95160 Viega MegaPress tee Smart Connect technology 304 stainless steel, 2'' x 2'' x 1/2''
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x P3
- Material Type:
- 304 Stainless Steel
- Product Dimension:
- 2'' x 2'' x 1/2''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 7.646"
- Product Height:
- 2.894"
- Product Weight:
- 2.082 lbs
- Product Width:
- 4.283"
- Product Material:
- 304 stainless steel
Viega 95160 – Frequently Asked Questions
1) What pipe sizes does the Viega 95160 MegaPress tee connect?
The Viega 95160 MegaPress tee is a 2 inch x 2 inch x 1/2 inch reducing tee. The run is 2 inch on both ends with a 1/2 inch branch outlet, so it taps a small branch (gauge, drain, drop) off a 2 inch main.
2) Are all three ends of the Viega 95160 tee press connections, or is one threaded?
All three are press. The connection type is P1 x P2 x P3, meaning press on both 2 inch run ends and on the 1/2 inch branch. There is no threaded or sweat end on this fitting, so you press all three joints with the appropriate jaw or ring for each size.
3) Can I use the Viega 95160 MegaPress tee to branch off existing black iron pipe without threading it?
That is what MegaPress is for. It presses onto IPS pipe, so you cut the 2 inch main, slide the tee in and press all three joints, no threading, no cutting oil, no hot work. Connection type is P1 x P2 x P3 and the branch comes off at 1/2 inch.
4) Is the Viega 95160 MegaPress tee stainless or carbon steel?
It is 304 stainless steel, body and all. That matters when you are choosing between the carbon steel MegaPress line and the stainless line, pick stainless where the pipe or the environment would corrode a carbon steel fitting.
5) What is Smart Connect on the Viega 95160 and why should an inspector care?
Smart Connect is Viega's unpressed connection feature. The fitting is built so an unpressed joint leaks under test rather than passing quietly, which lets you find the missed connection during pressure testing instead of after the wall is closed. On a 2 inch x 2 inch x 1/2 inch tee that is three separate presses to account for, so the feature earns its keep here.
6) How heavy is a 2 inch stainless MegaPress tee for overhead hanger spacing?
The 95160 weighs 2.082 lbs on its own. For an overhead 2 inch stainless run, that dead weight plus the 1/2 inch branch and whatever it feeds is what you support, hang close to the fitting rather than letting it float mid-span.
7) Where is the Viega 95160 MegaPress tee made?
Made in Germany. Useful if your project has country of origin reporting or a submittal that asks for it.
