Metallics JTEK14PV 8 x 1 in. P...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.20
$0.20
Metallics JTEK14PV 8 x 1 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 500qty

Metallics JTEK14PV 8 x 1 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTEK14PV
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.20
$0.20
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
8 x 1 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 500qty

  • Features

    • Pan Head with Phillips Drive
    • Steel Zinc Material
    • 8 Diameter, 1" Length
    • #2 Drill Point

  • Additional Notes

    • Other sizes and quantities available by request | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

Manufacturer Resources

Product Specs

Minimum Purchase:
500 units
Arra Compliant:
C
Buy American Compliant:
C
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#2
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Color:
Silver
Fastener Head Height:
0.105 - 0.115 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.306 - 0.322 in.
Fastener Length:
1
Hardness:
Rockwell C32-40
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Hd_Phil_Self-Drill_TS_Steel_and_SS.pdf
Order Minimum Imperial:
500
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Panel Thickness:
0.035 - 0.100 IN
Phillips Recess Diameter:
0.175
Product Group:
Fasteners
Product Height:
3.6 in
Product Length:
3 in
Product Weight:
2.75 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.071 - 0.097
Screw Point Type:
Drill Point
Sub Division:
Electrical-E H2
Thread Per Inch:
18
Thread Standard:
SAE J78 - 2013
Thread Type:
UNC
Torsional Strength:
42 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEK
Product Finish:
Zinc
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
Steel Zinc

Metallics JTEK14PV – Frequently Asked Questions

1) What standards do these self-drilling screws meet for a submittal package?
Dimensions conform to ASME B18.6.3-2010 and threads to SAE J78 - 2013, with UNC thread at 18 threads per inch. Case hardness is Rockwell C32-40 and minimum torsional strength is 42 lb-in. The item is flagged both ARRA compliant and Buy American compliant, with country of origin listed as multiple.
2) Do I need a pilot hole for these Metallics JTEK14PV screws?
No. It's a Type BSD self-drilling and tapping screw, so the drill point cuts its own hole and the UNC thread taps it in one pass. Drive it straight with steady pressure and no pre-drilling into 0.035 to 0.100 in. panel.
3) What size driver bit do I need for these screws?
A #2 Phillips bit. Both the drive and the driver size are #2, with a recess diameter of 0.175 in. and a gaging depth of 0.071 to 0.097 in. Using a #1 will cam out; a #3 won't seat in the recess.
4) Will the pan head sit flush, or does it stand above the surface?
Pan head, so it sits on top of the surface rather than sinking in. Head height runs 0.105 to 0.115 in. and head width 0.306 to 0.322 in., giving a bearing face wider than the #8 shank for clamping sheet metal, straps, and brackets. If you need the head buried, you want a flat or wafer head instead.
5) Is this screw suitable for outdoor or damp locations?
These are steel with a zinc finish, silver in appearance. Zinc plating handles dry interior work, electrical enclosures, and raceway fine, but it is not a stainless or coated exterior fastener. For sustained weather exposure or corrosive environments, specify a stainless self-drilling screw.
6) Will a 1 inch long screw be too long for mounting to a metal stud?
At 1 in. of overall length with 18 TPI UNC thread, the JTEK14PV leaves plenty of thread past a 20 to 12 gauge panel. Point and thread will protrude behind the stud flange, which is fine in a wall cavity but something to watch where the back side is exposed or where wiring runs tight behind the stud. If protrusion is a problem, step down to a shorter length in the same #8 diameter.
7) How many Metallics JTEK14PV screws come in a jar, and is there an order minimum?
They ship in a jar at a 500-count minimum order, weighing 2.75 lbs. Jar footprint is 3 x 3 x 3.6 in., so it fits a van bin or gang box shelf easily.
8) Can I use these on wood instead of metal?
It's built for sheet metal: a drill point and tapping thread sized to a 0.035 to 0.100 in. panel. In wood it will drive, but the drill point reams rather than bites and holding power suffers. Use a wood or deck screw for timber and keep the BSD screw for sheet, stud, strut, and enclosure work.
9) Is the #2 drill point and #2 driver size the same thing?
No, and it trips people up. The #2 under Drill Point Size describes the cutting tip geometry that sets the metal thickness range it will bore. The #2 under driver size is the Phillips bit that fits the head recess. They happen to share a number on the JTEK14PV but they refer to opposite ends of the screw.
