slotted Machine Screws - Steel Zinc - 100qty

Metallics JRM106SLT 8-32 x 1-3/4 in. Round Head Slotted Machine Screws - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JRM106SLT
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.26
$0.26
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
8-32 x 1-3/4 in. Round Head Slotted Machine Screws - Steel Zinc - 100qty

  • Additional Notes

    • In 1985, Metallics was the first fastener company in America to offer a full line of Combo’s! | Other sizes and quantities available by request | Tensile strength values for stainless screws are offered as approximations only; there is no single standard for the performance requirements of stainless machine screws.

  • Features

    • Steel Zinc Material
    • Round head with slotted Drive
    • 8-32 Diameter, 1-3/4" Length

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
C
Buy American Compliant:
C
Division:
Electrical H1
Drive Type:
Slotted
Fastener Head Height:
0.107 - 0.12 in.
Fastener Head Type:
Round
Fastener Head Width:
0.287 - 0.309 in.
Fastener Length:
1/3/04
Hardness:
Rockwell B70-B100
Language Code:
EN
Material Standard:
AISI 1006 - 1022
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Round_Head_Machine_Screw.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Product Group:
Fasteners
Product Height:
2.7 in
Product Length:
3 in
Product Weight:
0.98 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.064 - 0.090
Slot Depth:
0.058 - 0.077
Slot Width:
0.045 - 0.054
Sub Division:
Electrical-E H2
Tensile Strength:
60000 psi minimum
Thread Per Inch:
32
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Machine Screw
Type2:
Machine Screw
Series:
JRM
Product Finish:
Zinc
Product Details:
Machine Screw
Product Material:
Steel Zinc

Metallics JRM106SLT – Frequently Asked Questions

1) Do I need a nut, or does this screw thread into something?
A machine screw has no point and will not cut its own thread. The JRM106SLT needs either a tapped 8-32 hole, like the mounting ears on an outlet box or a device yoke, or a matching 8-32 nut on the back side. Nuts and washers are not included with the jar of screws.
2) How many 8-32 x 1-3/4 round head machine screws come in a jar?
They ship in a jar of 100, and 100 count is the order minimum, so the smallest buy is a full jar rather than loose pieces. The jar weighs 0.98 lbs.
3) Will a round head machine screw sit flush, or does the head stand above the surface?
Round head means the head sits on top of the surface, not in it. The head measures 0.287 to 0.309 in. across and 0.107 to 0.12 in. high, so budget about an eighth of an inch of standoff. If you need the head buried in the plate, you want a flat head screw in a countersunk hole instead.
4) Are these zinc plated screws suitable for outdoor or damp locations?
The material is zinc plated steel, which is a dry indoor to lightly protected finish. Zinc gives you handling and storage corrosion protection, not long term weather exposure. For wet locations, exterior boxes, coastal air, or anywhere washed down, go with a stainless 8-32 machine screw.
5) How strong is a Metallics 8-32 steel machine screw?
Minimum tensile strength is 60,000 psi, with hardness in the Rockwell B70 to B100 range, made from AISI 1006 to 1022 low carbon steel. That is standard commercial grade machine screw material, fine for mounting devices, plates, straps, and light fixture hardware. It is not a structural or high strength fastener, so do not substitute it where a graded bolt is specified.
6) Do these screws meet Buy American or ARRA requirements on a public job?
Metallics flags the JRM106SLT as compliant for both ARRA and Buy American, with country of origin listed as China. On federally funded work, confirm which clause your contract invokes, because the compliance flag and the origin need to be read together by your submittal reviewer.
