Metallics JTEK16P 8 x 5/8 in. ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.31
$0.31
Metallics JTEK16P 8 x 5/8 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 100qty

Metallics JTEK16P 8 x 5/8 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTEK16P
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.31
$0.31
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
8 x 5/8 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 100qty

  • Additional Notes

    • Other sizes and quantities available by request | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

  • Features

    • #2 Drill Point
    • Steel Zinc Material
    • Pan Head with Phillips Drive
    • 8 Diameter, 5/8" Length

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#2
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.105 - 0.115 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.306 - 0.322 in.
Fastener Length:
8-May
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Hardness:
Rockwell C32-40
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Hd_Phil_Self-Drill_TS_Steel_and_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Panel Thickness:
0.035 - 0.100 IN
Phillips Recess Diameter:
0.175
Product Group:
Fasteners
Product Height:
2.15 in
Product Length:
3 in
Product Weight:
0.41 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.071 - 0.097
Screw Point Type:
Drill Point
Sub Division:
Electrical-E H2
Thread Per Inch:
18
Thread Standard:
SAE J78 - 2013
Torsional Strength:
42 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEK
Product Finish:
Zinc
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
Steel Zinc

Metallics JTEK16P – Frequently Asked Questions

1) What standards do these Metallics TEK screws conform to, and are they Buy American compliant?
Head and recess geometry follows ASME B18.6.3-2010, and the thread and drill point follow SAE J78-2013. They are not Buy American compliant and are not ARRA compliant, with multiple countries of origin, so they will not satisfy a domestic-sourcing requirement on a federally funded job.
2) Do I need a pilot hole for the Metallics JTEK16P screws?
No. It is a Type BSD self-drilling and tapping screw, so the drill point cuts the hole and the 18 threads-per-inch thread forms its own mating thread in one pass. Just hold steady pressure until the point breaks through before the threads engage.
3) How much torque can a #8 Metallics TEK screw take before it snaps?
Minimum torsional strength is 42 lb-in, with the screw hardened to Rockwell C32-40. That is plenty for a screw gun on a clutch setting, but an impact driver run wide open will twist the head off a #8. Set the clutch and stop when the head seats.
4) Will a pan head screw sit flush, or does it stand proud of the panel?
It stands proud. The pan head is 0.105 to 0.115 inch high and 0.306 to 0.322 inch across, bearing on the surface rather than countersinking. Use it where you want clamping area on sheet metal or a bracket. If you need a flush face, you need a flat head screw and a countersunk hole.
5) Is a 5/8 inch TEK screw long enough for mounting boxes and straps to metal studs?
At 5/8 inch overall with a #8 diameter, there is enough length to pass through a strap or box ear and still get full thread engagement in sheet steel up to 0.100 inch thick. If you are stacking two brackets plus a panel, step up to a longer screw in the same JTEK family so the drill point clears the back of the steel before the threads load up.
6) How are the Metallics JTEK16P self-drilling screws packaged and what is the minimum order?
They come in a jar of 100, which is the order minimum. Shelf weight is 0.41 lbs for the jar.
