90120 Viega MegaPress tee Smart Connect technology 316 stainless steel, 1-1/2'' x 1-1/2''x 1-1/2''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x P3
- Material Type:
- 316 Stainless Steel
- Product Dimension:
- 1-1/2'' x 1-1/2''x 1-1/2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 6.953"
- Product Height:
- 2.437"
- Product Weight:
- 1.887 lbs
- Product Width:
- 4.65"
- Product Material:
- 316 stainless steel
Viega 90120 – Frequently Asked Questions
1) Is the Viega 90120 press tee carbon steel or stainless?
It is 316 stainless steel, not carbon steel. That matters when you are choosing between MegaPress and MegaPressG carbon fittings: the 316 body suits lines where the carbon steel version would be attacked, and it is the one to specify on stainless or corrosion-sensitive systems.
2) What is Smart Connect on the Viega 90120 tee and why does it matter on the job?
Smart Connect is Viega's unpressed-connection feature built into the 90120 MegaPress tee. It is there so a connection that was assembled but never pressed shows itself during pressure testing rather than after the walls are closed. It does not change the fitting's size or press tooling, it just makes a missed press findable.
3) How much room do I need to fit a 1-1/2 inch MegaPress stainless tee in a tight chase?
The 90120 tee measures 6.953 inches in length, 4.65 inches in width and 2.437 inches in height, and weighs 1.887 lbs. Lay that out against your chase or joist bay before committing, because the press tool jaw needs clearance around each of the three ends on top of the fitting's own footprint.
4) What exact part number do I order for a 1-1/2 inch 316 stainless MegaPress tee?
Viega part 90120. One configuration only, so there are no finish or end-type options to pick: it is the 1-1/2 x 1-1/2 x 1-1/2 inch stainless MegaPress tee.
5) Where is the Viega 90120 MegaPress tee manufactured?
Made in Germany. For submittals or buy-local documentation on a public job, that is the country of origin to list for part 90120.
